System And Components
216-1747 CYLINDER GP-SUSPENSION -REARS/N CXM1-UP
Group No: 216-1747
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B8489 | 1 FITTING-GREASE (1/8-27 PTF) | 2 | |
| 5M6707 | 2 VALVE-RELIEF (SUSPENSION CYLINDER) | 1 | |
| 5M6708 | 3 WASHER (0.609X1.25X0.219-IN THK) | 1 | |
| 7J5547 | 4 COVER AS | 2 | |
| 7Y4294 | 5 SEAL-O-RING | 1 | |
| 8T7694 | 6 RING-WEAR | 1 | |
| 9T5505 | 7 PLATE | 1 | |
| 2238455 | 8 CYLINDER AS | 1 | |
| 2234397 | 9 HEAD | 1 | |
| 2253901 | 10 ROD | 1 | |
| 1753184 | 11 VALVE GP (SUSPENSION CYLINDER CHARGING) | 2 | |
| 6J0368 | CAP | 1 | |
| 1753185 | CORE-VALVE | 1 | |
| 2236475 | 12 BOLT (7/16-14X4-IN) | 4 | |
| 1143361 | 13 SEAL-O-RING (FUEL SYSTEM) | 2 | |
| 2792269 | 14 FILM-WARNING (CRUSH HAZARD, READ MANUAL) | 1 | |
| 2792271 | 15 FILM-WARNING (HIGH PRESSURE, READ MANUAL) | 1 | |
| 2H5001 | 16 SEAL-O-RING | 2 | |
| 3179115 | 17 FILM-INFORMATION (CYLINDER PRESS, READ OMM) | 1 | |
| 4335903 | 18 SEAL-U-CUP | 1 | |
| 3402379 | 19 RING-RETAINING | 4 | |
| 4J6557 | 20 RING | 1 | |
| 5P8244 | 21 WASHER-HARD (12X22.5X2.5-MM THK) | 18 | |
| 6J1144 | 22 BEARING (SELF ALIGNING) | 2 | |
| 7F8698 | 23 BOLT (7/16-14X3.5-IN) | 14 | |
| 9X7333 | 24 SEAL-LIP TYPE | 1 | |
| 2976848 | KIT-SEAL (HYDRAULIC CYLINDER) | 1 |
