265-8058 DRIVE GP-FAN -DIRECT DRIVES/N EED1083-UP

Group No: 265-8058 · Commonality

Part Number	Part Name	Qty
2M2742	1 PLATE-RETAINER	1
2S6150	2 COVER-PULLEY	1
3B4617	3 PIN-COTTER	2
4N8278	4 V-BELT SET (INCLUDES 3-BELTS)(FAN DRIVE)	1
4W1203	5 CUP-BEARING	1
4W1204	6 CONE-BEARING	1
5M9735	7 SEAL-LIP TYPE	1
6N3641	8 PULLEY-TIGHTENER	1
6Y2736	9 CONE-BEARING	1
6Y2737	10 CUP-BEARING	1
8N5579	11 RETAINER	1
8B2327	12 RING-RETAINING	1
3225108	13 ARM AS (BELT TIGHTENER)	1
4N0955	DOWEL	1
4S5367	BUSHING AS (MOUNT)	1
8N4550	SHAFT-PULLEY	1
3272476	14 SPRING AS	1
3841616	15 BRACKET	1
1795610	16 PULLEY-FAN	1
2652839	17 PULLEY (CRANKSHAFT)	1
2655827	18 ADAPTER	1
2747947	19 GUARD GP-BELT	1
4264304	20 BRACKET AS	1
1S9209	SHAFT-TIGHTENER	1
4N0955	DOWEL	1
6V2852	DOWEL	1
2837316	21 ADAPTER-FAN	1
4264306	22 PLATE	1
3446159	23 HUB-FAN PULLEY	1
3446160	24 SHIM	1
3459170	25 SPACER-BEARING (35.3X45.5X38.331-MM THK)	1
0310228	26 BOLT-12 POINT HEAD (1/2-13X3-IN)	4
7V9791	27 PIN	2
1S8687	28 SPACER (25.5X33.4X31.75-MM THK)	1
2S6151	29 GASKET	1
2S6160	30 WASHER-HARD (10.2X32X5-MM THK)	1
4M6425	31 BOLT (5/16-18X1-IN)	4
5M3062	32 BOLT (3/8-16X0.75-IN)	1
5M6214	33 PLUG (1/8-27 PTF)	1
5P1075	34 WASHER-HARD (10.2X22.5X3-MM THK)	1
5S2106	35 SEAL-LIP TYPE	1
5S7379	36 BOLT (3/8-16X0.875-IN)	1
5S9062	37 SPACER (35.032X50.8X15.88-MM THK)	1
6B1124	38 BALL BEARING	2
4H8380	39 PIN-SPRING	1
6V8188	40 NUT (1/2-13-THD)	1
6V8801	41 NUT (3/8-16-THD)	6
7X2550	42 BOLT (M12X1.75X110-MM)	2
2U2580	43 NUT-NYLOCK (M18X1.5-THD)	1
8T4223	44 WASHER-HARD (13.5X25.5X3-MM THK)	5
8T4896	45 WASHER-HARD (10.2X18.5X2.5-MM THK)	7
8T6868	46 BOLT (M12X1.75X80-MM)	2
8T7008	47 BOLT (3/8-16X3-IN)	6
8T8920	48 BOLT (1/2-13X3.25-IN)	4
8T9377	49 BOLT (3/8-16X2.25-IN)	1
9F4446	50 SEAL-O-RING	1
