System And Components
250-7573 DRIVE GP-FAN -FAN CLUTCHS/N DLS1-332
Group No: 250-7573 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2M2742 | 1 PLATE-RETAINER | 1 | |
| 2S6150 | 2 COVER-PULLEY | 1 | |
| 3B4617 | 3 PIN-COTTER | 2 | |
| 6N3641 | 4 PULLEY-TIGHTENER | 1 | |
| 7W1399 | 5 RETAINER-SPRING | 1 | |
| 9N6670 | 6 ARM AS | 1 | |
| 4N0955 | DOWEL | 1 | |
| 4S5367 | BUSHING AS (MOUNT) | 1 | |
| 8N4550 | SHAFT-PULLEY | 1 | |
| 1255071 | 7 SPRING | 1 | |
| 1795609 | 8 BRACKET | 1 | |
| 1927139 | 9 MANIFOLD GP-CONTROL (FAN DRIVE) | 1 | |
| 2053692 | 10 ELBOW AS (90-DEG) | 1 | |
| 9X2134 | ELBOW (90-DEG) | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 2431872 | 11 DRIVE GP-FAN | 1 | |
| 2747947 | 12 GUARD GP-BELT | 1 | |
| 2792617 | 13 WIRING GP-FAN | 1 | |
| 2793361 | 14 ADAPTER-FAN | 1 | |
| 2793363 | 15 BRACKET AS (FAN) | 1 | |
| 1S9209 | SHAFT-TIGHTENER | 1 | |
| 4N0955 | DOWEL | 1 | |
| 2793364 | 16 TUBE AS | 1 | |
| 2793365 | 17 TUBE AS | 1 | |
| 2793366 | 18 TUBE AS | 1 | |
| 2793367 | 19 HOSE AS | 1 | |
| 2793368 | 20 HOSE AS | 1 | |
| 2793370 | 21 PLATE AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 3 | |
| 2793371 | 22 PLUG | 1 | |
| 2793372 | 23 ADAPTER | 1 | |
| 2793466 | 24 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 2808728 | 25 V-BELT SET (INCLUDES 3-BELTS)(FAN) | 1 | |
| 2808730 | 26 PULLEY (CRANKSHAFT) | 1 | |
| 0310228 | 27 BOLT-12 POINT HEAD (1/2-13X3-IN) | 4 | |
| 0910081 | 28 SPACER (10.5X20X10-MM THK) | 4 | |
| 1008533 | 29 PULLEY-FAN DRIVE | 1 | |
| 1488336 | 30 CONNECTOR AS | 2 | |
| 6V8636 | CONNECTOR (SEAL) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488340 | 31 CONNECTOR AS | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488361 | 32 ELBOW AS (90-DEG) | 1 | |
| 6V9200 | ELBOW (FACE SEAL) | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488364 | 33 ELBOW AS | 1 | |
| 6V8625 | ELBOW (90-DEG) | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488365 | 34 ELBOW AS | 1 | |
| 8T6876 | ELBOW (90-DEG) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488435 | 35 TEE AS (ORFS) | 1 | |
| 6V8781 | TEE | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 1488444 | 36 TEE AS-SWIVEL | 1 | |
| 6V9837 | TEE-SWIVEL | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 0S0175 | 37 PIN-CLEVIS | 2 | |
| 1F7958 | 38 NUT-FULL (1/2-13-THD) | 4 | |
| 1S8687 | 39 SPACER (25.5X33.4X31.75-MM THK) | 1 | |
| 2D8154 | 40 STUD-TAPERLOCK (1/2-13X2.36-IN) | 4 | |
| 2S6151 | 41 GASKET | 1 | |
| 4M6425 | 42 BOLT (5/16-18X1-IN) | 4 | |
| 5P1076 | 43 WASHER-HARD (13.5X30X4-MM THK) | 8 | |
| 5P2566 | 44 BOLT (1/2-13X1.5-IN) | 6 | |
| 5S7379 | 45 BOLT (3/8-16X0.875-IN) | 1 | |
| 5S7382 | 46 BOLT (3/8-16X1.375-IN) | 9 | |
| 6B1124 | 47 BALL BEARING | 2 | |
| 6D4246 | 48 CLIP (LOOP) | 2 | |
| 6V8188 | 49 NUT (1/2-13-THD) | 1 | |
| 7X0293 | 50 BOLT (3/8-16X4.75-IN) | 1 | |
| 8M2773 | 51 CLIP (LOOP) | 3 | |
| 8T4121 | 52 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4136 | 53 BOLT (M10X1.5X25-MM) | 3 | |
| 8T4176 | 54 BOLT (M12X1.75X90-MM) | 2 | |
| 8T4223 | 55 WASHER-HARD (13.5X25.5X3-MM THK) | 11 | |
| 8T4896 | 56 WASHER-HARD (10.2X18.5X2.5-MM THK) | 14 | |
| 8T6868 | 57 BOLT (M12X1.75X80-MM) | 2 | |
| 8T8920 | 58 BOLT (1/2-13X3.25-IN) | 4 | |
| 8T9377 | 59 BOLT (3/8-16X2.25-IN) | 3 | |
| 9M9647 | 60 SEAL-O-RING | 1 | |
| 5M6214 | 61 PLUG (1/8-27 PTF) | 1 | |
| 5M9735 | 62 SEAL-LIP TYPE | 1 |
