System And Components
460-5847 VALVE GP-CONTROL -HOISTS/N RTL1-UP
Group No: 460-5847
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4183 | 1 BOLT (M12X1.75X40-MM) | 12 | |
| 8T4184 | 2 BOLT (M12X1.75X45-MM) | 8 | |
| 8T4186 | 3 BOLT (M10X1.5X40-MM) | 16 | |
| 7X2543 | 4 BOLT (M10X1.5X120-MM) | 2 | |
| 7X2546 | 5 BOLT (M10X1.5X180-MM) | 2 | |
| 7X2549 | 6 BOLT (M12X1.75X100-MM) | 4 | |
| 8T6868 | 7 BOLT (M12X1.75X80-MM) | 4 | |
| 1P4578 | 8 FLANGE-HALF | 8 | |
| 1P4579 | 9 FLANGE-HALF | 4 | |
| 1P4582 | 10 FLANGE-HALF | 2 | |
| 1P4584 | 11 FLANGE-HALF | 4 | |
| 1U0323 | 12 PLUG AS | 3 | |
| 1U0322 | 12A BUSHING | 1 | |
| 3G2683 | 12B PLUG | 1 | |
| 3P9498 | 13 PLUG-ORIFICE | 1 | |
| 4H5232 | 15 PIN-SPRING | 3 | |
| 5P0840 | 16 SEAL-O-RING | 1 | |
| 6E5066 | 17 SCREEN (HYDRAULIC)(CONTROL MANIFOLD) | 1 | |
| 4477206 | 18 SEAL-O-RING | 1 | |
| 6V7418 | 19 PLUG-PIPE | 2 | |
| 7J7423 | 20 VALVE-CONTROL | 3 | |
| 7S8491 | 21 SPRING | 3 | |
| 8J4351 | 22 SEAL-O-RING | 1 | |
| 8L2777 | 23 SEAL-O-RING | 1 | |
| 8T4121 | 24 WASHER-HARD (11X21X2.5-MM THK) | 20 | |
| 8T4223 | 25 WASHER-HARD (13.5X25.5X3-MM THK) | 22 | |
| 8T5001 | 26 BOLT (M12X1.75X130-MM) | 5 | |
| 0617540 | 27 SEAL-O-RING | 1 | |
| 1067683 | 28 ADAPTER | 1 | |
| 1138263 | 29 PISTON | 1 | |
| 1327102 | 30 VALVE GP-COUNTERBALANCE | 1 | |
| 1488407 | 31 PLUG AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 1621492 | 32 CONNECTOR | 1 | |
| 2287096 | 33 SEAL-O-RING | 3 | |
| 2501424 | 34 ELBOW AS | 1 | |
| 6V8724 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 3409727 | 36 VALVE GP-CHECK | 1 | |
| 3893708 | 38 PLUG AS | 6 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3603679 | PLUG-CONNECTOR (9/16-18-THD) | 1 | |
| 3893709 | 39 PLUG AS | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3603682 | PLUG-O-RING | 1 | |
| 3985596 | 40 PLUG AS | 2 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3603680 | PLUG (3/4-16-THD) | 1 | |
| 3985604 | 41 PLUG AS | 2 | |
| 2385078 | SEAL-O-RING | 1 | |
| 3603675 | PLUG (5/16-24-THD) | 1 | |
| 4607073 | 42 VALVE GP-RELIEF (LOW PRESSURE) | 1 | |
| 4640589 | 45 VALVE GP-RELIEF (HIGH PRESSURE) | 1 | |
| 4666675 | 46 TUBE AS | 1 | |
| 4852109 | 47 ACTUATOR GP-PILOT CONTROL (RAISE, LOWER) | 2 | |
| 2352480 | 48 SEAL-RECTANGULAR | 1 | |
| 6V8200 | 49 BOLT-SOCKET HEAD (M12X1.75X35-MM) | 4 | |
| 3D4603 | 50 PLUG-PIPE | 1 | |
| 3D8908 | 52 COVER | 1 | |
| 1757895 | 53 SEAL-O-RING | 1 | |
| 2660531 | 54 CAP-CONNECTOR | 2 | |
| 1685047 | KIT-SEAL (COUNTERBALANCE VALVE) | 1 |
