System And Components
532-8854 VALVE GP-CONTROLS/N SMX1-208
Group No: 532-8854
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7X2546 | 1 BOLT (M10X1.5X180-MM) | 4 | |
| 8T5436 | 2 BOLT (M10X1.5X130-MM) | 4 | |
| 2176720 | 3 ACTUATOR GP-PILOT CONTROL (LIFT CYLINDER ROD END) | 1 | |
| 2176720 | 3A ACTUATOR GP-PILOT CONTROL (TILT CYLINDER ROD END) | 1 | |
| 2176720 | 3B ACTUATOR GP-PILOT CONTROL (TILT CYLINDER HEAD END) | 1 | |
| 2176720 | 3C ACTUATOR GP-PILOT CONTROL (LIFT CYLINDER HEAD END) | 1 | |
| 1H5728 | 4 SEAL-O-RING | 2 | |
| 1P3709 | 5 SEAL-RECTANGULAR | 1 | |
| 2J6274 | 6 SEAL-O-RING | 4 | |
| 2S4078 | 7 SEAL-O-RING | 2 | |
| 4B4158 | 8 SCREW-DRIVE (NO 4X0.25-IN) | 4 | |
| 4J0523 | 9 SEAL-O-RING | 1 | |
| 4J0525 | 10 SEAL-O-RING | 1 | |
| 4T4073 | 11 VALVE GP-SHUTTLE | 1 | |
| 4T5896 | 12 VALVE GP-CHECK | 1 | |
| 6E1291 | 13 VALVE-CONTROL | 1 | |
| 6V0852 | 14 CAP-DUST | 1 | |
| 6V3668 | 15 BOLT (M12X1.75X30-MM) | 2 | |
| 7J1592 | 16 COVER | 1 | |
| 7J7852 | 17 SPRING | 1 | |
| 8L6565 | 18 PIN-SPRING | 4 | |
| 8T4121 | 19 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 8T5001 | 20 BOLT (M12X1.75X130-MM) | 2 | |
| 9F2167 | 21 SCREW-PURGE (3/8-24X1.164-IN) | 2 | |
| 9J4782 | 22 PROTECTOR | 2 | |
| 9L9188 | 23 SPRING-VALVE | 2 | |
| 0959804 | 24 BOLT-SOCKET HEAD (M12X1.75X110-MM) | 4 | |
| 1024156 | 25 VALVE-CONTROL | 2 | |
| 1024158 | 26 PLUG AS | 2 | |
| 3G5003 | BUSHING | 1 | |
| 1024157 | PLUG | 1 | |
| 1128244 | 27 HOUSING | 1 | |
| 1138263 | 28 PISTON | 2 | |
| 1471223 | 29 VALVE GP-SOLENOID (24-VOLT)(ON, OFF, FLOAT) | 1 | |
| 1488406 | 30 PLUG AS | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 9S9334 | PLUG (1-5/16-12-THD) | 1 | |
| 1607439 | 31 VALVE GP-MAKEUP (LIFT CYLINDER ROD END) | 1 | |
| 1645567 | 32 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1697403 | 33 ADAPTER AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6G3432 | ADAPTER | 1 | |
| 2048000 | 34 MOUNTING-CABLE TIE | 4 | |
| 2213939 | 35 VALVE GP-RELIEF (TILT CYLINDER ROD END) | 1 | |
| 3664694 | 37 PLUG AS | 9 | |
| 7J0204 | SEAL-O-RING | 1 | |
| 3664695 | 38 PLUG AS | 12 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 3603679 | PLUG-CONNECTOR (9/16-18-THD) | 1 | |
| 3676002 | 39 PLUG AS | 12 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 3603677 | PLUG (7/16-20-THD) | 1 | |
| 3676003 | 40 PLUG AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 3603680 | PLUG (3/4-16-THD) | 1 | |
| 3696862 | 41 PLUG AS | 2 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 3603684 | PLUG | 1 | |
| 3700438 | 42 VALVE GP-PRESSURE REDUCING | 1 | |
| 3961209 | 43 VALVE GP-SOLENOID (24-VOLT)(MANIFOLD) | 1 | |
| 3678532 | COIL AS (24-VOLT) | 1 | |
| 4655626 | NUT-SPECIAL (M18X1.5-THD) | 1 | |
| 3962304 | KIT-SEAL | 1 | |
| 4237710 | 44 VALVE GP-RELIEF (LIFT CYLINDER HEAD END) | 1 | |
| 4237711 | 45 VALVE GP-RELIEF (TILT CYLINDER HEAD END) | 1 | |
| 4401902 | 46 MANIFOLD | 1 | |
| 4402710 | 47 VALVE GP-RELIEF | 1 | |
| 9R5008 | 49 SPACER (11X20X6-MM THK) | 4 |
