System And Components
555-8050 VALVE GP-CONTROLS/N ST71-UP
Group No: 555-8050
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0617540 | 1 SEAL-O-RING | 1 | |
| 1067683 | 2 ADAPTER | 1 | |
| 2385086 | 3 SEAL-O-RING | 1 | |
| 1096918 | 4 VALVE GP-RELIEF | 1 | |
| 1138263 | 5 PISTON | 1 | |
| 1266104 | 6 PLUG | 1 | |
| 1266612 | 7 BODY | 1 | |
| 1327102 | 8 VALVE GP-COUNTERBALANCE | 1 | |
| 1621492 | 9 CONNECTOR | 1 | |
| 1P4578 | 10 FLANGE-HALF | 8 | |
| 1P4579 | 11 FLANGE-HALF | 4 | |
| 1P4582 | 12 FLANGE-HALF | 2 | |
| 1P4584 | 13 FLANGE-HALF | 4 | |
| 1U0323 | 14 PLUG AS | 3 | |
| 1U0322 | 14A BUSHING | 1 | |
| 3G2683 | PLUG | 1 | |
| 2287096 | 15 SEAL-O-RING | 3 | |
| 2287097 | 16 SEAL-O-RING | 1 | |
| 2352480 | 17 SEAL-RECTANGULAR | 1 | |
| 3886987 | 19 SHIM (0.4-MM THK) | 2 | |
| 3893708 | 20 PLUG AS | 6 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3603679 | PLUG-CONNECTOR (9/16-18-THD) | 1 | |
| 3985596 | 21 PLUG AS | 2 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3603680 | PLUG (3/4-16-THD) | 1 | |
| 3P9498 | 22 PLUG-ORIFICE | 1 | |
| 4852109 | 23 ACTUATOR GP-PILOT CONTROL | 2 | |
| 4H5232 | 25 PIN-SPRING | 3 | |
| 5P0840 | 28 SEAL-O-RING | 1 | |
| 6E5066 | 29 SCREEN (HYDRAULIC) | 1 | |
| 6J3380 | 30 SPRING | 1 | |
| 4477206 | 31 SEAL-O-RING | 1 | |
| 6V8200 | 32 BOLT-SOCKET HEAD (M12X1.75X35-MM) | 4 | |
| 6V8676 | 33 SEAL-O-RING | 1 | |
| 7J7423 | 34 VALVE-CONTROL (HOIST CONTROL) | 3 | |
| 7S8491 | 35 SPRING | 3 | |
| 7X2543 | 36 BOLT (M10X1.5X120-MM) | 2 | |
| 7X2546 | 37 BOLT (M10X1.5X180-MM) | 2 | |
| 7X2549 | 38 BOLT (M12X1.75X100-MM) | 4 | |
| 8B4624 | 39 SHIM (0.032-IN THK) | 11 | |
| 8J2379 | 40 VALVE-RELIEF (BRAKE COOLING) | 1 | |
| 8J4351 | 41 SEAL-O-RING | 1 | |
| 8L2777 | 42 SEAL-O-RING | 1 | |
| 8T4121 | 43 WASHER-HARD (11X21X2.5-MM THK) | 20 | |
| 8T4183 | 44 BOLT (M12X1.75X40-MM) | 12 | |
| 8T4184 | 45 BOLT (M12X1.75X45-MM) | 8 | |
| 8T4186 | 46 BOLT (M10X1.5X40-MM) | 16 | |
| 8T4223 | 47 WASHER-HARD (13.5X25.5X3-MM THK) | 22 | |
| 8T5001 | 48 BOLT (M12X1.75X130-MM) | 5 | |
| 8T6868 | 49 BOLT (M12X1.75X80-MM) | 4 | |
| 3893709 | 50 PLUG AS | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3603682 | PLUG-O-RING | 1 | |
| 3D4603 | 51 PLUG-PIPE | 1 | |
| 6V7418 | 52 PLUG-PIPE | 2 | |
| 3985604 | 53 PLUG AS | 2 | |
| 2385078 | SEAL-O-RING | 1 | |
| 3603675 | PLUG (5/16-24-THD) | 1 | |
| 3960393 | 54 PLUG AS | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3603677 | PLUG (7/16-20-THD) | 1 | |
| 1488407 | 55 PLUG AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 1757895 | 56 SEAL-O-RING | 1 | |
| 3D8908 | 57 COVER | 1 | |
| 1685047 | KIT-SEAL (COUNTERBALANCE VALVE) | 1 |
