517-3289 VALVE GP-CONTROLS/N RJZ1-UP

Group No: 517-3289

Part Number	Part Name	Qty
1P3709	1 SEAL-RECTANGULAR	1
1P4579	2 FLANGE-HALF	8
1P4582	3 FLANGE-HALF	2
1U0323	4 PLUG AS	1
1U0322	4A BUSHING	1
3G2683	PLUG	1
2S4078	5 SEAL-O-RING	1
3D4603	6 PLUG-PIPE	1
4H5232	8 PIN-SPRING	3
4J0519	9 SEAL-O-RING	2
4J2506	10 SEAL-O-RING	2
4J9780	11 PLUG-ORIFICE	1
5H6005	12 SEAL-O-RING	2
5J4664	13 SPRING	1
6C3241	14 BOLT (1/2-13X1.5-IN)	20
6E1297	15 SCREEN (HOIST CONTROL VALVE)	1
6J3405	16 SEAT	1
6V4432	17 BOLT (1/2-13X4-IN)	1
7D8048	18 SEAL-O-RING	2
7J7423	19 VALVE-CONTROL (HOIST CONTROL)	1
7S8491	20 SPRING	1
7X0293	21 BOLT (3/8-16X4.75-IN)	2
7X0301	22 BOLT (3/8-16X7-IN)	2
7X0326	23 BOLT (1/2-13X3-IN)	2
7X0339	24 BOLT (1/2-13X6.25-IN)	2
8T4223	25 WASHER-HARD (13.5X25.5X3-MM THK)	20
9P8217	26 WASHER (10X14.68X1.65-MM THK)	4
1051583	27 VALVE GP (MAIN RELIEF)	1
1051584	28 VALVE GP (HOIST DUAL STAGE)	1
1067683	29 ADAPTER	1
1138263	30 PISTON	1
1488395	31 PLUG AS	2
3K0360	SEAL-O-RING	1
9S8005	PLUG (3/4-16-THD)	1
1488407	32 PLUG AS	1
3J1907	SEAL-O-RING	1
9S4191	PLUG (9/16-18-THD)	1
1645619	33 PLUG AS	1
2M9780	SEAL-O-RING	1
9S8006	PLUG (7/8-14-THD)	1
1733993	34 PLUG AS	1
4J7533	SEAL-O-RING	1
9S8001	PLUG (5/16-24-THD)	1
1837263	37 PLUG AS	1
3J7354	SEAL-O-RING	1
9S8002	PLUG (7/16-20-THD)	1
2176720	38 ACTUATOR GP-PILOT CONTROL	2
3676001	39 PLUG AS	3
4J7533	SEAL-O-RING	1
3603675	PLUG (5/16-24-THD)	1
3676002	40 PLUG AS	1
3J7354	SEAL-O-RING	1
3603677	PLUG (7/16-20-THD)	1
4168724	41 VALVE GP-RELIEF (HOIST HIGH PRESSURE, RAISE)	1
4224594	42 VALVE GP-RELIEF (HOIST LOW PRESSURE, LOWER)	1
5173288	43 VALVE GP-RELIEF (HOIST)	1
1P6744	45 SPRING	1
2R1256	46 RING-RETAINING	1
