System And Components
106-8336 CONTROL GP-SERVICE BRAKE -CABS/N 6KR1-123
Group No: 106-8336
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1279501 | 1 FILM-INFORMATION (INDICATOR LIGHTS) | 1 | |
| 8T9394 | 2 BOLT-SOCKET HEAD (10-24X0.5-IN) | 2 | |
| 3D8935 | 3 HOSE AS | 1 | |
| 3D7587 | 4 ELBOW (EXTERNAL PIPE) | 4 | |
| 5S7379 | 5 BOLT (3/8-16X0.875-IN) | 1 | |
| 4L6454 | 6 BOLT (3/8-16X1-IN) | 2 | |
| 8T6765 | 7 PLUG-PIPE (1/4-18-THD) | 1 | |
| 2D6006 | 8 PIN | 1 | |
| 3B4610 | 9 PIN-COTTER | 1 | |
| 5D3426 | 10 ROLLER | 1 | |
| 7B9323 | 11 PIN | 1 | |
| 3B4607 | 12 PIN-COTTER | 1 | |
| 5H4778 | 13 ELBOW | 10 | |
| 4S7572 | 14 HOSE AS | 1 | |
| 8T4224 | 15 WASHER-HARD (8.8X16X2-MM THK) | 5 | |
| 5K2294 | 16 BEARING-SELF-ALIGNING | 2 | |
| 7D6096 | 17 HOSE AS | 2 | |
| 8D4973 | 18 HOSE AS | 1 | |
| 6J7926 | 19 HOSE AS | 2 | |
| 6D3797 | 20 HOSE AS | 1 | |
| 0045933 | 21 TEE-PIPE | 1 | |
| 2D7325 | 22 TEE-PIPE | 5 | |
| 4S6667 | 23 HOSE AS | 1 | |
| 8X7797 | 24 GASKET | 1 | |
| 3D8913 | 25 ELBOW | 1 | |
| 0308324 | 26 ELBOW | 1 | |
| 2H3940 | 27 ELBOW | 1 | |
| 2G8815 | 28 VALVE GP-RELIEF | 1 | |
| 7X0264 | 29 BOLT (1/4-20X2.5-IN) | 2 | |
| 6V8183 | 30 NUT-FULL (3/8-24-THD) | 2 | |
| 8T4205 | 31 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 3D8884 | 32 ELBOW | 2 | |
| 4M5317 | 33 BUSHING-REDUCER | 1 | |
| 5D9508 | 34 HOSE AS | 1 | |
| 3B7722 | 35 BUSHING-PIPE | 1 | |
| 6D1432 | 36 VALVE-CHECK | 1 | |
| 4M0061 | 37 BOLT (5/16-18X0.75-IN) | 5 | |
| 8W6908 | 38 VALVE (FRONT BRAKE) | 1 | |
| 3D6370 | 39 ELBOW | 1 | |
| 7D4922 | 40 HOSE AS | 1 | |
| 2G8573 | 41 CAP | 4 | |
| 6D3781 | 42 VALVE GP-CHECK (DOUBLE) | 1 | |
| 0045933 | 43 TEE-PIPE | 3 | |
| 2G8572 | 44 WASHER-SPECIAL | 4 | |
| 1313159 | 45 PEDAL-BRAKE | 1 | |
| 6D7317 | 46 HOSE AS | 1 | |
| 9J7600 | 47 CONNECTOR-PIPE | 2 | |
| 2D0193 | 48 CONNECTOR-PIPE | 1 | |
| 9D3886 | 49 VALVE GP-AIR CONTROL (RETARDER) | 1 | |
| 2G2512 | 50 SHAFT | 1 | |
| 1440691 | 51 SETSCREW-SPECIAL | 4 | |
| 5T9691 | 52 HANDLE | 1 | |
| 5T8285 | 53 JUNCTION BLOCK | 1 | |
| 5K8451 | 54 CLIP (LOOP) | 2 | |
| 5M3062 | 55 BOLT (3/8-16X0.75-IN) | 6 | |
| 8T4896 | 56 WASHER-HARD (10.2X18.5X2.5-MM THK) | 10 | |
| 4D2847 | 57 HOSE AS | 1 | |
| 8D9423 | 58 COUPLING | 2 | |
| 1284972 | 59 VALVE GP-AIR CONTROL (FRONT BRAKE ON/OFF) | 1 | |
| 8T6763 | 60 PLUG-PIPE (1/4-18-THD) | 2 | |
| 9D8098 | 61 VALVE GP-AIR CONTROL (SECONDARY BRAKE) | 1 | |
| 5T9690 | 62 HANDLE | 1 | |
| 2G2511 | 63 SHAFT AS | 1 | |
| 9M8662 | 64 COUPLING | 3 | |
| 4S7563 | 65 HOSE AS | 1 | |
| 4H6147 | 66 CONNECTOR | 4 | |
| 2B1016 | 67 SPRING | 1 | |
| 4J3914 | 68 ELBOW | 2 | |
| 9H7089 | 69 ROD END | 1 | |
| 9D3351 | 70 ELBOW | 1 | |
| 3P1823 | 71 ADAPTER-PIPE | 1 | |
| 9D8097 | 72 VALVE GP-AIR CONTROL (SERVICE BRAKE) | 1 | |
| 8T6762 | 73 PLUG-PIPE (1/2-14-THD) | 4 | |
| 9D3352 | 74 ELBOW | 1 | |
| 5S7382 | 75 BOLT (3/8-16X1.375-IN) | 4 | |
| 1313158 | 76 PLATE AS | 1 | |
| 4K9097 | NUT-WELD (5/16-18-THD) | 6 | |
| 5M6213 | 77 PLUG-PIPE (1/4-18-THD) | 1 |
