System And Components
106-8339 CONSOLE GP-OPERATORS/N 2YW1-UP
Group No: 106-8339
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E6754 | 1 GROMMET | 1 | |
| 3H2900 | 2 GROMMET | 1 | |
| 3L2540 | 3 BOLT-SOCKET HEAD (10-24X0.75-IN) | 2 | |
| 3S2093 | 4 STRAP-CABLE | 2 | |
| 4J7533 | 5 SEAL-O-RING | 4 | |
| 5B9318 | 6 BALL | 4 | |
| 5K0906 | 7 BOLT (5/16-18X0.625-IN) | 2 | |
| 5P1075 | 8 WASHER-HARD (10.2X22.5X3-MM THK) | 8 | |
| 6G0001 | 9 SHAFT | 1 | |
| 6G4092 | 10 BUSHING | 2 | |
| 6G4093 | 11 SPRING | 4 | |
| 6G4134 | 12 PIN | 4 | |
| 6V7699 | 13 WASHER-HARD (5.5X13X1.6-MM THK) | 2 | |
| 6V8185 | 14 NUT (1/4-20-THD) | 3 | |
| 6V8801 | 15 NUT (3/8-16-THD) | 8 | |
| 8L8413 | 16 STRAP-CABLE (WHITE) | 1 | |
| 8T4205 | 17 WASHER-HARD (7.2X14.5X2-MM THK) | 3 | |
| 8T4224 | 18 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8W0976 | 19 HOUSING | 1 | |
| 9S8001 | 20 PLUG (5/16-24-THD) | 4 | |
| 9X2042 | 21 SCREW-TRUSS HEAD (M6X1X12-MM) | 8 | |
| 1279499 | 22 FILM-INSTRUCTION (TRANSMISSION CONTROL)(TRANSMISSION CONTROL) | 1 | |
| 1636508 | 23 LAMP-LED (24-VOLT, WHITE) | 1 | |
| 1146658 | 24 WASHER (6.5X17X1-MM THK) | 4 | |
| 1169310 | 25 HARNESS AS | 1 | |
| 1253356 | 26 COVER AS | 1 | |
| 1253357 | 27 COVER AS | 1 | |
| 1253360 | 28 COVER AS | 1 | |
| 1253365 | 29 KNOB (SHIFT LEVER) | 1 | |
| 1266450 | 30 PLATE AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 8 | |
| 8D5476 | STUD-WELD (3/8-16X0.75-IN) | 4 | |
| 1267896 | 31 SENSOR GP-POSITION (TRANSMISSION SHIFT LEVER) | 1 | |
| 1279190 | 33 LEVER AS | 1 | |
| 6B3057 | RIVET | 2 | |
| 2A5351 | 34 NUT-JAM (3/8-24-THD) | 1 |
