System And Components
226-1267 PUMP GP-GEARS/N CXM1-UP
Group No: 226-1267
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V6800 | 1 BOLT-12 POINT HEAD (3/18-16X6.25-IN) | 2 | |
| 7B3028 | 2 SCREW-DRIVE (NO 4X 3/16-IN) | 1 | |
| 1287351 | 3 BODY AS | 1 | |
| 8M8489 | DOWEL | 4 | |
| 1845432 | 4 BODY AS-OIL PUMP | 1 | |
| 6P3223 | DAMPER-BOLT | 4 | |
| 8M8489 | DOWEL | 2 | |
| 1876571 | 5 MANIFOLD AS | 1 | |
| 1M3909 | 5A BUSHING | 2 | |
| 1915261 | 6 MANIFOLD AS | 1 | |
| 1M3909 | 6A BUSHING | 2 | |
| 8M8489 | DOWEL | 2 | |
| 3887192 | 7 COVER AS-PUMP | 1 | |
| 3651496 | 7A BUSHING | 2 | |
| 8M5007 | 8 SEAL-O-RING | 1 | |
| 2937509 | 9 GEAR (12-TEETH) | 2 | |
| 3763942 | 10 GEAR AS-OIL PUMP | 1 | |
| 3763943 | 11 GEAR AS-OIL PUMP | 1 | |
| 1291609 | 12 SEAL-O-RING | 3 | |
| 1653925 | 13 BOLT (3/8-16X5.75-IN) | 4 | |
| 2B9373 | 14 KEY-WOODRUFF | 1 | |
| 3S0004 | 15 WASHER (0.406X0.728X0.09-IN THK) | 6 |
