System And Components
245-1669 VALVE GP-CONTROL -HOISTS/N RLB876-UP
Group No: 245-1669 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P6744 | 1 SPRING | 1 | |
| 1U0323 | 2 PLUG AS | 1 | |
| 3G2683 | PLUG | 1 | |
| 1U0322 | BUSHING | 1 | |
| 6J3380 | 4 SPRING | 1 | |
| 6J3405 | 5 SEAT | 1 | |
| 7J7423 | 6 VALVE-CONTROL | 1 | |
| 8B4624 | 7 SHIM (0.032-IN THK) | 4 | |
| 1067683 | 8 ADAPTER | 1 | |
| 1138263 | 9 PISTON | 1 | |
| 1266612 | 10 BODY | 1 | |
| 4230466 | 11 VALVE GP-RELIEF (HOIST HIGH PRESSURE, RAISE) | 1 | |
| 2176720 | 14 ACTUATOR GP-PILOT CONTROL | 2 | |
| 0304606 | 16 SEAL-O-RING | 1 | |
| 1051583 | 17 VALVE GP | 1 | |
| 1051584 | 18 VALVE GP (HOIST DUAL STAGE) | 1 | |
| 4224594 | 19 VALVE GP-RELIEF (HOIST LOW PRESSURE, LOWER) | 1 | |
| 1266104 | 20 PLUG | 1 | |
| 1P3709 | 21 SEAL-RECTANGULAR | 1 | |
| 1P4579 | 22 FLANGE-HALF | 8 | |
| 1P4582 | 23 FLANGE-HALF | 2 | |
| 2R1256 | 24 RING-RETAINING | 1 | |
| 2S4078 | 25 SEAL-O-RING | 1 | |
| 4H5232 | 26 PIN-SPRING | 3 | |
| 4J0519 | 27 SEAL-O-RING | 2 | |
| 4J2506 | 28 SEAL-O-RING | 2 | |
| 5H6005 | 29 SEAL-O-RING | 2 | |
| 5J4664 | 30 SPRING | 1 | |
| 5P2566 | 31 BOLT (1/2-13X1.5-IN) | 20 | |
| 6E1297 | 32 SCREEN (HOIST CONTROL VALVE) | 1 | |
| 6K6307 | 33 SEAL-O-RING | 1 | |
| 6V4432 | 34 BOLT (1/2-13X4-IN) | 1 | |
| 6V8676 | 35 SEAL-O-RING | 1 | |
| 7D8048 | 36 SEAL-O-RING | 2 | |
| 7S8491 | 37 SPRING | 1 | |
| 7X0293 | 38 BOLT (3/8-16X4.75-IN) | 2 | |
| 7X0301 | 39 BOLT (3/8-16X7-IN) | 2 | |
| 7X0326 | 40 BOLT (1/2-13X3-IN) | 2 | |
| 7X0339 | 41 BOLT (1/2-13X6.25-IN) | 2 | |
| 8J2379 | 42 VALVE-RELIEF (BRAKE COOLING) | 1 | |
| 8T4223 | 43 WASHER-HARD (13.5X25.5X3-MM THK) | 20 | |
| 9P8217 | 44 WASHER (10X14.68X1.65-MM THK) | 4 | |
| 4J9780 | 45 PLUG-ORIFICE | 1 | |
| 3D4603 | 46 PLUG-PIPE | 1 | |
| 1488395 | 47 PLUG AS | 2 | |
| 9S8005 | PLUG (3/4-16-THD) | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 3676001 | 48 PLUG AS | 4 | |
| 3603675 | PLUG (5/16-24-THD) | 1 | |
| 4J7533 | SEAL-O-RING | 1 | |
| 1837263 | 49 PLUG AS | 1 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 3676004 | 50 PLUG AS | 1 | |
| 9S8006 | PLUG (7/8-14-THD) | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 1488407 | 51 PLUG AS | 1 | |
| 3603681 | PLUG (7/8-14-THD) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 3549539 | 52 VALVE GP-CONTROL (HOIST) | 1 | |
| 3676002 | 53 PLUG AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 3603677 | PLUG (7/16-20-THD) | 1 |
