System And Components
276-4002 MIRROR GPS/N JRP1-UP
Group No: 276-4002 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7D9969 | 1 SUPPORT | 4 | |
| 2958899 | 2 PLATE | 1 | |
| 1340987 | 3 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 3 | |
| 1340989 | 4 BLOCK | 2 | |
| 1442227 | 5 MIRROR GP (HEATED, 24-VOLT)(EXTERIOR, RH) | 2 | |
| 3227277 | 6 MIRROR (ADHESIVE BACKED) | 1 | |
| 3341004 | 7 TUBE AS | 2 | |
| 1293180 | 8 LOCKNUT (M12X1.75-THD) | 1 | |
| 2790467 | 9 MIRROR GP (EXTERIOR, HEATED, LH) | 1 | |
| 3K6060 | 10 LOCKNUT (3/8-16-THD) | 1 | |
| 5P1075 | 11 WASHER-HARD (10.2X22.5X3-MM THK) | 1 | |
| 5P1076 | 12 WASHER-HARD (13.5X30X4-MM THK) | 2 | |
| 5P7468 | 13 CLIP (SLOT) | 1 | |
| 5P7469 | 14 CLIP (TAB) | 1 | |
| 8T4137 | 15 BOLT (M10X1.5X20-MM) | 4 | |
| 8T6868 | 16 BOLT (M12X1.75X80-MM) | 4 | |
| 7X7468 | 17 MIRROR-CONVEX | 1 | |
| 8T4121 | 18 WASHER-HARD (11X21X2.5-MM THK) | 11 | |
| 8T4136 | 19 BOLT (M10X1.5X25-MM) | 3 | |
| 8T4183 | 20 BOLT (M12X1.75X40-MM) | 1 | |
| 8T4186 | 21 BOLT (M10X1.5X40-MM) | 4 | |
| 7X3391 | 22 WASHER-HARD (13.5X32X6-MM THK) | 4 | |
| 6V1874 | 23 GROMMET (31-MM ID) | 1 |
