System And Components
380-2236 LINES GP-FUELS/N TXW1-UP
Group No: 380-2236
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 2 | |
| 3253234 | 2 TUBE AS | 1 | |
| 3307736 | 3 HOSE AS | 1 | |
| 3307738 | 4 HOSE AS | 1 | |
| 3307739 | 5 HOSE AS | 1 | |
| 3307740 | 6 HOSE AS | 1 | |
| 3447826 | 7 MANIFOLD-FUEL | 1 | |
| 3522426 | 8 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 3528928 | 9 REGULATOR GP-FUEL PRESSURE | 1 | |
| 3534765 | 10 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 1653931 | 11 BOLT (3/8-16X1.75-IN) | 1 | |
| 1653929 | 12 BOLT (3/8-16X1.5-IN) | 2 | |
| 0S1588 | 13 BOLT (3/8-16X1.25-IN) | 1 | |
| 0S1618 | 14 BOLT (5/16-18X1-IN) | 2 | |
| 1833407 | 15 PLUG AS | 1 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1B2713 | 16 BOLT (1/4-20X1.75-IN) | 2 | |
| 2721777 | 17 WASHER-HARD (11X18.5X15-MM THK) | 1 | |
| 2A4639 | 18 BOLT (3/8-16X1.625-IN) | 1 | |
| 3031506 | 19 ELBOW AS | 2 | |
| 4K6297 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3139614 | 20 ADAPTER AS | 2 | |
| 2R6806 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3535108 | 21 ELBOW AS | 1 | |
| 2P7214 | ADAPTER-ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3537952 | 22 GROMMET | 1 | |
| 3537953 | 23 GROMMET | 2 | |
| 3650578 | 24 CONNECTOR AS | 1 | |
| 2P7636 | CONNECTOR (3/4-16 STR-THD) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 5M2894 | 25 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 5P0537 | 26 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 8T1889 | 27 CLIP (SLOT) | 2 | |
| 8T1890 | 28 CLIP (TAB) | 2 | |
| 8T1897 | 29 CLIP (SLOT) | 1 | |
| 8T1898 | 30 CLIP (TAB) | 1 | |
| 9M1974 | 31 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 7X7702 | 33 CONDUIT-FLEXIBLE (23.35-MM ID, SPLIT)(25-CM) |
