System And Components
359-3606 WHEEL GP-FINAL DRIVE & BRAKES/N RLB718-UP
Group No: 359-3606 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4D5642 | 1 SHIM PACK (INCLUDES 14-SHIMS) | 1 | |
| 4D8695 | 2 BOLT-WHEEL (1-5/16-12-THD) | 24 | |
| 5D0765 | 3 NUT-FULL (1-5/16-12-THD) | 24 | |
| 2088795 | 4 RETAINER | 1 | |
| 2373811 | 5 RETAINER | 1 | |
| 2389912 | 6 DRIVE GP-FINAL | 1 | |
| 2408240 | 7 BEARING AS | 2 | |
| 2942974 | 8 PLATE AS | 1 | |
| 3193887 | 9 SEAL GP-DUO-CONE | 1 | |
| 3493327 | 10 RING | 1 | |
| 3548503 | 11 BRAKE GP-SERVICE & PARKING | 1 | |
| 3565974 | 12 RETAINER-SEAL | 1 | |
| 3593605 | 13 WHEEL-REAR | 1 | |
| 3618117 | 14 SPINDLE-REAR | 1 | |
| 2446925 | 24 RING-RETAINING | 1 | |
| 3144122 | 25 SEAL GP-DUO-CONE | 1 | |
| 3144121 | 25A RING-TORIC | 2 | |
| 3K0360 | 26 SEAL-O-RING | 1 | |
| 3S3074 | 27 SEAL-O-RING | 1 | |
| 4M0737 | 28 SEAL-O-RING | 1 | |
| 5D0764 | 29 WASHER-HARD (34X57X8-MM THK) | 24 | |
| 5P8247 | 30 WASHER-HARD (17X32X3.5-MM THK) | 8 | |
| 7D7519 | 31 SEAL-O-RING | 1 | |
| 8T0357 | 32 BOLT (M16X2X70-MM) | 8 | |
| 8T4136 | 33 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4195 | 34 BOLT (M10X1.5X30-MM) | 8 | |
| 8T7934 | 35 WASHER-HARD (11X21X5-MM THK) | 4 | |
| 9S4185 | 36 PLUG (3/4-16-THD) | 1 | |
| 9X2027 | 37 WASHER (11X18X2-MM THK) | 8 | |
| 3638811 | SHIM PACK (INCLUDES 6-SHIMS) | 1 |
