System And Components
237-0439 LINES GP-WATER -RADIATORS/N M5G447-UP
Group No: 237-0439
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P4278 | 1 CLAMP-HOSE | 2 | |
| 2681497 | 2 ELBOW | 1 | |
| 6S8620 | 3 CLAMP-HOSE | 4 | |
| 8T4983 | 4 CLAMP-HOSE | 2 | |
| 5P1262 | 5 HOSE (16-CM) | ||
| 9R6307 | 6 SPACER (11X28X12-MM THK) | 1 | |
| 9Y9236 | 7 GAUGE-SIGHT | 1 | |
| 1117092 | 8 HOSE | 1 | |
| 1327370 | 9 HOSE | 1 | |
| 1503024 | 10 ELBOW AS | 1 | |
| 5P4924 | ELBOW | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1570670 | 11 CAP-DUST | 1 | |
| 2684045 | 12 CONNECTOR | 2 | |
| 1716061 | 13 ELBOW AS | 1 | |
| 3E4041 | ELBOW | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 1883034 | 14 ELBOW AS | 2 | |
| 6V1355 | ELBOW | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 1925017 | 15 BRACKET AS | 1 | |
| 2179060 | 16 VALVE AS-FLUID SAMPLING | 1 | |
| 1549023 | VALVE-SAMPLING | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 2399884 | 17 TUBE AS | 1 | |
| 2432372 | 18 HOSE | 1 | |
| 2432373 | 19 HOSE | 1 | |
| 2432374 | 20 TUBE AS | 1 | |
| 2604698 | 21 GROMMET | 1 | |
| 3122014 | 22 TANK GP-RADIATOR TOP | 1 | |
| 1333260 | 23 SPACER (11X19X10-MM THK) | 1 | |
| 1M4543 | 24 GROMMET | 1 | |
| 2126934 | 25 CLAMP-T BOLT | 2 | |
| 3243210 | 26 CLAMP | 7 | |
| 4D9517 | 27 CLIP | 2 | |
| 5P9299 | 28 CLIP (LOOP) | 2 | |
| 6P0699 | 29 GROMMET | 1 | |
| 6V2235 | 30 CLIP | 1 | |
| 7D7233 | 31 CLIP (LOOP) | 1 | |
| 7M8485 | 32 SEAL-O-RING | 1 | |
| 7X7729 | 33 WASHER (11X25X3-MM THK) | 2 | |
| 8T4121 | 34 WASHER-HARD (11X21X2.5-MM THK) | 7 | |
| 8T4133 | 35 NUT (M10X1.5-THD) | 1 | |
| 8T4136 | 36 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4186 | 37 BOLT (M10X1.5X40-MM) | 1 | |
| 8T4195 | 38 BOLT (M10X1.5X30-MM) | 3 | |
| 8T4196 | 39 BOLT (M10X1.5X35-MM) | 1 | |
| 8T6466 | 40 BOLT (M10X1.5X60-MM) | 1 | |
| 8M2770 | 41 CLIP (LOOP) | 1 | |
| 0974896 | 42 SPACER (12X20X23-MM THK) | 1 | |
| 5P6442 | 43 HOSE (53-CM) | ||
| 5P6442 | 43A HOSE (65-CM) | ||
| 5P1442 | 44 HOSE (28-CM) | ||
| 5P1251 | 45 HOSE (102-CM) | ||
| 7Y1976 | 46 HOSE-WATER (221-CM) | ||
| 2126933 | 47 CLAMP | 1 | |
| 7X1443 | 48 PROTECTOR | 10 | |
| 3J1907 | 49 SEAL-O-RING | 2 | |
| 6V7383 | 50 CLIP | 1 |
