System And Components
228-0007 PUMP & LINES GPS/N DLS1-303
Group No: 228-0007 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6N3925 | 1 EXTENSION GP-DRAIN | 1 | |
| 1235150 | 2 VALVE-CHECK (ENGINE OIL) | 1 | |
| 1292327 | 3 ELBOW | 1 | |
| 1532995 | 4 COUPLING (MALE) | 1 | |
| 1938335 | 5 FITTING AS (QUICK DISCONNECT, FEMALE) | 1 | |
| 2275525 | 6 PUMP & MOTOR GP-HYDRAULIC (SEC STRG, BRK REL, HS OIL CHG) | 1 | |
| 2302173 | 7 BLOCK | 1 | |
| 2307170 | 8 SCREEN AS (PUMP LINES) | 1 | |
| 2366212 | 9 HOSE AS | 1 | |
| 2534276 | 10 HOSE AS | 1 | |
| 2534277 | 11 HOSE AS | 1 | |
| 1196220 | 12 ELBOW | 1 | |
| 1488390 | 13 ELBOW AS | 1 | |
| 6V8626 | ELBOW | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1504048 | 14 ELBOW AS | 1 | |
| 6V8722 | ELBOW | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1536247 | 15 CONNECTOR AS | 1 | |
| 8C6875 | CONNECTOR | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 1J8668 | 16 STUD-TAPERLOCK (3/8-16X1.97-IN) | 2 | |
| 2M9189 | 17 GASKET | 2 | |
| 2M9780 | 18 SEAL-O-RING | 3 | |
| 3D2824 | 19 SEAL-O-RING | 1 | |
| 4P0519 | 20 ADAPTER AS-DRAIN | 1 | |
| 1095839 | PLUG-DRAIN (ENGINE OIL) | 1 | |
| 1095840 | ADAPTER-PLUG | 1 | |
| 4S1962 | 21 CLIP (LOOP) | 1 | |
| 5K9090 | 22 SEAL-O-RING | 1 | |
| 5P2211 | 23 ADAPTER (1-1/16-12-THD) | 1 | |
| 6V8189 | 24 NUT (5/16-18-THD) | 2 | |
| 6V8801 | 25 NUT (3/8-16-THD) | 4 | |
| 6V8918 | 26 BOLT (5/16-18X1.25-IN) | 2 | |
| 6V9170 | 27 NUT-BULKHEAD (1-14-THD) | 1 | |
| 7J9108 | 28 SEAL-O-RING | 2 | |
| 8M1047 | 29 STUD-TAPERLOCK (3/8-16X1.67-IN) | 2 | |
| 8T4121 | 30 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4136 | 31 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4223 | 32 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4224 | 33 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T4896 | 34 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 8T9391 | 35 BOLT (1/2-13X3.75-IN) | 2 |
