System And Components
308-3182 DIFFERENTIAL & BEVEL GEAR GPS/N KEX1-UP
Group No: 308-3182
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4B8393 | 1 CUP-BEARING | 1 | |
| 5P8081 | 2 BOLT-LOCKING (3/4-16X2-IN) | 36 | |
| 8W3064 | 3 RING-ADJUSTMENT | 2 | |
| 9K4454 | 4 LOCK | 2 | |
| 1077857 | 5 DIFFERENTIAL GP | 1 | |
| 2372895 | 6 RETAINER | 1 | |
| 2374770 | 7 COVER | 1 | |
| 2480833 | 8 PLUG AS-DRAIN (DIFFERENTIAL CASE) | 1 | |
| 3S9233 | SEAL-O-RING | 1 | |
| 5L4759 | SEAL-O-RING | 1 | |
| 2597138 | PLUG | 1 | |
| 2874002 | 9 YOKE | 1 | |
| 3083522 | 10 HOUSING | 1 | |
| 3411542 | 11 HOUSING | 1 | |
| 3411548 | 12 SHIM PACK (INCLUDES 13-SHIMS) | 1 | |
| 3484337 | 13 RETAINER | 1 | |
| 3484649 | 14 SHIM PACK (INCLUDES 13-SHIMS) | 1 | |
| 3474218 | 15 SET-BEVEL GEAR | 1 | |
| 1B4034 | 16 CONE-BEARING | 1 | |
| 1J2860 | 17 CUP-BEARING (TAPERED ROLLER) | 1 | |
| 1J4757 | 18 CONE-BEARING (TAPERED ROLLER) | 1 | |
| 2D9457 | 19 CONE-BEARING (TAPERED ROLLER) | 1 | |
| 2K4472 | 20 SEAL-O-RING | 1 | |
| 2M9780 | 21 SEAL-O-RING | 2 | |
| 3E4356 | 22 WASHER-HARD (17.5X30X6-MM THK) | 16 | |
| 4F2041 | 23 CUP-BEARING (TAPERED ROLLER) | 1 | |
| 5H2824 | 24 SEAL-O-RING | 1 | |
| 5P8245 | 25 WASHER-HARD (13.5X25.5X3-MM THK) | 20 | |
| 5P8248 | 26 WASHER-HARD (20X36.5X3.5-MM THK) | 36 | |
| 6V0414 | 27 CUP-BEARING | 1 | |
| 6V0415 | 28 CONE-BEARING | 1 | |
| 6V3263 | 29 SEAL-O-RING | 1 | |
| 6V3303 | 30 BOLT (M16X2X60-MM) | 16 | |
| 6V3822 | 31 BOLT (M10X1.5X35-MM) | 8 | |
| 6V5050 | 32 SEAL-O-RING | 1 | |
| 6V5839 | 33 WASHER (11X21X2.5-MM THK) | 8 | |
| 6V7673 | 34 BOLT (M12X1.75X50-MM) | 18 | |
| 6V8675 | 35 BOLT (M12X1.75X35-MM) | 2 | |
| 7M8485 | 36 SEAL-O-RING | 2 | |
| 8C3084 | 37 SEAL-LIP TYPE | 1 | |
| 8T0070 | 38 BOLT (M20X2.5X120-MM) | 1 | |
| 9S4181 | 39 PLUG (1-5/16-12-THD) | 1 | |
| 9S4183 | 40 PLUG (1-1/16-12-THD) | 1 | |
| 9S4190 | 41 PLUG-O-RING (7/8-14-THD) | 2 |
