System And Components
399-5955 WHEEL GP-FINAL DRIVE & BRAKES/N KEX1-UP
Group No: 399-5955
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3393284 | 1 NUT-HEX (M33X3.5-THD) | 24 | |
| 4D5642 | 2 SHIM PACK (INCLUDES 14-SHIMS) | 1 | |
| 2088795 | 3 RETAINER | 1 | |
| 2389912 | 4 DRIVE GP-FINAL | 1 | |
| 2408240 | 5 BEARING AS | 2 | |
| 3083195 | 6 WHEEL-REAR | 1 | |
| 4626304 | 7 SEAL GP-DUO-CONE | 1 | |
| 3221942 | 8 WASHER-HARD (34X57X14-MM THK) | 24 | |
| 3472467 | 9 RETAINER-SEAL | 1 | |
| 3473149 | 10 SHIM PACK (INCLUDES 6-SHIMS) | 1 | |
| 3493327 | 11 RING | 1 | |
| 3494657 | 12 COVER | 1 | |
| 3520461 | 13 SPINDLE-REAR | 1 | |
| 5415046 | 14 BRACKET AS | 1 | |
| 3654924 | 24 SEAL GP-DUO-CONE | 1 | |
| 4571024 | 25 RETAINER | 1 | |
| 3869560 | 26 BRAKE GP-SERVICE & PARKING (REAR) | 1 | |
| 2446925 | 27 RING-RETAINING | 1 | |
| 3215144 | 28 BOLT-WHEEL | 24 | |
| 3S3074 | 29 SEAL-O-RING | 1 | |
| 4M0737 | 30 SEAL-O-RING | 1 | |
| 5P8247 | 31 WASHER-HARD (17X32X3.5-MM THK) | 8 | |
| 8T4200 | 32 BOLT (M8X1.25X16-MM) | 2 | |
| 6W4310 | 33 SEAL-O-RING | 1 | |
| 8T0357 | 34 BOLT (M16X2X70-MM) | 8 | |
| 8T4121 | 35 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4137 | 36 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4195 | 37 BOLT (M10X1.5X30-MM) | 8 | |
| 9X2027 | 38 WASHER (11X18X2-MM THK) | 8 | |
| 8T4224 | 40 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 3638811 | SHIM PACK (INCLUDES 6-SHIMS) | 1 |
