System And Components
309-1341 LINES GP-HOISTS/N TNM580-779
Group No: 309-1341
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6G1444 | 1 ADAPTER | 1 | |
| 8X4575 | 2 FILTER AS-BREATHER (HOIST LINES) | 1 | |
| 9M0164 | 3 CLAMP-HOSE | 1 | |
| 1050381 | 4 BLOCK | 1 | |
| 1368424 | 5 HOSE | 1 | |
| 2451668 | 6 VALVE GP-CONTROL (HOIST)(HOIST) | 1 | |
| 2938861 | 7 BOLT (1/2-13X11.5-IN) | 1 | |
| 2939002 | 8 BOLT (1/2-13X11-IN) | 1 | |
| 2945076 | 9 PLATE AS | 1 | |
| 2956087 | 10 HOSE AS | 1 | |
| 3426586 | 11 HOSE AS | 1 | |
| 3426642 | 12 TUBE AS | 1 | |
| 3557329 | 13 TUBE AS | 1 | |
| 3557330 | 14 TUBE AS | 1 | |
| 3588595 | 15 HOSE AS | 1 | |
| 3614975 | 16 HOSE AS | 1 | |
| 3799739 | 17 HOSE AS | 1 | |
| 1333260 | 20 SPACER (11X19X10-MM THK) | 1 | |
| 1645582 | 21 UNION AS | 1 | |
| 6V9810 | UNION | 1 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 1P4579 | 22 FLANGE-HALF | 2 | |
| 1P4585 | 23 FLANGE-HALF | 4 | |
| 2094581 | 24 CLAMP-T BOLT | 4 | |
| 2287092 | 25 SEAL-O-RING | 1 | |
| 2352478 | 26 SEAL-RECTANGULAR | 1 | |
| 2977976 | 27 ELBOW AS | 1 | |
| 6V9850 | ELBOW | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 6V8001 | 28 SEAL-O-RING | 2 | |
| 3196216 | 29 CONNECTOR AS | 1 | |
| 6V8716 | CONNECTOR (STRAIGHT) | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3196220 | 30 ELBOW AS | 1 | |
| 6V9008 | ELBOW (90-DEG) | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3218673 | 31 CONNECTOR AS | 2 | |
| 8T9041 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 3309758 | 32 ELBOW AS | 1 | |
| 8T4149 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3353971 | 33 TEE AS | 1 | |
| 6V9836 | TEE-SWIVEL | 1 | |
| 2287089 | SEAL-O-RING | 2 | |
| 4J0524 | 34 SEAL-O-RING | 2 | |
| 6V1572 | 35 CLIP (SLOT) | 1 | |
| 6V1573 | 36 CLIP (TAB) | 1 | |
| 6V1574 | 37 GROMMET | 1 | |
| 6F8515 | 38 SPACER (0.493X0.675X1.12-IN THK) | 1 | |
| 6V1867 | 39 CLIP (SLOT) | 1 | |
| 6V1868 | 40 CLIP (TAB) | 1 | |
| 6V1869 | 41 GROMMET (65-MM ID) | 1 | |
| 6V1889 | 42 CLIP (LOOP) | 1 | |
| 7D1553 | 44 CLIP | 1 | |
| 7X0328 | 45 BOLT (1/2-13X3.5-IN) | 4 | |
| 7X0481 | 46 BOLT (1/2-13X8-IN) | 1 | |
| 8M2773 | 47 CLIP (LOOP) | 3 | |
| 8T4121 | 49 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4136 | 50 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4186 | 51 BOLT (M10X1.5X40-MM) | 1 | |
| 8T4184 | 52 BOLT (M12X1.75X45-MM) | 4 | |
| 8T4193 | 53 BOLT (M16X2X50-MM) | 8 | |
| 8T4195 | 54 BOLT (M10X1.5X30-MM) | 1 | |
| 8T4196 | 55 BOLT (M10X1.5X35-MM) | 1 | |
| 8T4223 | 56 WASHER-HARD (13.5X25.5X3-MM THK) | 7 | |
| 3445675 | 57 NUT (M10X1.5-THD) | 1 | |
| 8T5005 | 58 BOLT (M10X1.5X70-MM) | 2 | |
| 8T6466 | 59 BOLT (M10X1.5X60-MM) | 1 | |
| 9D6196 | 60 CLIP (SLOT) | 1 | |
| 9D6197 | 61 CLIP (TAB) | 1 | |
| 9V5382 | 62 GROMMET | 1 | |
| 9X8257 | 63 WASHER (17.5X30X3.5-MM THK) | 8 | |
| 5P4295 | 64 CLIP | 2 | |
| 7X7729 | 65 WASHER (11X25X3-MM THK) | 2 | |
| 7X3392 | 66 WASHER-HARD (13.5X22.5X3-MM THK) | 4 |
