System And Components
339-9793 BOX GP-OBJECT DETECTION -RADARPART OF 382-7927 BOX & MTG GP-OBJECT DETECTION, 332-5764, 343-7287, 345-7015, 348-8655, 351-9302, 353-9417 WIRING GP-SENSOR
Group No: 339-9793
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1882712 | 1 VALVE-DRAIN | 1 | |
| 3377188 | 2 PLATE AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 1 | |
| 3377356 | 3 BOX AS | 1 | |
| 5P8247 | WASHER-HARD (17X32X3.5-MM THK) | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 4 | |
| 7T1099 | LINK | 1 | |
| 3377981 | 4 COVER | 1 | |
| 3378183 | 5 BRACKET | 1 | |
| 3383713 | 6 SEAL | 2 | |
| 3399400 | 7 FRAME (OUTER) | 1 | |
| 3399402 | 8 SEAL | 1 | |
| 3399471 | 9 SEAL | 1 | |
| 0950723 | 10 SCREW-SPECIAL (M3X0.5X10-MM) | 2 | |
| 0950756 | 11 SCREW-MACHINE (M5X0.8X16-MM) | 8 | |
| 1629112 | 12 GROMMET-SPLIT | 1 | |
| 3C6969 | 13 NUT (M3X0.5-THD) | 2 | |
| 3L8187 | 14 LOCKWASHER | 4 | |
| 5C9553 | 15 BOLT (M6X1X16-MM) | 5 | |
| 9X8256 | 16 WASHER (6.6X12X2-MM THK) | 5 |
