System And Components
371-4780 LINES GP-STEERINGS/N MJS574-613
Group No: 371-4780
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I0899 | 1 FITTING | 1 | |
| 6V0852 | 2 CAP-DUST | 1 | |
| 7K1181 | 3 STRAP-CABLE | 2 | |
| 5P1293 | 4 HOSE (18.5-CM) | ||
| 1562525 | 5 VALVE-SHUTOFF | 1 | |
| 1600564 | 6 BRACKET AS | 3 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1730159 | 7 FILTER GP-OIL (ULTRA HIGH EFFICIENCY)(STEERING PUMP CASE DRAIN) | 1 | |
| 2006345 | 8 SADDLE-MOUNTING (DUAL SWIVEL) | 1 | |
| 2501424 | 9 ELBOW AS | 3 | |
| 6V8724 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 2609143 | 10 ELBOW AS | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1095824 | ELBOW (SWIVEL) | 1 | |
| 2609220 | 11 ELBOW AS | 1 | |
| 8T7546 | ELBOW | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 2815934 | 12 ELBOW AS | 1 | |
| 6V9877 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 2815977 | 13 CONNECTOR AS | 1 | |
| 6V8642 | CONNECTOR | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 2977999 | 14 ELBOW AS | 2 | |
| 8T2530 | ELBOW | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3195405 | 15 PUMP & MOTOR GP-HYDRAULIC | 1 | |
| 3196220 | 16 ELBOW AS | 1 | |
| 6V9008 | ELBOW (90-DEG) | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3264515 | 17 TIE-CABLE | 5 | |
| 3302159 | 18 PLATE | 3 | |
| 3309754 | 19 CONNECTOR AS | 1 | |
| 8T3611 | CONNECTOR | 1 | |
| 2287094 | SEAL-O-RING | 1 | |
| 2287096 | SEAL-O-RING | 1 | |
| 3329463 | 20 TUBE AS | 1 | |
| 3330133 | 21 BLOCK | 2 | |
| 3340070 | 22 TUBE AS | 1 | |
| 3340078 | 23 BLOCK | 2 | |
| 3346227 | 24 HOSE AS | 1 | |
| 3346229 | 25 HOSE AS | 1 | |
| 3346231 | 26 TUBE AS | 1 | |
| 3346345 | 27 BLOCK | 4 | |
| 3355539 | 28 HOSE AS | 1 | |
| 3376654 | 29 BLOCK | 2 | |
| 3376673 | 30 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 3376677 | 31 PLATE | 2 | |
| 3376684 | 32 TUBE AS | 1 | |
| 3383917 | 33 HOSE & TUBE AS | 1 | |
| 3395645 | 34 PLATE | 4 | |
| 3459929 | 35 HOSE AS | 1 | |
| 3481951 | 36 COVER AS | 1 | |
| 3489023 | 37 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 3493396 | 38 BLOCK | 2 | |
| 3498519 | 39 ELBOW AS | 1 | |
| 6V9003 | ELBOW | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3524202 | 40 STRAP-CABLE | 4 | |
| 3524203 | 41 STRAP-CABLE | 2 | |
| 3524205 | 42 STRAP-CABLE | 4 | |
| 3601794 | 43 HOSE AS | 1 | |
| 3642581 | 44 HOSE & TUBE AS | 1 | |
| 3642583 | 45 HOSE AS | 1 | |
| 3642584 | 46 HOSE AS | 1 | |
| 3642587 | 47 HOSE AS | 1 | |
| 3642588 | 48 HOSE AS | 1 | |
| 3642589 | 49 HOSE AS | 1 | |
| 3642590 | 50 HOSE AS | 1 | |
| 3642591 | 51 TUBE AS | 1 | |
| 3642592 | 52 TUBE AS | 1 | |
| 3642593 | 53 TUBE AS | 1 | |
| 3642597 | 54 BRACKET AS | 3 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 9R9866 | BOSS-THREADED (M10X1.5-THD) | 2 | |
| 3642598 | 55 BLOCK | 6 | |
| 3642612 | 56 TUBE AS | 1 | |
| 3642613 | 57 TUBE AS | 1 | |
| 3642619 | 58 BLOCK | 2 | |
| 3772541 | 59 HOSE AS | 1 | |
| 3968112 | 60 HOSE AS | 1 | |
| 3968113 | 61 TUBE AS | 1 | |
| 4186445 | 62 HOSE AS | 1 | |
| 4186456 | 63 TUBE AS | 1 | |
| 4228957 | 64 MANIFOLD GP-CONTROL (STEERING) | 1 | |
| 4333778 | 65 HOSE AS | 1 | |
| 4333779 | 66 HOSE AS | 1 | |
| 4333780 | 67 HOSE AS | 1 | |
| 4333781 | 68 HOSE AS | 1 | |
| 4362231 | 69 TUBE AS | 1 | |
| 4362232 | 70 TUBE AS | 1 | |
| 4766559 | 71 TUBE AS | 1 | |
| 4766561 | 72 TUBE AS | 1 | |
| 4766594 | 73 BRACKET AS | 1 | |
| 4766593 | BRACKET | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 4851366 | 74 FILTER GP-OIL (WITH MOUNTING) | 1 | |
| 4908140 | 75 HOSE AS | 1 | |
| 5076183 | 76 TUBE AS | 1 | |
| 1065074 | 77 ADAPTER | 1 | |
| 1336934 | 78 SPACER (11X20X25-MM THK) | 2 | |
| 1410721 | 79 PLATE | 1 | |
| 1448344 | 80 SPACER (11X19X20-MM THK) | 1 | |
| 1472286 | 81 SLEEVE | 4 | |
| 1488324 | 82 CONNECTOR AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 6V9874 | CONNECTOR | 1 | |
| 1488357 | 83 ELBOW AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9008 | ELBOW (90-DEG) | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488411 | 84 PLUG AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 9S4185 | PLUG (3/4-16-THD) | 1 | |
| 1536237 | 85 ELBOW AS | 1 | |
| 6V9004 | ELBOW | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1536259 | 86 TEE AS | 1 | |
| 6V8777 | TEE-FACE SEAL | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 1645567 | 87 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1803998 | 88 STUD (M10X1.5X55-MM) | 2 | |
| 1833399 | 89 CONNECTOR AS | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 1984777 | 90 WASHER-HARD (11X25X10-MM THK) | 4 | |
| 1P3703 | 91 SEAL-RECTANGULAR | 1 | |
| 1P4582 | 92 FLANGE-HALF | 2 | |
| 2287089 | 93 SEAL-O-RING | 4 | |
| 2287091 | 94 SEAL-O-RING | 1 | |
| 2287092 | 95 SEAL-O-RING | 8 | |
| 2287093 | 96 SEAL-O-RING | 3 | |
| 2385080 | 97 SEAL-O-RING | 2 | |
| 2788316 | 98 STUD-TAPERLOCK (M10X1.5-6 THD) | 2 | |
| 2815972 | 99 CONNECTOR AS | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 2815975 | 100 ELBOW AS | 2 | |
| 6V8626 | ELBOW | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 2815982 | 101 CONNECTOR AS | 3 | |
| 6V9874 | CONNECTOR | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 2887158 | 102 STUD (M10X1.5X125-MM) | 1 | |
| 2977976 | 103 ELBOW AS | 1 | |
| 6V9850 | ELBOW | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 2M8545 | 104 SPACER (1.56-IN THK) | 1 | |
| 3091905 | 105 STUD-TAPERLOCK (M10X1.5X100-MM) | 3 | |
| 3105903 | 106 TEE AS | 1 | |
| 3105902 | TEE | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 3118803 | 107 SPACER (10.5X19X85.5-MM THK) | 1 | |
| 3159837 | 108 ELBOW AS | 1 | |
| 6V9854 | ELBOW (SWIVEL) | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 3196222 | 109 ELBOW AS | 1 | |
| 6V9200 | ELBOW | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 3232262 | 110 SPACER (11.1X15.9X38.5-MM THK) | 2 | |
| 3264516 | 111 TIE-CABLE | 15 | |
| 3314354 | 112 ROD | 5 | |
| 3328562 | 113 ELBOW AS | 1 | |
| 6V9852 | ELBOW (SWIVEL) | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 3445675 | 114 NUT (M10X1.5-THD) | 16 | |
| 3474447 | 115 TEE AS | 1 | |
| 1263902 | TEE-O-RING | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2287094 | SEAL-O-RING | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3524200 | 116 STRAP-CABLE | 4 | |
| 3526510 | 117 TEE AS | 1 | |
| 6V8792 | TEE-FACE SEAL | 1 | |
| 2287093 | SEAL-O-RING | 3 | |
| 3H3244 | 118 SPACER (12.52X17.14X57-MM THK) | 6 | |
| 3J7354 | 119 SEAL-O-RING | 1 | |
| 4J0520 | 120 SEAL-O-RING | 1 | |
| 4J0527 | 121 SEAL-O-RING | 3 | |
| 4S1962 | 122 CLIP (LOOP) | 2 | |
| 4S4455 | 123 CLIP | 1 | |
| 5K9090 | 124 SEAL-O-RING | 1 | |
| 5P1076 | 125 WASHER-HARD (13.5X30X4-MM THK) | 6 | |
| 5P2369 | 126 CLIP (LOOP) | 3 | |
| 5P7464 | 127 CLIP (SLOT) | 2 | |
| 5P7465 | 128 CLIP (TAB) | 2 | |
| 5P7466 | 129 CLIP (SLOT) | 4 | |
| 5P7467 | 130 CLIP (TAB) | 4 | |
| 5P7468 | 131 CLIP (SLOT) | 1 | |
| 5P7469 | 132 CLIP (TAB) | 1 | |
| 5P8112 | 133 GROMMET | 4 | |
| 5P9297 | 134 CLIP (LOOP) | 1 | |
| 6D4246 | 135 CLIP (LOOP) | 2 | |
| 6V0545 | 136 GROMMET (52-MM OD) | 1 | |
| 6V0871 | 137 GROMMET | 3 | |
| 6V7359 | 138 GROMMET (25-MM ID, 37-MM OD) | 2 | |
| 7D7233 | 139 CLIP (LOOP) | 1 | |
| 7X2551 | 140 BOLT (M12X1.75X200-MM) | 3 | |
| 7X7729 | 141 WASHER (11X25X3-MM THK) | 12 | |
| 8T4121 | 142 WASHER-HARD (11X21X2.5-MM THK) | 38 | |
| 8T4136 | 143 BOLT (M10X1.5X25-MM) | 11 | |
| 8T4137 | 144 BOLT (M10X1.5X20-MM) | 5 | |
| 8T4139 | 145 BOLT (M12X1.75X30-MM) | 6 | |
| 8T4172 | 146 BOLT (M10X1.5X80-MM) | 1 | |
| 8T4178 | 147 BOLT (M10X1.5X90-MM) | 2 | |
| 8T4182 | 148 BOLT (M10X1.5X45-MM) | 1 | |
| 8T4184 | 149 BOLT (M12X1.75X45-MM) | 4 | |
| 8T4185 | 150 BOLT (M10X1.5X50-MM) | 1 | |
| 8T4195 | 151 BOLT (M10X1.5X30-MM) | 8 | |
| 8T4196 | 152 BOLT (M10X1.5X35-MM) | 2 | |
| 8T4200 | 153 BOLT (M8X1.25X16-MM) | 4 | |
| 8T4223 | 154 WASHER-HARD (13.5X25.5X3-MM THK) | 7 | |
| 8T4224 | 155 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T4984 | 156 CLAMP-HOSE | 4 | |
| 8T5005 | 157 BOLT (M10X1.5X70-MM) | 4 | |
| 8T6466 | 158 BOLT (M10X1.5X60-MM) | 1 | |
| 8T6685 | 159 BOLT (M10X1.5X110-MM) | 1 | |
| 8T9101 | 160 BOLT (3/8-16X2.75-IN) | 1 | |
| 9M8406 | 161 CLIP (LOOP) | 1 | |
| 9P2495 | 162 SPACER (12.52X17.14X67-MM THK) | 2 | |
| 9S4185 | 163 PLUG (3/4-16-THD) | 1 | |
| 9X8250 | 164 CLIP (LOOP) | 2 | |
| 3158639 | 165 SLEEVE (54-CM EACH) | ||
| 3158639 | 165A SLEEVE (59-CM EACH) | ||
| 3158639 | 165B SLEEVE (56-CM) |
