System And Components
284-2787 CYLINDER HEAD ASPART OF 284-8892 CYLINDER HEAD GP
Group No: 284-2787
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B0623 | 1 PLUG-CUP (25.73-MM OD) | 36 | |
| 1227375 | 2 GUIDE-VALVE (STANDARD)(STANDARD) | 24 | |
| 1220447 | GUIDE-VALVE (0.51-MM OS) | ||
| 1228612 | GUIDE-VALVE (0.13-MM OS) | ||
| 2165582 | 3 BUSHING (STANDARD)(STANDARD) | 7 | |
| 2170751 | BUSHING (0.25-MM OS) | ||
| 2170752 | BUSHING (0.762-MM OS) | ||
| 2613429 | BUSHING (1.778-MM OS) | ||
| 2613430 | BUSHING (1.27-MM OS) | ||
| 2634920 | 4 SLEEVE-INJECTOR (INLET) | 6 | |
| 2842786 | 5 CYLINDER HEAD AS | 1 | |
| 2243983 | INSERT-SEAT (INLET)(STANDARD) | 12 | |
| 3143063 | INSERT-VALVE SEAT (0.55-MM THK)(INLET) | ||
| 3143064 | INSERT-VALVE SEAT (0.13-MM OS, INLET) | ||
| 3143065 | INSERT-VALVE SEAT (0.13-MM OS)(INLET) | ||
| 3143066 | INSERT-VALVE SEAT (0.26-MM OS, INLET) | ||
| 3143067 | INSERT-VALVE SEAT (0.26-MM OS)(INLET) | ||
| 3143068 | INSERT-VALVE SEAT (0.51-MM OS, INLET) | ||
| 3143069 | INSERT-VALVE SEAT (0.51-MM OS)(INLET) | ||
| 2265561 | INSERT-VALVE SEAT (EXHAUST)(STANDARD) | 12 | |
| 2884883 | INSERT-VALVE SEAT (0.51-MM OS, EXHAUST) | ||
| 2884884 | INSERT-VALVE SEAT (0.76-MM OS, EXHAUST) | ||
| 1662904 | 7 SEAL-O-RING | 12 | |
| 3B0645 | 8 PLUG-CUP (32.08-MM OD) | 2 | |
| 8T6757 | 9 PLUG-PIPE | 3 | |
| 9X7430 | 10 SEAL-O-RING | 6 |
