System And Components
433-3793 LINES GP-STEERINGS/N LTZ146-154
Group No: 433-3793
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3218616 | 1 FITTING AS | 1 | |
| 8X7851 | FITTING-ORIFICE | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 8W5161 | 6 MANIFOLD | 1 | |
| 8X5139 | 7 JUNCTION BLOCK | 2 | |
| 1515933 | 8 VALVE GP-STEERING (CONTROL) | 1 | |
| 1884525 | 9 BLOCK-MANIFOLD | 1 | |
| 1973295 | 10 FLANGE-HALF | 2 | |
| 1976453 | 11 BRACKET AS | 1 | |
| 2161618 | 12 PLATE AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 3 | |
| 1336934 | 13 SPACER (11X20X25-MM THK) | 4 | |
| 5617299 | 14 HOSE AS | 1 | |
| 2859372 | 15 TUBE AS | 1 | |
| 2884351 | 16 VALVE GP-SOLENOID & RELIEF (STEERING) | 1 | |
| 2930054 | 17 TUBE AS | 1 | |
| 2930055 | 18 TUBE AS | 1 | |
| 2956052 | 19 CLAMP | 4 | |
| 2999391 | 20 CLAMP | 2 | |
| 2999392 | 21 PLATE | 1 | |
| 3017415 | 22 PLATE AS | 2 | |
| 1259477 | PLATE | 1 | |
| 3089525 | 23 PLATE | 1 | |
| 3135209 | 24 HOSE AS | 1 | |
| 3135210 | 25 HOSE AS | 1 | |
| 5237897 | 26 HOSE AS | 1 | |
| 5237896 | 27 HOSE AS | 1 | |
| 3337596 | 28 HOSE AS | 1 | |
| 3337597 | 29 TUBE AS | 1 | |
| 3338152 | 30 PLATE AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 1 | |
| 3338374 | 31 PLATE | 1 | |
| 3339997 | 32 HOSE AS | 1 | |
| 3339998 | 33 HOSE AS | 1 | |
| 3340235 | 34 BLOCK | 1 | |
| 3356127 | 35 HOSE AS | 1 | |
| 5228295 | 36 TUBE AS | 1 | |
| 3399708 | 37 FILTER GP-OIL (BRK CLG, FAN, STEERING RETURN) | 1 | |
| 3410125 | 38 CONNECTOR AS | 2 | |
| 8C3323 | CONNECTOR | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 2385086 | SEAL-O-RING | 1 | |
| 3883023 | 39 TUBE AS | 1 | |
| 3434389 | 40 PLATE AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 1 | |
| 3452179 | 41 HOSE AS | 1 | |
| 3452180 | 42 HOSE AS | 1 | |
| 3452181 | 43 HOSE AS | 1 | |
| 3457980 | 44 HOSE AS | 1 | |
| 3457981 | 45 HOSE AS | 1 | |
| 3457982 | 46 HOSE AS | 1 | |
| 4842125 | 47 HOSE AS | 1 | |
| 3883033 | 48 HOSE AS | 1 | |
| 3469567 | 49 PLATE | 2 | |
| 5228296 | 50 TUBE AS | 1 | |
| 5237898 | 51 HOSE AS | 1 | |
| 4433677 | 52 TUBE AS | 1 | |
| 4468371 | 53 MANIFOLD | 1 | |
| 4469263 | 54 ADAPTER | 1 | |
| 1488419 | 55 REDUCER AS | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8935 | REDUCER | 1 | |
| 1644180 | 56 PLUG AS | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 9S4181 | PLUG (1-5/16-12-THD) | 1 | |
| 1645567 | 57 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1647908 | 58 ELBOW AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T7546 | ELBOW | 1 | |
| 1705715 | 59 SEAL-O-RING | 13 | |
| 4883974 | 60 BOLT AS | 2 | |
| 1912962 | 61 SEAL-O-RING | 2 | |
| 1984777 | 62 WASHER-HARD (11X25X10-MM THK) | 1 | |
| 1P4578 | 63 FLANGE-HALF | 2 | |
| 1P4579 | 64 FLANGE-HALF | 2 | |
| 1P4582 | 65 FLANGE-HALF | 12 | |
| 1P5767 | 66 FLANGE-HALF | 2 | |
| 2343544 | 67 SEAL-O-RING | 1 | |
| 2352475 | 69 SEAL-RECTANGULAR | 6 | |
| 2352476 | 70 SEAL-RECTANGULAR | 1 | |
| 2352478 | 71 SEAL-RECTANGULAR | 1 | |
| 2539739 | 72 BOLT-12 POINT HEAD (M12X1.75X35-MM) | 4 | |
| 2815979 | 73 ELBOW AS | 1 | |
| 6V9007 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3196217 | 75 CONNECTOR AS | 2 | |
| 6V8639 | CONNECTOR | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3196218 | 76 ELBOW AS | 1 | |
| 6V9002 | ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3196220 | 77 ELBOW AS | 1 | |
| 6V9008 | ELBOW (90-DEG) | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3196231 | 78 PLUG AS | 1 | |
| 9S4183 | PLUG (1-1/16-12-THD) | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3196233 | 79 TEE AS | 1 | |
| 6V8782 | TEE | 1 | |
| 2287090 | SEAL-O-RING | 2 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3196235 | 80 TEE AS | 1 | |
| 6V9847 | TEE-SWIVEL | 1 | |
| 2287093 | SEAL-O-RING | 2 | |
| 3196242 | 81 ELBOW AS | 1 | |
| 6V9004 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3218637 | 82 ADAPTER AS | 1 | |
| 8V7764 | ADAPTER-O-RING | 1 | |
| 2385086 | SEAL-O-RING | 1 | |
| 3218657 | 83 ELBOW AS | 1 | |
| 6V8076 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3293356 | 84 NUT (M12X1.75-THD) | 3 | |
| 3295471 | 85 TEE AS | 1 | |
| 8T3313 | TEE-O-RING | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 2287088 | SEAL-O-RING | 1 | |
| 3603672 | 86 TEE AS | 1 | |
| 2501457 | TEE | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3672026 | 88 BOLT-SOCKET HEAD (M12X1.75X135-MM) | 4 | |
| 3727169 | 89 SPACER (13X16.5X7-MM THK) | 2 | |
| 3727170 | 90 SPACER (13X16.5X37-MM THK) | 4 | |
| 3E4321 | 91 CLIP (LOOP) | 1 | |
| 5H4020 | 92 COVER | 1 | |
| 5P1076 | 93 WASHER-HARD (13.5X30X4-MM THK) | 1 | |
| 5P7464 | 94 CLIP (SLOT) | 2 | |
| 5P7465 | 95 CLIP (TAB) | 2 | |
| 5P7468 | 96 CLIP (SLOT) | 5 | |
| 5P7469 | 97 CLIP (TAB) | 5 | |
| 5P7470 | 98 CLIP (SLOT) | 5 | |
| 5P7471 | 99 CLIP (TAB) | 5 | |
| 5P7703 | 100 GROMMET (52-MM ID) | 3 | |
| 5P8077 | 101 FLANGE-HALF | 2 | |
| 5P8182 | 102 GROMMET (46-MM ID) | 2 | |
| 5P8444 | 103 GROMMET (37-MM ID) | 4 | |
| 1364992 | 104 SPACER (11X20X40-MM THK) | 1 | |
| 6D4244 | 105 CLIP (LOOP) | 2 | |
| 6D4246 | 106 CLIP (LOOP) | 2 | |
| 6V0852 | 108 CAP-DUST | 1 | |
| 6V1572 | 109 CLIP (SLOT) | 5 | |
| 6V1573 | 110 CLIP (TAB) | 5 | |
| 6V1867 | 111 CLIP (SLOT) | 2 | |
| 6V1868 | 112 CLIP (TAB) | 2 | |
| 6V1869 | 113 GROMMET (65-MM ID) | 2 | |
| 6V1874 | 114 GROMMET (31-MM ID) | 1 | |
| 6V4590 | 115 SEAL-O-RING | 9 | |
| 6V7359 | 116 GROMMET (25-MM ID, 37-MM OD) | 2 | |
| 7X2543 | 118 BOLT (M10X1.5X120-MM) | 4 | |
| 7X2550 | 119 BOLT (M12X1.75X110-MM) | 4 | |
| 4792171 | 120 BOLT AS | 5 | |
| 7X3392 | 121 WASHER-HARD (13.5X22.5X3-MM THK) | 8 | |
| 7X7729 | 122 WASHER (11X25X3-MM THK) | 1 | |
| 8C3206 | 123 FLANGE-HALF | 20 | |
| 8T4121 | 125 WASHER-HARD (11X21X2.5-MM THK) | 56 | |
| 4792172 | 127 BOLT AS | 8 | |
| 8T4139 | 129 BOLT (M12X1.75X30-MM) | 9 | |
| 8T4140 | 130 BOLT (M16X2X60-MM) | 4 | |
| 8T4183 | 131 BOLT (M12X1.75X40-MM) | 2 | |
| 8T4184 | 132 BOLT (M12X1.75X45-MM) | 35 | |
| 8T4185 | 133 BOLT (M10X1.5X50-MM) | 2 | |
| 8T4186 | 134 BOLT (M10X1.5X40-MM) | 9 | |
| 8T4192 | 135 BOLT (M12X1.75X25-MM) | 2 | |
| 8T4194 | 136 BOLT (M12X1.75X50-MM) | 5 | |
| 8T4195 | 137 BOLT (M10X1.5X30-MM) | 1 | |
| 8T4196 | 138 BOLT (M10X1.5X35-MM) | 37 | |
| 8T4198 | 139 BOLT (M10X1.5X100-MM) | 2 | |
| 8T4223 | 140 WASHER-HARD (13.5X25.5X3-MM THK) | 77 | |
| 8T4648 | 141 BOLT (M12X1.75X70-MM) | 10 | |
| 8T4956 | 142 BOLT (M12X1.75X35-MM) | 13 | |
| 8T5001 | 143 BOLT (M12X1.75X130-MM) | 3 | |
| 8T5005 | 144 BOLT (M10X1.5X70-MM) | 7 | |
| 9X2027 | 145 WASHER (11X18X2-MM THK) | 6 | |
| 9X6582 | 146 NUT (13/16-16-THD) | 1 | |
| 9X8257 | 147 WASHER (17.5X30X3.5-MM THK) | 8 | |
| 2062726 | 148 GUARD-HOSE (25-CM) | ||
| 2183258 | 149 GROMMET | 1 | |
| 2167558 | 150 CLIP | 1 | |
| 2167557 | 151 CLIP | 1 | |
| 1943450 | 152 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 6V1875 | 153 GROMMET | 5 | |
| 7X2555 | 154 BOLT (M16X2X80-MM) | 2 | |
| 3196212 | 155 CONNECTOR AS | 1 | |
| 6V8714 | CONNECTOR | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 1358575 | 156 BOLT AS | 2 | |
| 1187313 | 157 BOLT (M16X2X70-MM) | 2 | |
| 8T4172 | 158 BOLT (M10X1.5X80-MM) | 2 | |
| 1V6274 | 159 TAG-IDENTIFICATION (LETTER R) | 2 | |
| 1V6276 | 160 TAG-IDENTIFICATION (LETTER L) | 2 | |
| 1V6277 | 161 TAG-IDENTIFICATION (LETTER T) | 2 | |
| 4J6311 | 162 TAG-IDENTIFICATION (NUMBER ELEVEN) | 2 | |
| 8R4853 | 163 TAG-IDENTIFICATION (LETTER P) | 2 |
