System And Components
466-2866 LINES GP-STEERINGS/N LTZ1-162
Group No: 466-2866
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2167557 | 1 CLIP | 1 | |
| 1V6274 | 2 TAG-IDENTIFICATION (LETTER R) | 2 | |
| 1V6276 | 3 TAG-IDENTIFICATION (LETTER L) | 2 | |
| 1V6277 | 4 TAG-IDENTIFICATION (LETTER T) | 2 | |
| 4J6311 | 5 TAG-IDENTIFICATION (NUMBER ELEVEN) | 2 | |
| 8R4853 | 6 TAG-IDENTIFICATION (LETTER P) | 2 | |
| 8W5161 | 7 MANIFOLD | 1 | |
| 8X5139 | 8 JUNCTION BLOCK | 2 | |
| 9T1013 | 9 VALVE AS-CHECK | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1095811 | 10 TEE-O-RING PORT | 1 | |
| 1268306 | 11 TEE | 2 | |
| 1884525 | 12 BLOCK-MANIFOLD | 1 | |
| 1943450 | 13 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1973295 | 14 FLANGE-HALF | 2 | |
| 1976453 | 15 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 2161618 | 16 PLATE AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 3 | |
| 2167558 | 17 CLIP | 1 | |
| 2609219 | 18 CONNECTOR AS | 7 | |
| 6V8638 | CONNECTOR | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 2884351 | 19 VALVE GP-SOLENOID & RELIEF (STEERING) | 1 | |
| 2930054 | 20 TUBE AS | 1 | |
| 2930055 | 21 TUBE AS | 1 | |
| 2956052 | 22 CLAMP | 4 | |
| 2999391 | 23 CLAMP | 2 | |
| 2999392 | 24 PLATE | 1 | |
| 3017415 | 25 PLATE AS | 2 | |
| 1259477 | PLATE | 1 | |
| 3089525 | 26 PLATE | 1 | |
| 3135209 | 27 HOSE AS | 1 | |
| 3135210 | 28 HOSE AS | 1 | |
| 3196212 | 29 CONNECTOR AS | 1 | |
| 6V8714 | CONNECTOR | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3196217 | 30 CONNECTOR AS | 2 | |
| 6V8639 | CONNECTOR | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3196220 | 31 ELBOW AS | 1 | |
| 6V9008 | ELBOW (90-DEG) | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3196226 | 32 ELBOW AS | 2 | |
| 8T6876 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 3196228 | 33 ELBOW AS | 4 | |
| 6V8721 | ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3196235 | 34 TEE AS | 1 | |
| 6V9847 | TEE-SWIVEL | 1 | |
| 2287093 | SEAL-O-RING | 2 | |
| 3196242 | 35 ELBOW AS | 1 | |
| 6V9004 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3218616 | 36 FITTING AS | 1 | |
| 8X7851 | FITTING-ORIFICE | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3218657 | 37 ELBOW AS | 1 | |
| 6V8076 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3337596 | 38 HOSE AS | 1 | |
| 3337597 | 39 TUBE AS | 1 | |
| 3338152 | 40 PLATE AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 1 | |
| 3338374 | 41 PLATE | 1 | |
| 3339997 | 42 HOSE AS | 1 | |
| 3339998 | 43 HOSE AS | 1 | |
| 3340161 | 44 MANIFOLD & VALVE GP (PILOT OIL) | 1 | |
| 3340235 | 45 BLOCK | 1 | |
| 3397793 | 46 MANIFOLD GP-CONTROL (STEERING) | 1 | |
| 2516159 | VALVE GP-SHUTTLE | 1 | |
| 2776343 | VALVE GP-SOLENOID (24-VOLT)(STEERING) | 2 | |
| 2540072 | COIL AS (24-VOLT) | 1 | |
| 2855622 | KIT-SEAL (SOLENOID VALVE) | 1 | |
| 3399708 | 47 FILTER GP-OIL (BRAKE COOLING, FAN, STEERING RETURN) | 1 | |
| 3410123 | 48 TEE AS | 2 | |
| 9X2492 | TEE | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3410125 | 49 CONNECTOR AS | 2 | |
| 8C3323 | CONNECTOR | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 2385086 | SEAL-O-RING | 1 | |
| 3419393 | 50 VALVE GP-DIVERTER (STEERING) | 1 | |
| 6V8653 | BOLT-SOCKET HEAD (M6X1X40-MM) | 2 | |
| 4612544 | SENSOR AS (SPOOL) | 1 | |
| 3434389 | 51 PLATE AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 1 | |
| 3452179 | 52 HOSE AS | 1 | |
| 3452180 | 53 HOSE AS | 1 | |
| 3452181 | 54 HOSE AS | 1 | |
| 3469567 | 55 PLATE | 2 | |
| 3495283 | 56 PLATE-ADAPTER | 3 | |
| 3526498 | 57 TEE AS | 1 | |
| 8T8902 | ADAPTER-TEE | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 3526499 | 58 TEE AS | 1 | |
| 1266872 | TEE | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 3534993 | 59 ADAPTER | 1 | |
| 3574605 | 60 ADAPTER AS | 1 | |
| 8T0151 | ADAPTER | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3601414 | 61 MANIFOLD | 1 | |
| 3603672 | 62 TEE AS | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 2501457 | TEE | 1 | |
| 3622944 | 63 HOSE AS | 1 | |
| 3706297 | 64 CONNECTOR AS | 3 | |
| 6V8715 | CONNECTOR | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3883023 | 65 TUBE AS | 1 | |
| 3883033 | 66 HOSE AS | 1 | |
| 3960396 | 67 PLUG AS | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3603697 | PLUG | 1 | |
| 4178855 | 68 HOSE AS | 1 | |
| 4193196 | 69 HOSE AS | 1 | |
| 4204853 | 70 HOSE AS | 1 | |
| 4392403 | 71 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 5 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 2 | |
| 2944550 | BOSS-WELD (M10X1.5X60-MM) | 2 | |
| 4394525 | 72 PLATE | 1 | |
| 4429910 | 73 PLATE AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 2 | |
| 9R2613 | BOSS-WELD (M10X1.5X25-MM) | 1 | |
| 4433677 | 74 TUBE AS | 1 | |
| 4452572 | 75 TUBE AS | 1 | |
| 4452573 | 76 TUBE AS | 1 | |
| 4452574 | 77 TUBE AS | 1 | |
| 4452575 | 78 TUBE AS | 1 | |
| 4468371 | 79 MANIFOLD | 1 | |
| 4469263 | 80 ADAPTER | 1 | |
| 4858867 | 81 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 4883974 | 82 BOLT AS | 2 | |
| 5228295 | 83 TUBE AS | 1 | |
| 5228296 | 84 TUBE AS | 1 | |
| 5237897 | 85 HOSE AS | 1 | |
| 5334159 | 86 BOLT AS | 41 | |
| 1106349 | 87 FITTING AS (QUICK DISCONNECT) | 2 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 1187313 | 88 BOLT (M16X2X70-MM) | 2 | |
| 1261814 | 89 FILTER-OIL (ULTRA HIGH EFFICIENCY) | 2 | |
| 1336934 | 90 SPACER (11X20X25-MM THK) | 4 | |
| 1358575 | 91 BOLT AS | 8 | |
| 1515933 | 92 VALVE GP-STEERING (CONTROL) | 1 | |
| 1645567 | 93 COUPLER AS-QUICK DISCONNECT (MALE) | 8 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1705715 | 94 SEAL-O-RING | 17 | |
| 1833399 | 95 CONNECTOR AS | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 1912962 | 96 SEAL-O-RING | 1 | |
| 1932120 | 97 GROMMET | 1 | |
| 1984777 | 98 WASHER-HARD (11X25X10-MM THK) | 3 | |
| 1984778 | 99 WASHER-HARD (13.5X30X12-MM THK) | 5 | |
| 1P4578 | 100 FLANGE-HALF | 2 | |
| 1P4579 | 101 FLANGE-HALF | 2 | |
| 1P4582 | 102 FLANGE-HALF | 12 | |
| 1P5767 | 103 FLANGE-HALF | 2 | |
| 2183258 | 104 GROMMET | 1 | |
| 2233490 | 105 CLIP | 1 | |
| 2287090 | 106 SEAL-O-RING | 3 | |
| 2287091 | 107 SEAL-O-RING | 4 | |
| 2343544 | 108 SEAL-O-RING | 1 | |
| 2352475 | 109 SEAL-RECTANGULAR | 6 | |
| 2352476 | 110 SEAL-RECTANGULAR | 1 | |
| 2352478 | 111 SEAL-RECTANGULAR | 1 | |
| 2385080 | 112 SEAL-O-RING | 3 | |
| 2539739 | 113 BOLT-12 POINT HEAD (M12X1.75X35-MM) | 4 | |
| 2815979 | 114 ELBOW AS | 1 | |
| 6V9007 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 2884402 | 115 STUD-TAPERLOCK (M10X1.5X60-MM) | 1 | |
| 2977976 | 116 ELBOW AS | 1 | |
| 6V9850 | ELBOW | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 3101945 | 117 STUD-TAPERLOCK (M12X1.75X70-MM) | 2 | |
| 3196221 | 118 ELBOW AS | 1 | |
| 6V9182 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3196222 | 119 ELBOW AS | 1 | |
| 6V9200 | ELBOW | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 3196225 | 120 ELBOW AS | 3 | |
| 6V8625 | ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3196231 | 121 PLUG AS | 1 | |
| 9S4183 | PLUG (1-1/16-12-THD) | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3196233 | 122 TEE AS | 4 | |
| 6V8782 | TEE | 1 | |
| 2287090 | SEAL-O-RING | 2 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3196240 | 123 CONNECTOR AS | 2 | |
| 6V9873 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 3218637 | 124 ADAPTER AS | 1 | |
| 8V7764 | ADAPTER-O-RING | 1 | |
| 2385086 | SEAL-O-RING | 1 | |
| 3293356 | 125 NUT (M12X1.75-THD) | 7 | |
| 3295470 | 126 TEE AS | 1 | |
| 6V9840 | TEE-SWIVEL | 1 | |
| 2287093 | SEAL-O-RING | 2 | |
| 3295518 | 127 ADAPTER AS | 1 | |
| 8T2353 | ADAPTER | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3309720 | 128 REDUCER AS | 1 | |
| 6V8944 | REDUCER | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 3309721 | 129 ADAPTER AS | 1 | |
| 6V8936 | REDUCER | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 3309772 | 130 ELBOW AS | 2 | |
| 6V8624 | ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3328542 | 131 TEE AS | 1 | |
| 6V9844 | TEE-SWIVEL | 1 | |
| 2287090 | SEAL-O-RING | 2 | |
| 3328543 | 132 TEE AS | 1 | |
| 7X0871 | TEE | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 3368613 | 133 CLIP (LOOP) | 1 | |
| 3445675 | 134 NUT (M10X1.5-THD) | 8 | |
| 3672026 | 135 BOLT-SOCKET HEAD (M12X1.75X135-MM) | 4 | |
| 3727169 | 136 SPACER (13X16.5X7-MM THK) | 2 | |
| 3727170 | 137 SPACER (13X16.5X37-MM THK) | 4 | |
| 3E4321 | 138 CLIP (LOOP) | 1 | |
| 4662840 | 139 HOSE AS | 1 | |
| 4662842 | 140 HOSE AS | 1 | |
| 4662850 | 141 HOSE AS | 1 | |
| 4662851 | 142 HOSE AS | 1 | |
| 4662857 | 143 HOSE AS | 1 | |
| 4792171 | 144 BOLT AS | 12 | |
| 4792172 | 145 BOLT AS | 17 | |
| 4842727 | 146 HOSE AS | 1 | |
| 5218491 | 147 VALVE GP-STEERING | 1 | |
| 5237896 | 148 HOSE AS | 1 | |
| 5237898 | 149 HOSE AS | 1 | |
| 5287410 | 150 HOSE AS | 1 | |
| 5287411 | 151 HOSE AS | 1 | |
| 5617299 | 152 HOSE AS | 1 | |
| 5662621 | 153 TUBE AS | 1 | |
| 5758401 | 154 HOSE AS | 1 | |
| 5801049 | 155 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 5801052 | 156 HOSE AS | 1 | |
| 5801053 | 157 HOSE AS | 1 | |
| 5801054 | 158 HOSE AS | 1 | |
| 5801055 | 159 HOSE AS | 1 | |
| 5801056 | 160 HOSE AS | 1 | |
| 5801057 | 161 HOSE AS | 1 | |
| 5801058 | 162 HOSE AS | 1 | |
| 5801059 | 163 TUBE AS | 1 | |
| 5H4020 | 164 COVER | 1 | |
| 5P1076 | 165 WASHER-HARD (13.5X30X4-MM THK) | 1 | |
| 5P4116 | 166 WASHER-HARD (8.8X20.5X2-MM THK) | 4 | |
| 5P7464 | 167 CLIP (SLOT) | 9 | |
| 5P7465 | 168 CLIP (TAB) | 9 | |
| 5P7468 | 169 CLIP (SLOT) | 9 | |
| 5P7469 | 170 CLIP (TAB) | 9 | |
| 5P7470 | 171 CLIP (SLOT) | 5 | |
| 5P7471 | 172 CLIP (TAB) | 5 | |
| 5P8077 | 173 FLANGE-HALF | 2 | |
| 5P8182 | 174 GROMMET (46-MM ID) | 5 | |
| 5P8444 | 175 GROMMET (37-MM ID) | 8 | |
| 5T6374 | 176 SPACER (11X20X40-MM THK) | 1 | |
| 6D4244 | 177 CLIP (LOOP) | 2 | |
| 6D4246 | 178 CLIP (LOOP) | 3 | |
| 6D4636 | 179 CLIP (LOOP) | 1 | |
| 6V0852 | 180 CAP-DUST | 10 | |
| 6V1249 | 181 GROMMET (22-MM ID) | 6 | |
| 6V1572 | 182 CLIP (SLOT) | 5 | |
| 6V1573 | 183 CLIP (TAB) | 5 | |
| 6V1867 | 184 CLIP (SLOT) | 3 | |
| 6V1868 | 185 CLIP (TAB) | 3 | |
| 6V1869 | 186 GROMMET (65-MM ID) | 2 | |
| 6V1874 | 187 GROMMET (31-MM ID) | 1 | |
| 6V1875 | 188 GROMMET | 5 | |
| 6V4590 | 189 SEAL-O-RING | 9 | |
| 6V7359 | 190 GROMMET (25-MM ID, 37-MM OD) | 3 | |
| 6V8555 | 191 NUT-FACE SEAL (1-14-THD) | 1 | |
| 6V8557 | 192 NUT-FACE SEAL (1-7/16-12-THD) | 1 | |
| 6V8939 | 193 REDUCER-O-RING | 1 | |
| 6V9838 | 194 TEE-SWIVEL | 1 | |
| 7X2543 | 195 BOLT (M10X1.5X120-MM) | 4 | |
| 7X2550 | 196 BOLT (M12X1.75X110-MM) | 4 | |
| 7X2555 | 197 BOLT (M16X2X80-MM) | 2 | |
| 7X3392 | 198 WASHER-HARD (13.5X22.5X3-MM THK) | 8 | |
| 7X7729 | 199 WASHER (11X25X3-MM THK) | 1 | |
| 8C3206 | 200 FLANGE-HALF | 20 | |
| 8T4121 | 201 WASHER-HARD (11X21X2.5-MM THK) | 50 | |
| 8T4137 | 202 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4139 | 203 BOLT (M12X1.75X30-MM) | 7 | |
| 8T4140 | 204 BOLT (M16X2X60-MM) | 4 | |
| 8T4179 | 205 BOLT (M12X1.75X20-MM) | 1 | |
| 8T4182 | 206 BOLT (M10X1.5X45-MM) | 8 | |
| 8T4183 | 207 BOLT (M12X1.75X40-MM) | 9 | |
| 8T4184 | 208 BOLT (M12X1.75X45-MM) | 33 | |
| 8T4185 | 209 BOLT (M10X1.5X50-MM) | 4 | |
| 8T4186 | 210 BOLT (M10X1.5X40-MM) | 12 | |
| 8T4189 | 211 BOLT (M8X1.25X20-MM) | 4 | |
| 8T4192 | 212 BOLT (M12X1.75X25-MM) | 2 | |
| 8T4194 | 213 BOLT (M12X1.75X50-MM) | 7 | |
| 8T4196 | 214 BOLT (M10X1.5X35-MM) | 3 | |
| 8T4198 | 215 BOLT (M10X1.5X100-MM) | 3 | |
| 8T4223 | 216 WASHER-HARD (13.5X25.5X3-MM THK) | 80 | |
| 8T4648 | 217 BOLT (M12X1.75X70-MM) | 10 | |
| 8T4956 | 218 BOLT (M12X1.75X35-MM) | 11 | |
| 8T5001 | 219 BOLT (M12X1.75X130-MM) | 3 | |
| 8T5005 | 220 BOLT (M10X1.5X70-MM) | 9 | |
| 8T5436 | 221 BOLT (M10X1.5X130-MM) | 3 | |
| 8T6466 | 222 BOLT (M10X1.5X60-MM) | 4 | |
| 8T6685 | 223 BOLT (M10X1.5X110-MM) | 1 | |
| 9X2027 | 224 WASHER (11X18X2-MM THK) | 6 | |
| 9X8250 | 225 CLIP (LOOP) | 12 | |
| 9X8257 | 226 WASHER (17.5X30X3.5-MM THK) | 8 | |
| 2062727 | 227 GUARD-HOSE (26-CM) |
