System And Components
556-4152 LINES GP-PUMPS/N RJZ1-UP
Group No: 556-4152
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9X9365 | 1 BRACKET (LAMP) | 1 | |
| 1274667 | 2 STRIP AS | 1 | |
| 1488390 | 3 ELBOW AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8626 | ELBOW | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 5P1291 | 4 HOSE (12-CM EACH) | ||
| 3264515 | 5 TIE-CABLE | 6 | |
| 3481768 | 6 HOSE AS | 1 | |
| 3498519 | 7 ELBOW AS | 1 | |
| 6V9003 | ELBOW | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3626553 | 8 HOSE AS | 1 | |
| 3628277 | 9 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 3629774 | 10 HOSE AS | 1 | |
| 3631625 | 11 HOSE AS | 1 | |
| 3632264 | 12 HOSE AS | 1 | |
| 3782489 | 13 HOSE AS | 1 | |
| 4165591 | 14 HOSE AS | 1 | |
| 4387266 | 15 BRACKET | 1 | |
| 1004336 | 16 CLIP (LOOP) | 2 | |
| 1488455 | 17 UNION AS | 1 | |
| 6V8997 | UNION | 1 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 1647908 | 18 ELBOW AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T7546 | ELBOW | 1 | |
| 1803998 | 19 STUD (M10X1.5X55-MM) | 3 | |
| 1P3705 | 20 SEAL-RECTANGULAR | 1 | |
| 1P4579 | 21 FLANGE-HALF | 2 | |
| 1P4582 | 22 FLANGE-HALF | 4 | |
| 1S0994 | 23 CLIP (LOOP) | 3 | |
| 2431353 | 24 SPACER (11X20X35-MM THK) | 1 | |
| 2681605 | 25 ELBOW AS | 1 | |
| 8T1686 | ADAPTER-ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 2815975 | 26 ELBOW AS | 1 | |
| 6V8626 | ELBOW | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 2H3924 | 27 LOCKWASHER | 2 | |
| 2H3926 | 28 LOCKWASHER | 2 | |
| 2P1293 | 29 LOCKNUT (1-3/16-12-THD) | 1 | |
| 3023908 | 30 SPACER (11X20X30-MM THK) | 1 | |
| 3295526 | 31 UNION AS | 1 | |
| 6V8996 | UNION | 1 | |
| 2287091 | SEAL-O-RING | 2 | |
| 3445675 | 32 NUT (M10X1.5-THD) | 5 | |
| 3626439 | 33 HOSE AS | 1 | |
| 4174312 | 34 HOSE AS | 1 | |
| 4J0520 | 35 SEAL-O-RING | 4 | |
| 4J0524 | 36 SEAL-O-RING | 3 | |
| 4J0527 | 37 SEAL-O-RING | 2 | |
| 5572157 | 38 TUBE AS | 1 | |
| 5572158 | 39 TUBE AS | 1 | |
| 5572159 | 40 TUBE AS | 1 | |
| 5572160 | 41 HOSE AS | 1 | |
| 5572161 | 42 HOSE & TUBE AS | 1 | |
| 5582567 | 43 TUBE AS | 1 | |
| 5P7468 | 44 CLIP (SLOT) | 6 | |
| 5P7469 | 45 CLIP (TAB) | 6 | |
| 5P8444 | 46 GROMMET (37-MM ID) | 6 | |
| 6D4247 | 47 CLIP | 1 | |
| 6V0423 | 48 PLUG | 1 | |
| 6V9170 | 49 NUT-BULKHEAD (1-14-THD) | 1 | |
| 7J9108 | 50 SEAL-O-RING | 1 | |
| 7S8920 | 51 CLIP (SLOT) | 1 | |
| 7S8921 | 52 CLIP (TAB) | 1 | |
| 8C3206 | 53 FLANGE-HALF | 2 | |
| 8M2773 | 54 CLIP (LOOP) | 1 | |
| 8T4121 | 55 WASHER-HARD (11X21X2.5-MM THK) | 18 | |
| 8T4136 | 56 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4137 | 57 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4182 | 58 BOLT (M10X1.5X45-MM) | 1 | |
| 8T4183 | 59 BOLT (M12X1.75X40-MM) | 4 | |
| 8T4184 | 60 BOLT (M12X1.75X45-MM) | 4 | |
| 8T4195 | 61 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4196 | 62 BOLT (M10X1.5X35-MM) | 5 | |
| 8T4223 | 63 WASHER-HARD (13.5X25.5X3-MM THK) | 16 | |
| 8T4956 | 64 BOLT (M12X1.75X35-MM) | 4 | |
| 8T6703 | 65 CLAMP-HOSE | 4 | |
| 8T6868 | 66 BOLT (M12X1.75X80-MM) | 4 | |
| 9R1004 | 67 CLIP (TAB) | 1 | |
| 9R1005 | 68 CLIP (SLOT) | 1 | |
| 9X8250 | 69 CLIP (LOOP) | 2 | |
| 3158639 | 70 SLEEVE (98.5-CM) | ||
| 3158639 | 70A SLEEVE (65-CM) |
