System And Components
354-6714 MOUNTING GP-RADIATORS/N NGH1-UP
Group No: 354-6714
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8D3786 | 1 MOUNTING | 2 | |
| 3896769 | 2 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 4 | |
| 3546695 | 3 BRACE | 1 | |
| 3546696 | 4 BRACE | 1 | |
| 3546715 | 5 BRACKET AS | 1 | |
| 3546716 | 6 BRACKET AS | 1 | |
| 3413119 | 7 WASHER-HARD (13X48X3.5-MM THK) | 4 | |
| 4W3753 | 8 SPACER (13.5X25X38.1-MM THK) | 2 | |
| 5P1076 | 9 WASHER-HARD (13.5X30X4-MM THK) | 4 | |
| 8T6868 | 10 BOLT (M12X1.75X80-MM) | 4 | |
| 7T8332 | 11 MOUNTING | 4 | |
| 7X0618 | 13 WASHER-HARD (13.5X40X5-MM THK) | 8 | |
| 7X2575 | 14 BOLT (M24X3X60-MM) | 8 | |
| 8T4001 | 15 NUT (M24X3-THD) | 8 | |
| 8T4139 | 16 BOLT (M12X1.75X30-MM) | 2 | |
| 8T4167 | 17 WASHER-HARD (26X44X4-MM THK) | 16 | |
| 8T4223 | 18 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4244 | 19 NUT (M12X1.75-THD) | 6 | |
| 8T4648 | 20 BOLT (M12X1.75X70-MM) | 4 | |
| 8T4895 | 21 WASHER (13.5X50X5-MM THK) | 4 |
