529-8741 MOUNTING GP-RADIATORS/N NGH1-UP

Group No: 529-8741
Part NumberPart NameQty
52322071 BRACE1
52322082 BRACE1
52321953 SUPPORT AS-RADIATOR1
52321964 SUPPORT AS-RADIATOR1
38967695 BRACKET AS1
34131196 WASHER-HARD (13X48X3.5-MM THK)4
4W37537 SPACER (13.5X25X38.1-MM THK)2
5P10768 WASHER-HARD (13.5X30X4-MM THK)4
7T83329 MOUNTING4
7X061810 WASHER-HARD (13.5X40X5-MM THK)8
7X257511 BOLT (M24X3X60-MM)8
8D378612 MOUNTING2
8T400113 NUT (M24X3-THD)8
8T413914 BOLT (M12X1.75X30-MM)2
8T416715 WASHER-HARD (26X44X4-MM THK)16
8T422316 WASHER-HARD (13.5X25.5X3-MM THK)4
8T424417 NUT (M12X1.75-THD)8
8T464818 BOLT (M12X1.75X70-MM)4
8T489519 WASHER (13.5X50X5-MM THK)4
8T686820 BOLT (M12X1.75X80-MM)4
523219721 PLATE1
208931022 BOLT-FLANGE HEAD (M12X1.75X30-MM)2
