System And Components
304-9055 PLANETARY GP-TRANSMISSIONS/N GFY300-UP
Group No: 304-9055
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3P1910 | 1 RACE-BEARING OUTER | 1 | |
| 3S2708 | 2 PIN-SPRING | 14 | |
| 4D7889 | 3 RING | 1 | |
| 3468576 | 4 SEAL-O-RING | 1 | |
| 5M6126 | 5 BEARING AS-ROLLER | 4 | |
| 5Y1138 | 6 RING-RETAINING | 1 | |
| 8P4922 | 7 RING-SEAL | 2 | |
| 7G4822 | 8 RING-SEAL | 4 | |
| 7T5601 | 9 PLATE | 1 | |
| 8E8300 | 10 DISC-THRUST | 12 | |
| 8E8304 | 11 DISC-THRUST | 8 | |
| 8E8306 | 12 DISC-THRUST | 8 | |
| 8E8313 | 13 DISC-THRUST | 1 | |
| 8S3370 | 14 RING-SEAL | 1 | |
| 8T1178 | 15 BEARING-ROLLER | 2 | |
| 8T4223 | 16 WASHER-HARD (13.5X25.5X3-MM THK) | 20 | |
| 9F8477 | 17 RING-METAL SEAL | 1 | |
| 9S6929 | 18 SEAL-O-RING | 1 | |
| 3503698 | 19 SEAL-RING | 1 | |
| 1348361 | 20 PLATE-CLUTCH | 5 | |
| 5741271 | 21 BEARING-NEEDLE | 4 | |
| 1409842 | 22 RING-LOCK | 2 | |
| 1409843 | 23 DISC-THRUST | 1 | |
| 3468577 | 24 SEAL-O-RING | 2 | |
| 1775241 | 25 RING-RETAINING | 1 | |
| 1775246 | 26 RING-SPACER | 1 | |
| 1776797 | 27 RING-SEAL | 1 | |
| 1892089 | 28 RING-LOCK | 1 | |
| 2225203 | 29 DISC-FRICTION | 18 | |
| 2237519 | 30 DISC-FRICTION | 5 | |
| 4591195 | 31 BEARING-THRUST | 2 | |
| 2770392 | 32 PLATE-CLUTCH | 1 | |
| 2614724 | 33 SHAFT AS | 1 | |
| 9W0717 | PLUG | 3 | |
| 5226379 | 34 HUB AS | 1 | |
| 9W0717 | PLUG | 6 | |
| 3848632 | 35 GEAR-RING (69/68-TEETH) | 1 | |
| 3696958 | 36 HUB-CLUTCH | 1 | |
| 4167051 | 37 GEAR-RING (68-TEETH) | 1 | |
| 4173707 | 38 CARRIER-PLANETARY | 1 | |
| 2632846 | 39 CARRIER-BEARING | 1 | |
| 2632847 | 40 MANIFOLD AS | 1 | |
| 1833407 | PLUG AS | 2 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2770439 | INSERT-THREADED | 6 | |
| 2644794 | 41 SPRING-WAVE | 1 | |
| 3503699 | 42 SPRING | 1 | |
| 2644798 | 43 PISTON | 1 | |
| 3503697 | 44 PISTON | 1 | |
| 2644804 | 45 PLATE-CLUTCH | 3 | |
| 2644805 | 46 PLATE-CLUTCH | 12 | |
| 3499157 | 47 HUB | 1 | |
| 2647793 | 48 BEARING-NEEDLE | 1 | |
| 2647794 | 49 BEARING-THRUST | 2 | |
| 3508540 | 50 SPRING-WAVE | 1 | |
| 3499156 | 51 HOUSING-SEAL | 1 | |
| 2657028 | 52 PLATE-CLUTCH | 1 | |
| 2657969 | 53 CONE-TAPERED | 1 | |
| 2657970 | 54 CUP-TAPERED ROLLER | 1 | |
| 2663670 | 55 RING-SEAL | 2 | |
| 2663671 | 56 RING-SEAL | 2 | |
| 2663673 | 57 RING-SEAL | 1 | |
| 2663675 | 58 RING-SEAL | 1 | |
| 2664193 | 59 RING-SEAL | 1 | |
| 2667072 | 60 SHAFT AS-PLANETARY | 6 | |
| 2A3746 | PLUG-CUP | 1 | |
| 2667073 | 61 SHAFT AS-PLANETARY | 4 | |
| 0T0200 | PLUG-CUP | 1 | |
| 3861404 | 62 SHAFT AS (PLANETARY) | 4 | |
| 0T0200 | PLUG-CUP | 1 | |
| 2696932 | 63 BEARING-THRUST | 2 | |
| 2723616 | 64 GASKET | 1 | |
| 2735098 | 65 COUPLING | 1 | |
| 2746110 | 66 BEARING-INNER (RACE) | 1 | |
| 3577145 | 67 CARRIER AS | 1 | |
| 2773456 | 67A BUSHING | 1 | |
| 2836363 | 68 PLATE-CLUTCH | 4 | |
| 2846012 | 69 PIN | 8 | |
| 2846013 | 70 PIN | 4 | |
| 3503700 | 71 PISTON | 1 | |
| 2947962 | 72 GEAR-SUN (27-TEETH) | 1 | |
| 2947963 | 73 GEAR-PLANETARY (18-TEETH) | 6 | |
| 2947964 | 74 GEAR-SUN (24-TEETH) | 1 | |
| 2947965 | 75 GEAR-PLANETARY (22-TEETH) | 4 | |
| 3953117 | 76 SHAFT-CENTER | 1 | |
| 3953118 | 77 GEAR-PLANETARY (24-TEETH) | 4 | |
| 3049057 | 78 HOUSING | 1 | |
| 3049058 | 79 SHAFT | 1 | |
| 4316872 | 80 CARRIER-PLANETARY | 1 | |
| 3072673 | 81 PLUG AS | 6 | |
| 9S8005 | PLUG (3/4-16-THD) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3933559 | 82 CASE GP-TRANSMISSION | 1 | |
| 3234655 | 83 BEARING-RACE & ROLLER (INNER) | 1 | |
| 3521944 | 85 GASKET | 1 | |
| 3409914 | 86 SPRING | 8 | |
| 3409915 | 87 SPRING | 4 | |
| 3412132 | 88 PISTON | 2 | |
| 3412134 | 89 PISTON | 1 | |
| 3072671 | 90 PLUG AS | 2 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 1K6984 | 91 RING-RETAINING | 1 | |
| 2M0849 | 92 WASHER-HARD (13.5X25.5X5-MM THK) | 8 | |
| 2S0669 | 93 BEARING | 12 | |
| 5P2861 | 94 SEAL-O-RING | 1 | |
| 5P8245 | 95 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 6V0506 | 96 RING-RETAINING | 1 | |
| 6V6228 | 97 SEAL-O-RING | 2 | |
| 6V6764 | 98 RING-RETAINING | 1 | |
| 6V7673 | 99 BOLT (M12X1.75X50-MM) | 1 | |
| 7L9061 | 100 SEAL-O-RING | 3 | |
| 7T5594 | 101 RING-SEAL | 1 | |
| 8C3226 | 102 BOLT (M12X1.75X200-MM) | 8 | |
| 8T2572 | 103 SEAL-O-RING | 1 | |
| 8T4183 | 104 BOLT (M12X1.75X40-MM) | 20 | |
| 2709442 | 105 SCREW-TRUSS HEAD (M6X1X20-MM) | 6 | |
| 3777232 | 106 PLATE-CLUTCH | 2 | |
| 1272170 | 107 SCREW-TRUSS HEAD (M8X1.25X20-MM) | 12 |
