System And Components
571-6112 LINES GP-STEERINGS/N HRT107-UP
Group No: 571-6112
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2T3000 | 1 FLANGE-SPLIT | 6 | |
| 6V3482 | 2 CAP AS | 1 | |
| 7V8532 | 3 SPACER | 1 | |
| 9T1013 | 4 VALVE AS-CHECK | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1282407 | 5 BRACKET | 1 | |
| 1358575 | 6 BOLT AS | 2 | |
| 1518025 | 7 BLOCK | 1 | |
| 1608708 | 8 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1645567 | 9 COUPLER AS-QUICK DISCONNECT (MALE) | 2 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1833399 | 10 CONNECTOR AS | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 1925806 | 11 BRACKET | 1 | |
| 1973295 | 12 FLANGE-HALF | 2 | |
| 2067013 | 13 FASTENER | 71 | |
| 2609219 | 14 CONNECTOR AS | 2 | |
| 6V8638 | CONNECTOR | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 2815932 | 15 TEE AS | 3 | |
| 6V9837 | TEE-SWIVEL | 1 | |
| 2287090 | SEAL-O-RING | 2 | |
| 2815977 | 16 CONNECTOR AS | 8 | |
| 6V8642 | CONNECTOR | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 2977976 | 17 ELBOW AS | 1 | |
| 6V9850 | ELBOW | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 3196217 | 18 CONNECTOR AS | 4 | |
| 6V8639 | CONNECTOR | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3196226 | 19 ELBOW AS | 1 | |
| 8T6876 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 3196228 | 20 ELBOW AS | 1 | |
| 6V8721 | ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3338374 | 21 PLATE | 2 | |
| 3397793 | 22 MANIFOLD GP-CONTROL (STEERING) | 1 | |
| 2516159 | VALVE GP-SHUTTLE (TRACTION CONTROL) | 1 | |
| 2776343 | VALVE GP-SOLENOID (24-VOLT)(STEERING) | 2 | |
| 2540072 | COIL AS (24-VOLT) | 1 | |
| 2855622 | KIT-SEAL (SOLENOID VALVE) | 1 | |
| 3419393 | 23 VALVE GP-DIVERTER (STEERING) | 1 | |
| 6V8653 | BOLT-SOCKET HEAD (M6X1X40-MM) | 2 | |
| 4612544 | SENSOR AS (SPOOL)(STEERING) | 1 | |
| 3495283 | 24 PLATE-ADAPTER | 2 | |
| 3534993 | 25 ADAPTER | 2 | |
| 3615683 | 26 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 3706297 | 27 CONNECTOR AS | 1 | |
| 6V8715 | CONNECTOR | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3855772 | 28 ELBOW AS | 1 | |
| 6V8628 | ELBOW | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 2287088 | SEAL-O-RING | 1 | |
| 3960393 | 29 PLUG AS | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3603677 | PLUG (7/16-20-THD) | 1 | |
| 4316083 | 30 FILTER GP-OIL (STEERING) | 1 | |
| 4329443 | 31 PLATE | 1 | |
| 4350692 | 32 PLATE-COVER | 8 | |
| 4356712 | 33 PLATE-LOCK | 3 | |
| 4357022 | 34 PLATE-COVER | 2 | |
| 4386500 | 35 BOLT (M10X1.5X40-MM) | 6 | |
| 4391826 | 36 CONNECTOR AS | 1 | |
| 6V8647 | CONNECTOR | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 2287088 | SEAL-O-RING | 1 | |
| 4394525 | 37 PLATE | 1 | |
| 4423532 | 38 ADAPTER AS | 4 | |
| 8T7946 | REDUCER-ORFS | 1 | |
| 9X6577 | NUT | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 4423533 | 39 ADAPTER AS | 3 | |
| 2124991 | ADAPTER-TEE | 1 | |
| 2287095 | SEAL-O-RING | 2 | |
| 2385086 | SEAL-O-RING | 1 | |
| 4423535 | 40 ADAPTER AS | 2 | |
| 8T8552 | REDUCER-ORFS | 1 | |
| 9X6577 | NUT | 1 | |
| 2287094 | SEAL-O-RING | 1 | |
| 4491413 | 41 ADAPTER AS | 2 | |
| 6V8556 | NUT (1-3/16-12-THD) | 1 | |
| 6V8942 | REDUCER-O-RING | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 4491426 | 42 ADAPTER AS | 2 | |
| 8C8989 | ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 4590689 | 43 TEE AS | 1 | |
| 2287092 | SEAL-O-RING | 2 | |
| 2385081 | SEAL-O-RING | 1 | |
| 4590612 | TEE | 1 | |
| 4616676 | 44 BRACKET AS | 2 | |
| 4616678 | 45 BRACKET AS | 1 | |
| 9R2613 | BOSS-WELD (M10X1.5X25-MM) | 3 | |
| 4616683 | 46 PLATE | 1 | |
| 4616684 | 47 HOSE AS | 2 | |
| 4616695 | 48 HOSE AS | 1 | |
| 4616696 | 49 HOSE AS | 1 | |
| 4616736 | 50 HOSE AS | 1 | |
| 4616737 | 51 HOSE AS | 1 | |
| 4616742 | 52 HOSE AS | 1 | |
| 4669521 | 53 BRACKET AS | 1 | |
| 4689700 | 54 CLAMP-HALF | 6 | |
| 4689708 | 55 CLAMP-HALF | 4 | |
| 4727058 | 56 FILTER AS-OIL (HYDRAULIC STEERING) | 2 | |
| 4176162 | FILTER-OIL | 1 | |
| 4538935 | COVER AS-FILTER (CARTRIDGE, OIL) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 3603692 | PLUG (9/16-18-THD) | 1 | |
| 4883974 | 57 BOLT AS | 5 | |
| 5092754 | 58 ELBOW AS | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 4590630 | ADAPTER-ELBOW | 1 | |
| 5175448 | 59 CLAMP-HALF | 28 | |
| 5175505 | 60 CLAMP-HALF | 10 | |
| 5175530 | 61 CLAMP-HALF | 26 | |
| 0910081 | 62 SPACER (10.5X20X10-MM THK) | 1 | |
| 1220450 | 63 GROMMET | 2 | |
| 1249839 | 64 TEE | 1 | |
| 1261814 | 65 FILTER-OIL (ULTRA HIGH EFFICIENCY) | 2 | |
| 1358573 | 66 BOLT AS | 7 | |
| 1358577 | 67 BOLT AS | 8 | |
| 1497738 | 68 CLIP (LOOP) | 5 | |
| 1705715 | 69 SEAL-O-RING | 8 | |
| 1731437 | 70 FLANGE-HALF | 4 | |
| 1907673 | 71 SEAL-O-RING | 1 | |
| 1912962 | 72 SEAL-O-RING | 3 | |
| 1984781 | 73 WASHER-HARD (22X40X10-MM THK) | 3 | |
| 2287088 | 74 SEAL-O-RING | 1 | |
| 2287090 | 75 SEAL-O-RING | 6 | |
| 2287091 | 76 SEAL-O-RING | 2 | |
| 2287092 | 77 SEAL-O-RING | 4 | |
| 2343544 | 78 SEAL-O-RING | 3 | |
| 2352475 | 79 SEAL-RECTANGULAR | 1 | |
| 2352476 | 80 SEAL-RECTANGULAR | 1 | |
| 2385080 | 81 SEAL-O-RING | 2 | |
| 2385081 | 82 SEAL-O-RING | 1 | |
| 2458842 | 83 CLIP (LOOP) | 1 | |
| 2815933 | 84 ELBOW AS | 1 | |
| 6V9853 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2815972 | 85 CONNECTOR AS | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 2815982 | 86 CONNECTOR AS | 1 | |
| 6V9874 | CONNECTOR | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 2965724 | 87 TEE | 1 | |
| 2977968 | 88 FITTING | 1 | |
| 3196225 | 89 ELBOW AS | 2 | |
| 6V8625 | ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3196233 | 90 TEE AS | 2 | |
| 6V8782 | TEE | 1 | |
| 2287090 | SEAL-O-RING | 2 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3196236 | 91 TEE AS | 1 | |
| 6V9839 | TEE-SWIVEL | 1 | |
| 2287092 | SEAL-O-RING | 2 | |
| 3196240 | 92 CONNECTOR AS | 3 | |
| 6V9873 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 3218619 | 93 TEE AS | 1 | |
| 1021384 | TEE-FACE SEAL | 1 | |
| 2287092 | SEAL-O-RING | 2 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3218632 | 94 CONNECTOR AS | 4 | |
| 6V8632 | CONNECTOR | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3293356 | 95 NUT (M12X1.75-THD) | 3 | |
| 3295518 | 96 ADAPTER AS | 2 | |
| 8T2353 | ADAPTER | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3295537 | 97 CONNECTOR AS | 1 | |
| 6Y2349 | CONNECTOR | 1 | |
| 2385082 | SEAL-O-RING | 2 | |
| 3309758 | 98 ELBOW AS | 1 | |
| 8T4149 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3309772 | 99 ELBOW AS | 2 | |
| 6V8624 | ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3340161 | 100 MANIFOLD & VALVE GP (PILOT OIL) | 1 | |
| 3445675 | 101 NUT (M10X1.5-THD) | 16 | |
| 3696871 | 102 CONNECTOR AS | 2 | |
| 2287093 | SEAL-O-RING | 1 | |
| 2385086 | SEAL-O-RING | 1 | |
| 3696870 | ADAPTER-ELBOW | 1 | |
| 3979301 | 103 WASHER-HARD (11.5X20X15-MM THK) | 1 | |
| 4357441 | 104 PLATE-COVER | 24 | |
| 4580318 | 105 VALVE GP-STEERING | 1 | |
| 4616698 | 106 BRACKET AS | 2 | |
| 4792171 | 107 BOLT AS | 3 | |
| 4792172 | 108 BOLT AS | 2 | |
| 5692102 | 109 HOSE AS | 1 | |
| 5692103 | 110 HOSE AS | 1 | |
| 5715624 | 111 BRACKET AS-MOUNT | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 6 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 8 | |
| 9R2613 | BOSS-WELD (M10X1.5X25-MM) | 2 | |
| 5715626 | 112 BRACKET AS-MOUNT | 1 | |
| 8Y3795 | BOSS (M10X1.5X40-MM) | 2 | |
| 8Y4489 | BOSS (M10X1.5X35-MM) | 3 | |
| 9R2613 | BOSS-WELD (M10X1.5X25-MM) | 1 | |
| 5715628 | 113 BRACKET AS | 1 | |
| 5716010 | 114 HOSE AS | 1 | |
| 5716011 | 115 TUBE AS | 1 | |
| 5716012 | 116 HOSE AS | 1 | |
| 5716013 | 117 HOSE AS | 1 | |
| 5716014 | 118 HOSE AS | 1 | |
| 5716017 | 119 TUBE AS | 1 | |
| 5716018 | 120 HOSE AS | 1 | |
| 5716019 | 121 HOSE AS | 1 | |
| 5716020 | 122 HOSE AS | 1 | |
| 5716021 | 123 HOSE AS | 1 | |
| 5716024 | 124 HOSE AS | 1 | |
| 5716025 | 125 HOSE AS | 1 | |
| 5716026 | 126 HOSE AS | 1 | |
| 5716027 | 127 HOSE AS | 1 | |
| 5716028 | 128 TUBE AS | 1 | |
| 5716029 | 129 HOSE AS | 1 | |
| 5716030 | 130 HOSE AS | 1 | |
| 5716031 | 131 HOSE AS | 1 | |
| 5716032 | 132 TUBE AS | 1 | |
| 5716035 | 133 TUBE AS | 1 | |
| 5716036 | 134 TUBE AS | 1 | |
| 5716037 | 135 HOSE AS | 1 | |
| 5716054 | 136 TUBE AS | 1 | |
| 5716055 | 137 TUBE AS | 1 | |
| 5716253 | 138 MANIFOLD GP-CONTROL | 1 | |
| 5829230 | 139 TUBE AS | 1 | |
| 5829231 | 140 TUBE AS | 1 | |
| 5872789 | 141 VALVE GP-STEERING | 1 | |
| 5916983 | 142 HOSE AS | 1 | |
| 5916984 | 143 HOSE AS | 1 | |
| 5916985 | 144 HOSE AS | 1 | |
| 1P4577 | 145 FLANGE-HALF | 2 | |
| 1P4579 | 146 FLANGE-HALF | 2 | |
| 1P5767 | 147 FLANGE-HALF | 2 | |
| 1P7009 | 148 CLIP | 1 | |
| 1S0994 | 149 CLIP (LOOP) | 1 | |
| 3B4505 | 150 LOCKWASHER | 2 | |
| 3E6909 | 151 CLIP (LOOP) | 1 | |
| 3G8047 | 152 GROMMET | 1 | |
| 3G8054 | 153 CLIP (TAB) | 1 | |
| 3G8057 | 154 CLIP (SLOT) | 1 | |
| 4D9517 | 155 CLIP | 5 | |
| 5H4020 | 156 COVER | 1 | |
| 5P1076 | 157 WASHER-HARD (13.5X30X4-MM THK) | 7 | |
| 6C3241 | 158 BOLT (1/2-13X1.5-IN) | 8 | |
| 5P7466 | 159 CLIP (SLOT) | 2 | |
| 5P7467 | 160 CLIP (TAB) | 2 | |
| 5P7468 | 161 CLIP (SLOT) | 2 | |
| 5P7469 | 162 CLIP (TAB) | 2 | |
| 5P7470 | 163 CLIP (SLOT) | 1 | |
| 5P7471 | 164 CLIP (TAB) | 1 | |
| 5P8077 | 165 FLANGE-HALF | 2 | |
| 5P8112 | 166 GROMMET | 2 | |
| 5P8182 | 167 GROMMET (46-MM ID) | 1 | |
| 5P8444 | 168 GROMMET (37-MM ID) | 2 | |
| 5S7382 | 169 BOLT (3/8-16X1.375-IN) | 4 | |
| 6D4244 | 170 CLIP (LOOP) | 9 | |
| 6D4636 | 171 CLIP (LOOP) | 1 | |
| 6V0852 | 172 CAP-DUST | 2 | |
| 6V1572 | 173 CLIP (SLOT) | 4 | |
| 6V1573 | 174 CLIP (TAB) | 4 | |
| 6V1875 | 175 GROMMET | 4 | |
| 6V1889 | 176 CLIP (LOOP) | 4 | |
| 6V8783 | 177 TEE-FACE SEAL | 1 | |
| 7X2444 | 178 TEE-SWIVEL | 1 | |
| 7X3392 | 179 WASHER-HARD (13.5X22.5X3-MM THK) | 8 | |
| 7X7729 | 180 WASHER (11X25X3-MM THK) | 23 | |
| 8C3206 | 181 FLANGE-HALF | 4 | |
| 8S0023 | 182 CLIP (SLOT) | 2 | |
| 8S0024 | 183 CLIP (TAB) | 2 | |
| 8T4121 | 184 WASHER-HARD (11X21X2.5-MM THK) | 131 | |
| 8T4122 | 185 WASHER-HARD (17X32X3.5-MM THK) | 16 | |
| 8T4136 | 186 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4140 | 187 BOLT (M16X2X60-MM) | 4 | |
| 8T4172 | 188 BOLT (M10X1.5X80-MM) | 3 | |
| 8T4182 | 189 BOLT (M10X1.5X45-MM) | 17 | |
| 8T4183 | 190 BOLT (M12X1.75X40-MM) | 4 | |
| 8T4184 | 191 BOLT (M12X1.75X45-MM) | 2 | |
| 8T4185 | 192 BOLT (M10X1.5X50-MM) | 8 | |
| 8T4186 | 193 BOLT (M10X1.5X40-MM) | 13 | |
| 8T4189 | 194 BOLT (M8X1.25X20-MM) | 4 | |
| 8T4192 | 195 BOLT (M12X1.75X25-MM) | 14 | |
| 8T4194 | 196 BOLT (M12X1.75X50-MM) | 5 | |
| 8T4195 | 197 BOLT (M10X1.5X30-MM) | 11 | |
| 1837121 | 198 BOLT (M10X1.5X35-MM) | 26 | |
| 8T4198 | 199 BOLT (M10X1.5X100-MM) | 2 | |
| 8T4223 | 200 WASHER-HARD (13.5X25.5X3-MM THK) | 37 | |
| 8T4224 | 201 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T4648 | 202 BOLT (M12X1.75X70-MM) | 4 | |
| 8T4896 | 203 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 8T4910 | 204 BOLT (M12X1.75X60-MM) | 1 | |
| 8T4956 | 205 BOLT (M12X1.75X35-MM) | 11 | |
| 8T5005 | 206 BOLT (M10X1.5X70-MM) | 6 | |
| 8T5436 | 207 BOLT (M10X1.5X130-MM) | 3 | |
| 8T6466 | 208 BOLT (M10X1.5X60-MM) | 45 | |
| 8T6871 | 209 BOLT (5/8-11X2.5-IN) | 12 | |
| 8T9043 | 210 BOLT (5/16-18X0.875-IN) | 2 | |
| 9M8406 | 211 CLIP (LOOP) | 2 | |
| 9X8250 | 212 CLIP (LOOP) | 7 | |
| 9X9365 | 213 BRACKET (LAMP) | 1 |
