System And Components
481-8119 LINES GP-POWER TRAIN OILS/N RB41-UP
Group No: 481-8119
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3755400 | 1 HOSE AS | 1 | |
| 0950670 | 2 BOLT (M12X1.75X45-MM) | 4 | |
| 1241859 | 3 SEAL-O-RING | 2 | |
| 1308433 | 4 GROMMET | 2 | |
| 1336934 | 5 SPACER (11X20X25-MM THK) | 1 | |
| 1355353 | 6 BLOCK | 1 | |
| 1645567 | 7 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1749708 | 8 ADAPTER-FILTER | 1 | |
| 1757963 | 9 CONNECTOR | 1 | |
| 1833399 | 10 CONNECTOR AS | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 1912962 | 11 SEAL-O-RING | 3 | |
| 1973295 | 12 FLANGE-HALF | 6 | |
| 1F7854 | 13 SPACER (11.01X19.05X49.21-MM THK) | 1 | |
| 1P4579 | 14 FLANGE-HALF | 16 | |
| 1P4584 | 15 FLANGE-HALF | 4 | |
| 2287090 | 16 SEAL-O-RING | 1 | |
| 2287092 | 17 SEAL-O-RING | 1 | |
| 2343544 | 18 SEAL-O-RING | 8 | |
| 2352476 | 19 SEAL-RECTANGULAR | 1 | |
| 2352479 | 20 SEAL-RECTANGULAR | 1 | |
| 2385080 | 21 SEAL-O-RING | 2 | |
| 2385082 | 22 SEAL-O-RING | 1 | |
| 2639020 | 23 CLAMP | 8 | |
| 2815871 | 24 ADAPTER | 1 | |
| 2815941 | 25 CONNECTOR AS | 1 | |
| 8T7496 | CONNECTOR | 1 | |
| 2154639 | SEAL-O-RING | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 2815979 | 26 ELBOW AS | 1 | |
| 6V9007 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 2958677 | 27 TUBE AS | 1 | |
| 2958745 | 28 BLOCK | 1 | |
| 2977976 | 29 ELBOW AS | 1 | |
| 6V9850 | ELBOW | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 3012197 | 30 PLATE AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 1 | |
| 3195383 | 31 PLATE AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 1 | |
| 3196227 | 32 ELBOW AS | 1 | |
| 6V9851 | ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 3196240 | 33 CONNECTOR AS | 1 | |
| 6V9873 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 3200389 | 34 PLATE | 1 | |
| 3201317 | 35 PLATE AS | 1 | |
| 3206134 | 36 PLATE AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 1 | |
| 3218617 | 37 CONNECTOR AS | 1 | |
| 8T8985 | CONNECTOR | 1 | |
| 2287095 | SEAL-O-RING | 1 | |
| 2287096 | SEAL-O-RING | 1 | |
| 3218649 | 38 VALVE AS-FLUID SAMPLING | 1 | |
| 8C3446 | VALVE-SAMPLING | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3260316 | 39 PLUG AS | 1 | |
| 9S6130 | PLUG | 1 | |
| 2287096 | SEAL-O-RING | 1 | |
| 3293356 | 40 NUT (M12X1.75-THD) | 1 | |
| 3295515 | 41 TEE AS | 1 | |
| 2287093 | SEAL-O-RING | 2 | |
| 6V8785 | TEE | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3309758 | 42 ELBOW AS | 1 | |
| 8T4149 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3309759 | 43 TEE AS | 1 | |
| 4I7651 | TEE-O-RING PORT | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3309762 | 44 FITTING AS | 1 | |
| 0857356 | ELBOW-ADAPTER | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3309764 | 45 ELBOW AS | 1 | |
| 8C6712 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3351814 | 46 TUBE AS | 1 | |
| 3399704 | 47 FILTER GP-OIL (POWER TRAIN) | 2 | |
| 3410086 | 48 ELBOW AS | 1 | |
| 8C3364 | ELBOW | 1 | |
| 2287094 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3416253 | 49 HOSE AS | 1 | |
| 3445675 | 50 NUT (M10X1.5-THD) | 1 | |
| 3717151 | 51 ELBOW AS | 1 | |
| 8T1682 | ELBOW | 1 | |
| 2287095 | SEAL-O-RING | 1 | |
| 2385086 | SEAL-O-RING | 1 | |
| 3833587 | 52 HOSE AS | 1 | |
| 3E4096 | 53 CAP | 8 | |
| 4285380 | 54 PLATE | 2 | |
| 4285385 | 55 PLATE AS | 2 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 1 | |
| 4285396 | 56 HOSE AS | 1 | |
| 4285404 | 57 BLOCK | 4 | |
| 4285406 | 58 BLOCK | 4 | |
| 4286633 | 59 HOSE AS | 1 | |
| 4392335 | 60 HOSE AS | 1 | |
| 4593182 | 61 PLATE AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 1 | |
| 4628068 | 62 HOSE AS | 1 | |
| 4792171 | 63 BOLT AS | 1 | |
| 4792172 | 64 BOLT AS | 2 | |
| 4883974 | 65 BOLT AS | 2 | |
| 4T6788 | 66 FILTER-OIL (ADVANCED EFFICIENCY)(HYDRAULIC) | 1 | |
| 2237809 | FILTER-OIL (ULTRA HIGH EFFICIENCY)(HYDRAULIC) | 1 | |
| 5594913 | 67 HOSE | 2 | |
| 5597193 | 68 TUBE AS | 1 | |
| 5597196 | 69 TUBE AS | 1 | |
| 5755569 | 70 HOSE AS | 1 | |
| 5755573 | 71 HOSE AS | 1 | |
| 5755574 | 72 HOSE AS | 1 | |
| 5755575 | 73 HOSE AS | 1 | |
| 5796201 | 74 TUBE AS | 1 | |
| 5796202 | 75 PLATE AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 2 | |
| 5796203 | 76 HOSE AS | 1 | |
| 5796204 | 77 HOSE AS | 1 | |
| 5P7464 | 78 CLIP (SLOT) | 1 | |
| 5P7465 | 79 CLIP (TAB) | 1 | |
| 5P7466 | 80 CLIP (SLOT) | 3 | |
| 5P7467 | 81 CLIP (TAB) | 3 | |
| 5P7468 | 82 CLIP (SLOT) | 1 | |
| 5P7469 | 83 CLIP (TAB) | 1 | |
| 5P7470 | 84 CLIP (SLOT) | 8 | |
| 5P7471 | 85 CLIP (TAB) | 8 | |
| 5P7703 | 86 GROMMET (52-MM ID) | 3 | |
| 5P8112 | 87 GROMMET | 3 | |
| 5P8182 | 88 GROMMET (46-MM ID) | 5 | |
| 5P8444 | 89 GROMMET (37-MM ID) | 1 | |
| 6D4244 | 90 CLIP (LOOP) | 5 | |
| 6V0852 | 91 CAP-DUST | 1 | |
| 6V1249 | 92 GROMMET (22-MM ID) | 1 | |
| 6V4356 | 93 CLIP (SLOT) | 2 | |
| 6V4357 | 94 CLIP (TAB) | 2 | |
| 6V4590 | 95 SEAL-O-RING | 3 | |
| 6V9833 | 96 CAP | 1 | |
| 7X2550 | 97 BOLT (M12X1.75X110-MM) | 4 | |
| 7X2554 | 98 BOLT (M16X2X70-MM) | 10 | |
| 7X3392 | 99 WASHER-HARD (13.5X22.5X3-MM THK) | 12 | |
| 8C3447 | 100 CAP-DUST | 1 | |
| 8T0077 | 101 CONNECTOR | 1 | |
| 8T0568 | 102 SEAL-O-RING | 2 | |
| 8T4121 | 103 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4139 | 104 BOLT (M12X1.75X30-MM) | 15 | |
| 8T4183 | 105 BOLT (M12X1.75X40-MM) | 31 | |
| 8T4184 | 106 BOLT (M12X1.75X45-MM) | 14 | |
| 8T4185 | 107 BOLT (M10X1.5X50-MM) | 1 | |
| 8T4191 | 108 BOLT (M10X1.5X16-MM) | 1 | |
| 8T4223 | 109 WASHER-HARD (13.5X25.5X3-MM THK) | 83 | |
| 8T4648 | 110 BOLT (M12X1.75X70-MM) | 8 | |
| 8T4910 | 111 BOLT (M12X1.75X60-MM) | 4 | |
| 8T4956 | 112 BOLT (M12X1.75X35-MM) | 14 | |
| 8T5005 | 113 BOLT (M10X1.5X70-MM) | 1 | |
| 8T5041 | 114 BOLT (M12X1.75X120-MM) | 4 | |
| 8T7338 | 115 BOLT (M16X2X45-MM) | 8 | |
| 8W3166 | 116 HOSE AS | 1 | |
| 9X8257 | 117 WASHER (17.5X30X3.5-MM THK) | 20 |
