368-5018 DIFFERENTIAL & BEVEL GEAR GPS/N LWX1-UP

Group No: 368-5018
Part NumberPart NameQty
4B93741 CUP-BEARING (TAPERED ROLLER)1
5M65922 CUP-BEARING (TAPERED ROLLER)1
6M16373 CONE-BEARING (TAPERED ROLLER)1
6M16384 CUP-BEARING (TAPERED ROLLER)1
12681825 CUP-BEARING (TAPERED ROLLER)1
16521356 CONE-SPECIAL TAPERED1
4B93737 CONE-BEARING (TAPERED ROLLER)1
6B48528 CONE-BEARING (TAPERED ROLLER)1
4E19669 RETAINER1
5J108610 SEAL-O-RING1
5K366111 LOCK-BEARING2
8R005312 WASHER (91.4X129.8X6.4-MM THK)1
8R285713 RING-ADJUSTMENT1
8T301314 SEAL-O-RING1
9M502415 SEAL-O-RING1
133429216 SEAL-LIP TYPE1
356420317 GEAR SET-BEVEL (45-TEETH)1
3564202SHAFT-BEVEL PINION1
3624771GEAR-BEVEL1
137885618 PIN1
137885719 RING-ADJUSTMENT1
146727120 DIFFERENTIAL GP-NOSPIN1
154799721 SHIM PACK (INCLUDES 16-SHIMS)1
164932622 SHIM PACK (INCLUDES 14-SHIMS)1
173585023 YOKE AS1
1H622723A SEAL-O-RING1
4E360123B GUARD1
121125723C RING-RETAINING1
144452423D CUP-DUST1
209669624 HOUSING-PINION1
154799825 COVER1
160851026 BOLT-SELF-LOCKING (M20X2.5X60-MM)24
164932427 CARRIER AS1
3J190727A SEAL-O-RING1
177975527B BOLT (M30X3.5X160-MM)4
9X839927C WASHER (33X56X6-MM THK)4
9S800427D PLUG (9/16-18-THD)1
178299128 BOLT-SELF-LOCKING (M20X2.5X70-MM)45
2H393229 SEAL-O-RING1
5P824530 WASHER-HARD (13.5X25.5X3-MM THK)4
5P824831 WASHER-HARD (20X36.5X3.5-MM THK)93
6V353232 BOLT (M20X2.5X60-MM)24
6V568433 BOLT (M12X1.75X45-MM)4
192474434 BOLT (M10X1.5X20-MM)2
8R005235 NUT-STAKE (M90X2-THD)1
8T412136 WASHER-HARD (11X21X2.5-MM THK)8
6V773237 BOLT (M10X1.5X25-MM)8
