System And Components
540-5200 TANK GP-FUELS/N ST71-UP
Group No: 540-5200
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E7753 | 1 FLOAT AS | 1 | |
| 6G7803 | 2 VENT AS | 1 | |
| 2057303 | 3 ADAPTER-FAST FILL FUEL | 1 | |
| 2525806 | 4 VALVE AS-SHUTOFF (FAST FILL FUEL) | 2 | |
| 2801065 | 5 PLATE AS | 3 | |
| 3173252 | 6 VENT AS-FUEL TANK (FAST FILL) | 2 | |
| 4718198 | 7 RECEIVER (FAST FILL FUEL) | 1 | |
| 4792171 | 8 BOLT AS | 2 | |
| 4895648 | 9 MOUNTING GP-SENSOR | 1 | |
| 5403940 | 10 TANK AS-FUEL | 1 | |
| 3E6773 | 11 SEAL-O-RING | 3 | |
| 5606350 | 12 HOSE AS | 1 | |
| 3J2903 | 13 COVER | 1 | |
| 1358577 | 14 BOLT AS | 6 | |
| 1J9671 | 15 SEAL-O-RING | 4 | |
| 1P4582 | 16 FLANGE-HALF (SPLIT) | 2 | |
| 5403950 | 17 HOSE AS | 2 | |
| 3884327 | 18 CAP-DUST | 1 | |
| 4J0527 | 19 SEAL-O-RING | 2 | |
| 5H6734 | 20 SEAL-O-RING | 2 | |
| 5P2618 | 21 CONNECTOR | 4 | |
| 5630354 | 22 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 8T4139 | 23 BOLT (M12X1.75X30-MM) | 4 | |
| 7D1553 | 24 CLIP | 2 | |
| 8T4184 | 25 BOLT (M12X1.75X45-MM) | 4 | |
| 8T4223 | 26 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 9M7958 | 27 CLAMP-HOSE | 1 | |
| 5T8645 | KIT-VENT (FUEL TANK)(ALUMINUM) | 1 | |
| 2721595 | KIT-VENT (FUEL TANK)(PLASTIC) | 1 |
