System And Components
567-0431 TANK GP-FUELS/N SKH1-606
Group No: 567-0431
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E7753 | 1 FLOAT AS | 1 | |
| 2525806 | 3 VALVE AS-SHUTOFF (FAST FILL FUEL) | 2 | |
| 3173252 | 4 VENT AS-FUEL TANK | 2 | |
| 4718198 | 5 RECEIVER (FAST FILL FUEL) | 1 | |
| 4895648 | 6 MOUNTING GP-SENSOR | 1 | |
| 1J9671 | 7 SEAL-O-RING | 4 | |
| 1P4582 | 8 FLANGE-HALF | 2 | |
| 2057303 | 9 ADAPTER-FAST FILL FUEL | 1 | |
| 3884327 | 10 CAP-DUST | 1 | |
| 3E6773 | 11 SEAL-O-RING | 3 | |
| 3J2903 | 12 COVER | 1 | |
| 4J0527 | 13 SEAL-O-RING | 2 | |
| 5717381 | 14 TANK AS-FUEL | 1 | |
| 1H8306 | SCREW-PURGE (1/2-20X1.625-IN) | 1 | |
| 2D8678 | SPACER (1.31X1.5X1-IN THK) | 2 | |
| 3D2824 | SEAL-O-RING | 2 | |
| 3E6773 | SEAL-O-RING | 4 | |
| 4H9027 | PLUG-PIPE | 1 | |
| 9S4181 | PLUG (1-5/16-12-THD) | 1 | |
| 9X6138 | PLUG-PIPE | 1 | |
| 9X7287 | SEAL-O-RING | 2 | |
| 1643417 | COVER | 1 | |
| 2212372 | ADAPTER | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 2934576 | GAUGE (SIGHT GLASS) | 2 | |
| 4792171 | BOLT AS | 24 | |
| 4792172 | BOLT AS | 6 | |
| 5334159 | BOLT AS | 6 | |
| 4773162 | EYEBOLT AS | 4 | |
| 8T4121 | WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 1837121 | BOLT (M10X1.5X35-MM) | 1 | |
| 5718520 | 15 HOSE AS | 2 | |
| 5754640 | 16 HOSE AS | 1 | |
| 5H6734 | 17 SEAL-O-RING | 2 | |
| 5P2618 | 18 CONNECTOR | 4 | |
| 8T4139 | 19 BOLT (M12X1.75X30-MM) | 4 | |
| 8T4184 | 20 BOLT (M12X1.75X45-MM) | 4 | |
| 8T4223 | 21 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 9M7958 | 22 CLAMP-HOSE | 1 | |
| 6G7803 | VENT AS | 1 | |
| 2721595 | KIT-VENT (FUEL TANK) | 1 | |
| 5T8645 | KIT-VENT (FUEL TANK) | 1 |
