System And Components
439-1201 LINES GP-BRAKE COOLINGS/N RB41-UP
Group No: 439-1201
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P1265 | 1 HOSE (19-CM EACH) | ||
| 3K4056 | 2 SPRING | 1 | |
| 1645567 | 3 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1650056 | 4 SCREEN AS (BRAKE COOLING LINES) | 1 | |
| 2352482 | 5 SEAL-RECTANGULAR | 3 | |
| 2958004 | 6 HOSE AS | 1 | |
| 2958008 | 7 TUBE AS | 1 | |
| 2958012 | 8 TUBE AS | 1 | |
| 2958023 | 9 TUBE AS | 1 | |
| 2958025 | 10 TUBE AS | 1 | |
| 2958027 | 11 TUBE AS | 1 | |
| 2958035 | 12 PLATE AS | 2 | |
| 2958037 | 13 PLATE | 6 | |
| 5526131 | 14 TUBE | 1 | |
| 2958076 | 15 BLOCK | 1 | |
| 2971868 | 16 HOSE AS | 1 | |
| 2980609 | 17 PLATE AS | 2 | |
| 2982745 | 18 PLATE AS | 1 | |
| 2987003 | 19 PLATE AS | 1 | |
| 2987480 | 20 PLATE AS | 2 | |
| 2995325 | 21 TUBE AS | 1 | |
| 2995326 | 22 HOSE AS | 1 | |
| 2995327 | 23 TUBE AS | 2 | |
| 2995332 | 24 HOUSING AS-SCREEN | 1 | |
| 2995334 | 25 BLOCK | 1 | |
| 2995335 | 26 HOSE AS | 1 | |
| 2995336 | 27 HOSE AS | 1 | |
| 5526132 | 28 TUBE | 1 | |
| 4679206 | 29 HOSE AS | 1 | |
| 3160652 | 30 TUBE AS | 1 | |
| 3160654 | 31 HOSE AS | 1 | |
| 3217602 | 32 PLATE AS | 1 | |
| 3221346 | 33 TUBE AS | 1 | |
| 3373442 | 34 HOSE AS | 1 | |
| 3373443 | 35 TUBE AS | 1 | |
| 3375126 | 36 PLATE AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 2 | |
| 3375256 | 37 PLATE | 1 | |
| 3399702 | 38 FILTER GP-OIL (BRAKE OIL COOLER LINES) | 1 | |
| 3414953 | 39 TUBE AS | 1 | |
| 3420731 | 40 SPACER | 1 | |
| 3422624 | 41 SPACER | 1 | |
| 3557218 | 42 TUBE AS | 1 | |
| 3557219 | 43 HOSE AS | 1 | |
| 4458799 | 44 PLATE AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 1 | |
| 5526133 | 45 TUBE AS | 1 | |
| 0950706 | 46 BOLT-SOCKET HEAD (M16X2X110-MM) | 4 | |
| 1081784 | 47 BOLT-SOCKET HEAD (M12X1.75X120-MM) | 6 | |
| 1081785 | 48 BOLT-SOCKET HEAD (M16X2X130-MM) | 4 | |
| 1171266 | 49 SEAL-O-RING | 1 | |
| 1241859 | 50 SEAL-O-RING | 11 | |
| 1576199 | 51 GROMMET | 1 | |
| 1704821 | 52 SEAL-O-RING | 2 | |
| 1P4582 | 53 FLANGE-HALF | 8 | |
| 1P4584 | 54 FLANGE-HALF | 10 | |
| 1P4585 | 55 FLANGE-HALF | 18 | |
| 1P7016 | 56 FLANGE-HALF | 4 | |
| 2094582 | 57 CLAMP-T BOLT | 24 | |
| 2352479 | 58 SEAL-RECTANGULAR | 2 | |
| 2V0600 | 59 CLAMP-HALF | 12 | |
| 3072670 | 60 PLUG AS | 1 | |
| 9S4185 | PLUG (3/4-16-THD) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3196211 | 61 ADAPTER AS | 1 | |
| 2P8421 | ADAPTER-O-RING | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3218649 | 62 VALVE AS-FLUID SAMPLING (HYDRAULIC OIL) | 1 | |
| 8C3446 | VALVE-SAMPLING | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3309764 | 63 ELBOW AS | 1 | |
| 8C6712 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3979301 | 64 WASHER-HARD (11.5X20X15-MM THK) | 1 | |
| 3E7434 | 65 COVER | 1 | |
| 3J2903 | 66 COVER | 1 | |
| 5P7470 | 67 CLIP (SLOT) | 1 | |
| 5P7471 | 68 CLIP (TAB) | 1 | |
| 5P7703 | 69 GROMMET (52-MM ID) | 1 | |
| 5S9134 | 70 SEAL-O-RING | 2 | |
| 6V0852 | 71 CAP-DUST | 1 | |
| 6V1197 | 72 SEAL-O-RING | 2 | |
| 6V1581 | 73 CLIP (SLOT) | 1 | |
| 6V1582 | 74 CLIP (TAB) | 1 | |
| 6V4590 | 75 SEAL-O-RING | 5 | |
| 6V6782 | 76 CLIP (SLOT) | 1 | |
| 6V6783 | 77 CLIP (TAB) | 1 | |
| 7X2553 | 78 BOLT (M16X2X40-MM) | 4 | |
| 7X2554 | 79 BOLT (M16X2X70-MM) | 5 | |
| 7X7729 | 80 WASHER (11X25X3-MM THK) | 2 | |
| 8C3451 | 81 CAP-DUST (HYDRAULIC OIL) | 1 | |
| 8T0568 | 82 SEAL-O-RING | 9 | |
| 8T4121 | 83 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4133 | 84 NUT (M10X1.5-THD) | 5 | |
| 4792171 | 85 BOLT AS | 4 | |
| 8T4139 | 86 BOLT (M12X1.75X30-MM) | 33 | |
| 8T4140 | 87 BOLT (M16X2X60-MM) | 40 | |
| 8T4183 | 88 BOLT (M12X1.75X40-MM) | 16 | |
| 8T4184 | 89 BOLT (M12X1.75X45-MM) | 36 | |
| 8T4185 | 90 BOLT (M10X1.5X50-MM) | 1 | |
| 8T4193 | 91 BOLT (M16X2X50-MM) | 28 | |
| 8T4194 | 92 BOLT (M12X1.75X50-MM) | 8 | |
| 4792172 | 93 BOLT AS | 5 | |
| 8T4223 | 94 WASHER-HARD (13.5X25.5X3-MM THK) | 138 | |
| 8T4244 | 95 NUT (M12X1.75-THD) | 18 | |
| 8T4910 | 96 BOLT (M12X1.75X60-MM) | 8 | |
| 8T4956 | 97 BOLT (M12X1.75X35-MM) | 19 | |
| 9X6400 | 98 CLIP-HALF | 22 | |
| 9X7287 | 99 SEAL-O-RING | 1 | |
| 9X8257 | 100 WASHER (17.5X30X3.5-MM THK) | 77 | |
| 3E4096 | 101 CAP | 24 |
