System And Components
543-1431 PUMP GP-GEARS/N AX71-UP
Group No: 543-1431
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1B8736 | 1 KEY-WOODRUFF | 2 | |
| 3J2903 | 2 COVER (FLANGE) | 1 | |
| 3P0254 | 3 GEAR (8-TEETH) | 2 | |
| 3S0004 | 4 WASHER (0.406X0.728X0.09-IN THK) | 6 | |
| 3T0571 | 5 BODY AS-OIL PUMP | 1 | |
| 8M8489 | DOWEL | 4 | |
| 4D2212 | 6 GEAR (12-TEETH) | 2 | |
| 4J0527 | 8 SEAL-O-RING | 1 | |
| 6P0822 | 9 COVER AS-OIL PUMP | 1 | |
| 1M3780 | 9A BUSHING | 2 | |
| 7X0304 | 10 BOLT (3/8-16X8.5-IN) | 6 | |
| 8T4192 | 11 BOLT (M12X1.75X25-MM) | 4 | |
| 8T4223 | 12 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 9S1018 | 13 WASHER (9.73X19.05X0.84-MM THK) | 8 | |
| 1357273 | 14 SEAL-LIP TYPE | 1 | |
| 1593064 | 15 BODY AS-OIL PUMP | 1 | |
| 1M3909 | 15A BUSHING | 2 | |
| 1618068 | 16 SEAL-O-RING | 3 | |
| 5393853 | 17 BODY AS-OIL PUMP | 1 | |
| 1M3909 | 17A BUSHING | 2 | |
| 8M8489 | DOWEL | 2 | |
| 5403184 | 18 GEAR AS-PUMP | 1 | |
| 5403186 | 19 GEAR AS-PUMP | 1 |
