System And Components
579-1670 COVER GP-SHIPPINGS/N AX71-UP
Group No: 579-1670
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E4096 | 1 CAP | 11 | |
| 1256729 | 2 COVER | 5 | |
| 2077899 | 3 PLUG AS | 1 | |
| 9S4188 | PLUG | 1 | |
| 4K1388 | SEAL-O-RING | 1 | |
| 2094573 | 4 CLAMP-T BOLT | 3 | |
| 2239985 | 5 CLAMP | 12 | |
| 2343544 | 6 SEAL-O-RING | 7 | |
| 2352476 | 7 SEAL-RECTANGULAR | 6 | |
| 2639020 | 8 CLAMP | 3 | |
| 2993330 | 9 NUT (1/2-13-THD) | 4 | |
| 3196238 | 10 PLUG AS | 3 | |
| 6V9509 | PLUG (13/16-16-THD) | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 3218612 | 11 PLUG AS | 2 | |
| 6V9508 | PLUG (11/16-16-THD) | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 3293356 | 12 NUT (M12X1.75-THD) | 88 | |
| 3404515 | 13 NUT (5/8-11-THD) | 8 | |
| 3803832 | 14 COVER | 1 | |
| 3803836 | 15 COVER | 1 | |
| 0S1589 | 16 BOLT (5/8-11X1.75-IN) | 4 | |
| 0S1621 | 17 BOLT (1/2-13X1-IN) | 16 | |
| 1J3619 | 18 COVER | 10 | |
| 1P3703 | 19 SEAL-RECTANGULAR | 2 | |
| 1P4576 | 20 FLANGE-HALF | 4 | |
| 1P4579 | 21 FLANGE-HALF | 10 | |
| 1P4582 | 22 FLANGE-HALF | 18 | |
| 1P4584 | 23 FLANGE-HALF | 10 | |
| 1P4585 | 24 FLANGE-HALF | 2 | |
| 1P7016 | 25 FLANGE-HALF | 2 | |
| 1S3730 | 26 COVER | 3 | |
| 2H6338 | 27 SEAL-O-RING | 1 | |
| 3B6484 | 28 CAP | 1 | |
| 3D8908 | 29 COVER | 1 | |
| 3E7434 | 30 COVER | 2 | |
| 3H5523 | 31 COVER | 6 | |
| 3J2903 | 32 COVER | 6 | |
| 3J5553 | 33 GASKET | 1 | |
| 3J6933 | 34 GASKET | 3 | |
| 3P1155 | 35 SEAL-O-RING | 2 | |
| 4J4382 | 36 PLUG-PIPE (1/2-14-THD) | 1 | |
| 4L6454 | 37 BOLT (3/8-16X1-IN) | 8 | |
| 5D9338 | 38 COVER | 2 | |
| 5M6213 | 39 PLUG-PIPE (1/4-18-THD) | 1 | |
| 6D0848 | 40 COVER | 1 | |
| 6J2680 | 41 SEAL-O-RING | 1 | |
| 6J4834 | 42 COVER | 4 | |
| 6V1179 | 43 SEAL-O-RING | 1 | |
| 6V1197 | 44 SEAL-O-RING | 3 | |
| 6V4590 | 45 SEAL-O-RING | 16 | |
| 6V8001 | 46 SEAL-O-RING | 1 | |
| 6V8801 | 47 NUT (3/8-16-THD) | 8 | |
| 6V9829 | 48 CAP (ORFS) | 2 | |
| 6V9830 | 49 CAP (ORFS) | 3 | |
| 6V9832 | 50 CAP (ORFS) | 1 | |
| 7J0401 | 51 COVER | 5 | |
| 7J0402 | 52 COVER | 3 | |
| 7M8543 | 53 COVER | 2 | |
| 7N7820 | 54 BOOT | 3 | |
| 7X0288 | 55 BOLT (3/8-16X1.625-IN) | 8 | |
| 7X0345 | 56 BOLT (5/8-11X1.75-IN) | 4 | |
| 7X0347 | 57 BOLT (5/8-11X2.25-IN) | 8 | |
| 7X0350 | 58 BOLT (5/8-11X3.5-IN) | 4 | |
| 7X0448 | 59 NUT (5/8-11-THD) | 4 | |
| 8L5680 | 60 CAP | 1 | |
| 8T0568 | 61 SEAL-O-RING | 7 | |
| 8T4122 | 62 WASHER-HARD (17X32X3.5-MM THK) | 32 | |
| 8T4176 | 63 BOLT (M12X1.75X90-MM) | 4 | |
| 8T4184 | 64 BOLT (M12X1.75X45-MM) | 50 | |
| 8T4194 | 65 BOLT (M12X1.75X50-MM) | 25 | |
| 8T4223 | 66 WASHER-HARD (13.5X25.5X3-MM THK) | 248 | |
| 8T4648 | 67 BOLT (M12X1.75X70-MM) | 8 | |
| 8T4835 | 68 BOLT (1/2-13X2-IN) | 2 | |
| 8T4896 | 69 WASHER-HARD (10.2X18.5X2.5-MM THK) | 24 | |
| 8T4910 | 70 BOLT (M12X1.75X60-MM) | 8 | |
| 8T4956 | 71 BOLT (M12X1.75X35-MM) | 36 | |
| 8T6871 | 72 BOLT (5/8-11X2.5-IN) | 4 | |
| 8T8917 | 73 BOLT (1/2-13X1.25-IN) | 12 | |
| 8T8919 | 74 BOLT (1/2-13X1.75-IN) | 8 | |
| 8T9383 | 75 BOLT (1/2-13X0.75-IN) | 4 | |
| 8T9391 | 76 BOLT (1/2-13X3.75-IN) | 2 | |
| 8W2692 | 77 FLANGE | 1 | |
| 9C2260 | 78 COVER | 2 | |
| 9N6377 | 79 CAP | 3 | |
| 9S8927 | 80 PLUG | 1 |
