System And Components
8X-0357 LINES GP-OIL COOLERS/N 2TK79-UP
Group No: 8X-0357
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P2566 | 1 BOLT (1/2-13X1.5-IN) | 22 | |
| 8T4223 | 2 WASHER-HARD (13.5X25.5X3-MM THK) | 28 | |
| 6K6307 | 3 SEAL-O-RING | 1 | |
| 1047658 | 4 ELBOW | 1 | |
| 9S4182 | PLUG (7/16-20-THD) | 1 | |
| 6G1444 | 5 ADAPTER | 1 | |
| 1P3707 | SEAL-RECTANGULAR | 1 | |
| 6V9182 | 6 ELBOW | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 9T1460 | 7 SCREEN | 1 | |
| 4J0527 | 8 SEAL-O-RING | 8 | |
| 8T9391 | 9 BOLT (1/2-13X3.75-IN) | 3 | |
| 1P4582 | 10 FLANGE-HALF | 14 | |
| 5T7944 | 11 HOSE AS | 1 | |
| 3E8026 | 12 CLIP (SLOT) | 1 | |
| 3E8027 | CLIP (TAB) | 1 | |
| 2A6780 | 13 HOSE AS | 1 | |
| 6V9007 | 14 ELBOW | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 8W3291 | 15 HOSE AS | 1 | |
| 5P7470 | 16 CLIP (SLOT) | 2 | |
| 5P7471 | CLIP (TAB) | 2 | |
| 8W3292 | 17 HOSE AS | 1 | |
| 8G0423 | 18 PLATE | 2 | |
| 9B7237 | BOLT (3/8-16X1.25-IN) | 2 | |
| 1D4717 | NUT (3/8-16-THD) | 2 | |
| 7X0772 | WASHER-HARD (10.2X25.5X2.5-MM THK) | 4 | |
| 6F8146 | 19 SEAL-O-RING | 2 | |
| 2G2213 | 20 TEE | 1 | |
| 8T8919 | BOLT (1/2-13X1.75-IN) | 4 | |
| 6V9746 | 21 SEAL-O-RING | 2 | |
| 3H7654 | 22 WASHER-HARD (13.5X22.5X3-MM THK) | 4 | |
| 2G6104 | 23 TUBE AS | 1 | |
| 8T9391 | 24 BOLT (1/2-13X3.75-IN) | 1 | |
| 3J7354 | 25 SEAL-O-RING | 1 | |
| 1N5998 | 26 PLUG | 1 | |
| 6E6640 | 27 SCREEN AS (HYDRAULIC OIL) | 1 | |
| 3J1907 | 28 SEAL-O-RING | 1 | |
| 8W5566 | 29 ADAPTER | 1 | |
| 7X0334 | 30 BOLT (1/2-13X5-IN) | 4 | |
| 9S4191 | 31 PLUG (9/16-18-THD) | 1 | |
| 9S4183 | 32 PLUG (1-1/16-12-THD) | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 5T6778 | 33 MANIFOLD | 1 | |
| 4J0527 | 34 SEAL-O-RING | 21 | |
| 5P2566 | 35 BOLT (1/2-13X1.5-IN) | 56 | |
| 8T4223 | 36 WASHER-HARD (13.5X25.5X3-MM THK) | 70 | |
| 7X0331 | 37 BOLT (1/2-13X4.25-IN) | 2 | |
| 5T6742 | 38 ELBOW | 1 | |
| 5T9030 | 39 TUBE | 1 | |
| 1092332 | SEAL-O-RING | 2 | |
| 1050170 | 40 VALVE GP-DIVERTER | 1 | |
| 5T0017 | 41 ELBOW | 1 | |
| 1P4582 | 42 FLANGE-HALF | 24 | |
| 8W0959 | 43 HOSE AS | 1 | |
| 5T7949 | 44 HOSE AS | 1 | |
| 5T5533 | 45 MANIFOLD | 1 | |
| 8T9389 | 46 BOLT (1/2-13X2.75-IN) | 4 | |
| 8W0958 | 47 HOSE AS | 2 | |
| 8C4436 | 48 BOLT (1/2-13X1.375-IN) | 2 | |
| 3J2903 | 49 COVER | 1 | |
| 5C6565 | 50 BOLT (1/2-13X1.125-IN) | 4 | |
| 8W3289 | 51 HOSE AS | 1 | |
| 8W3290 | 52 HOSE AS | 1 | |
| 2G3431 | 53 TUBE AS | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 2A6754 | 54 TUBE AS | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 2A6753 | 55 TUBE AS | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 8W8368 | 56 TUBE AS | 1 | |
| 7J5544 | FITTING (3/4X16-THD) | 1 | |
| 5J3306 | FITTING (9/16-18-THD)(9/16 - 18 THD) | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J0528 | 57 SEAL-O-RING | 4 | |
| 8T9391 | 58 BOLT (1/2-13X3.75-IN) | 12 | |
| 6D8305 | 59 CLAMP | 4 | |
| 7X0584 | 60 WASHER-HARD (13.5X20.5X2-MM THK) | 12 | |
| 6V3965 | 61 FITTING (QUICK DISCONNECT) | 1 | |
| 6V0852 | CAP-DUST | 1 | |
| 3J1907 | SEAL-O-RING (15.85MM OD) | 1 | |
| 6V0484 | ELBOW | 1 | |
| 8W4431 | 62 HOSE AS | 1 | |
| 8T8919 | 63 BOLT (1/2-13X1.75-IN) | 6 |
