System And Components
8W-4438 CONTROL GP-BRAKE -CHASSISS/N 6HK1-601
Group No: 8W-4438
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2D8910 | 1 ELBOW | 1 | |
| 3D6873 | 2 HOSE AS | 1 | |
| 2H3940 | 3 ELBOW | 3 | |
| 2L8228 | 4 ELBOW | 1 | |
| 5P7611 | 5 GROMMET | 1 | |
| 9D1829 | 6 CLIP | 2 | |
| 5S7379 | 7 BOLT (3/8-16X0.875-IN) | 9 | |
| 8T4896 | 8 WASHER-HARD (10.2X18.5X2.5-MM THK) | 15 | |
| 4D2489 | 9 HOSE AS | 1 | |
| 4D6463 | 10 CLIP | 4 | |
| 1D4717 | 11 NUT (3/8-16-THD) | 4 | |
| 5T9367 | 12 BRACKET | 1 | |
| 7D3957 | 13 HOSE AS | 1 | |
| 3B6552 | 14 ELBOW-PIPE | 1 | |
| 9D3352 | 15 ELBOW | 2 | |
| 5M6213 | 16 PLUG-PIPE (1/4-18-THD) | 2 | |
| 3G5587 | 17 HOSE AS | 1 | |
| 4D3734 | 18 ELBOW | 2 | |
| 4D4917 | 19 TEE | 2 | |
| 5D7688 | 20 HOSE AS | 1 | |
| 2B0858 | 21 PLUG-PIPE | 1 | |
| 5H4778 | 22 ELBOW | 1 | |
| 8T2502 | 23 BOLT (3/8-16X1.125-IN) | 2 | |
| 5M3062 | 24 BOLT (3/8-16X0.75-IN) | 1 | |
| 1137866 | 25 VALVE GP-RELAY (MASTER CYLINDERS) | 1 | |
| 3D8152 | 26 HOSE AS | 1 | |
| 4D7645 | 27 CLIP | 1 | |
| 4L6454 | 28 BOLT (3/8-16X1-IN) | 1 | |
| 7D3024 | 29 HOSE AS | 1 | |
| 5T9732 | 30 HOSE AS | 1 | |
| 5K8451 | 31 CLIP (LOOP)(15.88MM ID) | 1 | |
| 9M8406 | 32 CLIP (LOOP) | 2 | |
| 4S7570 | 33 HOSE AS | 1 | |
| 4S7606 | 34 ELBOW (EXTERNAL PIPE) | 2 | |
| 8X6263 | 35 HOSE AS | 1 | |
| 4D2560 | 36 CONNECTOR-PIPE | 1 | |
| 5H4778 | 37 ELBOW | 1 | |
| 3S6115 | 38 TEE | 1 | |
| 9M8406 | 39 CLIP (LOOP) | 11 | |
| 5S7379 | 40 BOLT (3/8-16X0.875-IN) | 4 | |
| 8T4896 | 41 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 4S7559 | 42 HOSE AS | 1 | |
| 3S8665 | 43 CLIP (LOOP) | 3 | |
| 2H9091 | 44 CONNECTOR-PIPE | 2 | |
| 8W4839 | 45 HOSE AS | 1 | |
| 7K1181 | 46 STRAP-CABLE | 3 | |
| 7D3963 | 47 HOSE AS | 1 | |
| 2H3940 | 48 ELBOW | 2 | |
| 3B7275 | 49 NIPPLE-PIPE | 1 | |
| 4D4267 | 50 ELBOW | 1 | |
| 2D8928 | 51 HOSE AS | 1 | |
| 4K5629 | 52 FITTING (1/2-14-THD) | 1 | |
| 7D5208 | 53 FITTING (QUICK DISCONNECT, FEMALE) | 1 | |
| 7D5207 | 54 PLUG | 1 | |
| 7D5206 | 55 CAP-DUST (BRAKE CONTROL) | 1 | |
| 5T9733 | 56 BRACKET | 1 | |
| 0026453 | 57 ELBOW | 1 | |
| 8D9423 | 58 COUPLING | 2 | |
| 4D6463 | 59 CLIP | 1 | |
| 4L6454 | 60 BOLT (3/8-16X1-IN) | 4 | |
| 2P4439 | 61 ADAPTER | 1 | |
| 5K8451 | 62 CLIP (LOOP)(15.88MM ID) | 3 | |
| 6D4247 | 63 CLIP | 3 | |
| 1139534 | KIT-SEAL & VALVE (MASTER CYLINDER RELAY VALVE) | 1 |
