System And Components
5T-1018 CONTROL GP-SERVICE BRAKE -CHASSISS/N 7EK670-UP
Group No: 5T-1018
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2H3940 | 1 ELBOW | 9 | |
| 9M8406 | 2 CLIP (LOOP) | 11 | |
| 0026453 | 3 ELBOW | 5 | |
| 7D5206 | 4 CAP-DUST (SERVICE BRAKE CONTROL) | 1 | |
| 7D5207 | 5 PLUG | 1 | |
| 7D5208 | 6 FITTING (QUICK DISCONNECT, FEMALE) | 1 | |
| 0026454 | 7 CONNECTOR | 4 | |
| 6D4244 | 8 CLIP (LOOP) | 3 | |
| 6J7929 | 9 HOSE AS | 1 | |
| 8W4373 | 10 HOSE AS | 1 | |
| 4D4267 | 11 ELBOW | 1 | |
| 3B7275 | 12 NIPPLE-PIPE | 1 | |
| 5M3062 | 13 BOLT (3/8-16X0.75-IN) | 7 | |
| 8T4896 | 14 WASHER-HARD (10.2X18.5X2.5-MM THK) | 18 | |
| 4D2560 | 15 CONNECTOR-PIPE | 1 | |
| 2H9091 | 16 CONNECTOR-PIPE | 3 | |
| 7D3024 | 17 HOSE AS | 1 | |
| 6D7661 | 18 HOSE AS | 2 | |
| 5L5502 | 19 FITTING | 2 | |
| 8X4909 | 20 HOSE AS | 1 | |
| 5H7549 | 22 CLIP | 2 | |
| 0S1595 | 23 BOLT (1/2-13X1.25-IN) | 2 | |
| 5P8245 | 24 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 1D4719 | 25 NUT-FULL (1/2-13-THD) | 1 | |
| 9G2029 | 26 STRIP | 1 | |
| 5S7379 | 27 BOLT (3/8-16X0.875-IN) | 2 | |
| 2G8992 | 28 CLAMP (SLOT) | 3 | |
| 5K8451 | 29 CLIP (LOOP) | 7 | |
| 8T2502 | 30 BOLT (3/8-16X1.125-IN) | 1 | |
| 2L8228 | 31 ELBOW (EXT PIPE THD) | 1 | |
| 8J8197 | 32 CLIP | 1 | |
| 3S2093 | 33 STRAP-CABLE | 3 | |
| 7K1181 | 34 STRAP-CABLE | 2 | |
| 1361715 | 35 PLATE | 1 | |
| 1595149 | 36 VALVE GP-RELAY (BRAKE AIR) | 2 | |
| 5C6565 | 37 BOLT (1/2-13X1.125-IN) | 2 | |
| 8T4223 | 38 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 5H4778 | 39 ELBOW | 2 | |
| 1539540 | 40 VALVE (BRAKE AIR) | 1 | |
| 5P1075 | 41 WASHER-HARD (10.2X22.5X3-MM THK) | 1 | |
| 5H4778 | 43 ELBOW | 2 | |
| 5H7549 | 45 CLIP | 1 | |
| 0S1595 | BOLT (1/2-13X1.25-IN) | 1 | |
| 5P8245 | WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 5D7688 | 46 HOSE AS | 1 | |
| 1476277 | 47 VALVE GP-CHECK (AIR/HYD CYLINDER) | 2 | |
| 9D3352 | 48 ELBOW | 2 | |
| 5M6213 | PLUG-PIPE (1/4-18-THD) | 2 | |
| 2D8910 | 50 ELBOW (EXT PIPE THD) | 1 | |
| 4S7606 | 51 ELBOW | 2 | |
| 3B6552 | 52 ELBOW-PIPE | 2 | |
| 7D2984 | 53 HOSE AS | 1 | |
| 8D9423 | 54 COUPLING | 1 | |
| 5T9733 | 55 BRACKET | 1 | |
| 5K8451 | 56 CLIP (LOOP) | 1 | |
| 6D3479 | CLIP (LOOP) | 1 | |
| 6V8801 | 57 NUT (3/8-16-THD) | 5 | |
| 3D8941 | 59 HOSE AS | 1 | |
| 5P7611 | 60 GROMMET | 1 | |
| 8W4839 | 61 HOSE AS | 1 | |
| 4S7562 | 62 HOSE AS | 1 | |
| 1079395 | 64 HOSE AS | 1 | |
| 2D8926 | 65 HOSE AS | 2 | |
| 8T2502 | 66 BOLT (3/8-16X1.125-IN) | 4 | |
| 0332177 | 67 TEE-PIPE | 1 | |
| 3G5587 | 68 HOSE AS | 1 | |
| 6D4244 | 70 CLIP (LOOP) | 1 | |
| 2P4439 | 71 ADAPTER | 1 | |
| 5S7379 | 72 BOLT (3/8-16X0.875-IN) | 1 | |
| 8X6263 | 73 HOSE AS | 2 | |
| 5S7382 | 74 BOLT (3/8-16X1.375-IN) | 2 | |
| 3J5389 | 76 PLUG (EXTERNAL) | 2 | |
| 4K8302 | 77 CLIP (LOOP) | 1 | |
| 1423439 | KIT-SEAL & VALVE (BRAKE AIR RELAY)(BRAKE AIR VALVE) | 1 |
