System And Components
137-0015 WIRING GP-CABS/N 1HW1-UP
Group No: 137-0015
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P5644 | 1 TRIM | ||
| 1V6688 | 2 GROMMET | 1 | |
| 3E0109 | 3 PLUG (ROCKER SWITCH) | 1 | |
| 3E2034 | 4 SWITCH AS-PRESSURE (AUTO ELECTRONIC TRACTION AID) | 1 | |
| 7N9738 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 3E2035 | 5 SWITCH AS-PRESSURE (MANUAL BRAKE RETARDER) | 1 | |
| 7N9738 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 3E5239 | 6 RELAY AS (24-VOLT) | 12 | |
| 3E6328 | 7 ALARM GP (24-VOLT)(ACTION) | 1 | |
| 3E6389 | 8 LAMP GP-DOME (24-VOLT)(CAB) | 1 | |
| 3E8646 | 9 CONVERTER AS-ELECTRICAL (24-VOLT TO 12-VOLT, 25-AMPERE) | 1 | |
| 3T0050 | 10 CLIP | 1 | |
| 3T3048 | 11 CLIP AS | 7 | |
| 3T1393 | 12 RESISTOR AS-CONNECTION | 1 | |
| 3T3270 | 12A WIRE AS (16-GA) | 1 | |
| 3T1415 | RESISTOR | 1 | |
| 3T3272 | CLIP | 1 | |
| 5P6008 | TUBE-HEAT SHRINK (6.35-MM DIA)(0.1M) | ||
| 3T4411 | 13 LAMP GP-FLOOD (24-VOLT)(LADDER) | 1 | |
| 4B1229 | 14 SCREW (10-24X12.7-MM) | 8 | |
| 5T4434 | 15 VALVE AS-SOLENOID (AUTO LUBE) | 1 | |
| 5D5569 | CONNECTOR | 1 | |
| 7D6081 | VALVE AS | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N9737 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 6D3033 | 16 SCREW-SOCKET HEAD (4-40X0.5-IN) | 8 | |
| 6V8187 | 17 NUT (1/4-28-THD) | 4 | |
| 6V9497 | 18 WASHER-HARD (3.2X6X0.5-MM THK) | 8 | |
| 7K1181 | 19 STRAP-CABLE | 74 | |
| 7T9074 | 20 VALVE GP-SOLENOID (24-VOLT)(AIR HORN) | 1 | |
| 8C6354 | 21 CAP-RECEPTACLE (ET CONNECTOR) | 1 | |
| 8D9537 | 22 CAP-DUST | 1 | |
| 9D4068 | 23 SWITCH-PUSH BUTTON (DOME LIGHT) | 1 | |
| 9F8125 | 24 LOCKWASHER | 2 | |
| 9G3695 | 25 PLUG-SEAL | 1 | |
| 9G9150 | 26 CLIP | 2 | |
| 9G9287 | 27 CONTROL GP-ENGINE ELECTRONIC (ENGINE SHUTDOWN) | 1 | |
| 9X0435 | 28 ADAPTER | 1 | |
| 9X3495 | 29 CLIP AS | 1 | |
| 1080358 | 30 FLASHER AS (24-VOLT) | 1 | |
| 1146658 | 31 WASHER (6.5X17X1-MM THK) | 4 | |
| 1160118 | 32 CLIP | 2 | |
| 1246704 | 33 RESISTOR AS (ETHER SOLENOID LOAD) | 2 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 3E3365 | WEDGE-RECEPTACLE LOCK (2-PIN) | 1 | |
| 5P6008 | TUBE-HEAT SHRINK (6.35-MM DIA)(0.4M) | ||
| 8C3334 | RIVET-TUBULAR | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 1259352 | 34 SWITCH AS-PRESSURE (STOP LAMP) | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N9738 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 1415746 | 35 SENSOR GP-PRESSURE (BRAKE AIR) | 1 | |
| 1437884 | 36 MODULE AS (INTERMITTENT WIPER) | 1 | |
| 1473655 | 37 PANEL GP-CIRCUIT BREAKER (VIMS) | 1 | |
| 1558826 | 38 PLATE AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 2 | |
| 7T1099 | LINK | 2 | |
| 9F6445 | NUT-WELD (1/4-20-THD) | 11 | |
| 1558828 | 39 PLATE AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 3 | |
| 7T1099 | LINK | 4 | |
| 9D6621 | NUT-WELD (10-24-THD) | 6 | |
| 9F6445 | NUT-WELD (1/4-20-THD) | 5 | |
| 1602445 | 40 SWITCH GP-PRESSURE (SECONDARY & PARKING BRAKE) | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N9738 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 1862485 | 41 HARNESS AS (MAIN CAB) | 1 | |
| 1610554 | 42 HARNESS AS (TRANSMISSION) | 1 | |
| 1610555 | 43 HARNESS AS-CAB (VIMS) | 1 | |
| 1610556 | 44 HARNESS AS (OVERHEAD CONSOLE) | 1 | |
| 1852361 | 45 HARNESS AS-PANEL (RELAY PANEL)(RELAY) | 1 | |
| 1635276 | 46 FILM-IDENTIFICATION (OPERATOR CONTROLS)(RELAY)(INCLS 12 FILMS) | 1 | |
| 1645393 | 47 PLUG AS-CONNECTOR (SPLICE) | 1 | |
| 1654026 | 48 SWITCH AS-MAGNETIC (24-VOLT)(MAIN POWER RELAY) | 1 | |
| 4F2294 | NUT-JAM (5/16-24-THD) | 2 | |
| 6V8186 | NUT-FULL (5/16-24-THD) | 2 | |
| 6V8378 | NUT (10-32-THD) | 2 | |
| 1268448 | 49 SCREW-FLAT HEAD (6-20X1.5-IN) | 3 | |
| 1474531 | 50 BOLT-SOCKET HEAD (10-24X0.37-IN) | 2 | |
| 1701305 | 51 SWITCH AS-ROCKER (OVERHEAD LAMP) | 1 | |
| 1655957 | 52 SWITCH AS-ROCKER (24-VOLT)(HAZARD LAMP) | 1 | |
| 1701310 | 53 SWITCH AS-ROCKER (BACK-UP LAMPS) | 1 | |
| 1701311 | 54 SWITCH AS-ROCKER (FOG LAMPS) | 1 | |
| 1701312 | 55 SWITCH AS-ROCKER (LADDER LAMP) | 1 | |
| 1H3338 | 56 LOCKWASHER | 4 | |
| 3J7354 | 57 SEAL-O-RING | 1 | |
| 3S2093 | 58 STRAP-CABLE | 13 | |
| 3S8665 | 59 CLIP (LOOP) | 1 | |
| 4B4274 | 60 WASHER (5.5X13X1.2-MM THK) | 10 | |
| 4B5324 | 61 WASHER (3.9X9.6X1.2-MM THK) | 24 | |
| 4D7794 | 62 CLIP | 2 | |
| 4M5281 | 63 BOLT (1/4-20X0.75-IN) | 4 | |
| 4P7429 | 64 CLIP (LADDER) | 1 | |
| 4P7581 | 65 CLIP (LADDER) | 3 | |
| 5M3062 | 66 BOLT (3/8-16X0.75-IN) | 18 | |
| 5P1075 | 67 WASHER-HARD (10.2X22.5X3-MM THK) | 5 | |
| 5P6264 | 68 GROMMET | 1 | |
| 5P7854 | 69 CLIP (LOOP) | 1 | |
| 5P8440 | 70 GROMMET | 1 | |
| 5S7349 | 71 BOLT (1/4-20X0.5-IN) | 12 | |
| 5S7379 | 72 BOLT (3/8-16X0.875-IN) | 1 | |
| 6B4540 | 73 NUT (4-40-THD) | 8 | |
| 6V2687 | 74 SCREW-PAN HEAD (10-24X1-IN) | 2 | |
| 6V8183 | 75 NUT-FULL (3/8-24-THD) | 2 | |
| 6V8188 | 76 NUT (1/2-13-THD) | 1 | |
| 7N9737 | 77 HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 7S7147 | 78 STUD (3/8-24, 3/8-16X1.5-IN) | 2 | |
| 8T4205 | 79 WASHER-HARD (7.2X14.5X2-MM THK) | 16 | |
| 8T4223 | 80 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8T4896 | 81 WASHER-HARD (10.2X18.5X2.5-MM THK) | 16 | |
| 8T9405 | 82 BOLT-SOCKET HEAD (M4X0.7X16-MM) | 24 | |
| 9G9154 | 83 CLIP | 2 | |
| 9X2044 | 84 SCREW-TRUSS HEAD (M6X1X16-MM) | 4 | |
| 1068704 | 85 SUPPRESSOR AS-ARC | 2 |
