System And Components
5T-4732 CONTROL GP-AIR STARTINGS/N AFS1-80
Group No: 5T-4732
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9D4609 | 1 RESERVOIR | 1 | |
| 6J1154 | 2 HOSE AS | 1 | |
| 1S0401 | 3 ELBOW | 1 | |
| 5S7379 | 4 BOLT (3/8-16X0.875-IN) | 2 | |
| 1S1015 | 5 CLIP (LOOP) | 1 | |
| 6G2229 | 6 GUARD | 1 | |
| 3L9157 | 7 GAUGE-PRESSURE | 1 | |
| 7J0482 | 8 ELBOW | 1 | |
| 4L6454 | 9 BOLT (3/8-16X1-IN) | 6 | |
| 3L7055 | 10 CONNECTOR-PIPE | 1 | |
| 6B9664 | 11 VALVE-AIR RELIEF | 1 | |
| 8T8917 | 12 BOLT (1/2-13X1.25-IN) | 4 | |
| 4D0670 | WASHER (0.562X1.19X0.188-IN THK) | 4 | |
| 3S8664 | 13 CLIP | 6 | |
| 5M3062 | 14 BOLT (3/8-16X0.75-IN) | 11 | |
| 6J0036 | 15 HOSE AS | 1 | |
| 8T8919 | 16 BOLT (1/2-13X1.75-IN) | 4 | |
| 8T4896 | 17 WASHER-HARD (10.2X18.5X2.5-MM THK) | 19 | |
| 8T4223 | 18 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 9D6663 | 19 VALVE-DRAIN | 1 | |
| 2G1349 | 20 COVER AS | 1 | |
| 1F0748 | NUT-WELD (1/2-13-THD) | 2 | |
| 9F2978 | 21 NUT-WELD (3/8-16-THD) | 4 | |
| 4D0582 | 22 ELBOW | 1 | |
| 4D0487 | 23 VALVE AS-CHECK (AIR START) | 1 | |
| 2G1153 | 24 BRACKET | 2 | |
| 6G2292 | 25 BRACKET AS | 2 | |
| 5B7666 | 26 ELBOW | 2 | |
| 7B0497 | 27 NIPPLE-PIPE | 1 | |
| 6B3685 | 28 ELBOW | 1 | |
| 5T7972 | 29 HOSE AS | 1 | |
| 6V9013 | 30 ELBOW | 1 | |
| 5P4325 | 31 CLIP (LOOP) | 1 | |
| 5M3062 | 32 BOLT (3/8-16X0.75-IN) | 3 | |
| 6V8801 | 33 NUT (3/8-16-THD) | 1 | |
| 8T4896 | 34 WASHER-HARD (10.2X18.5X2.5-MM THK) | 3 | |
| 5T4728 | 35 HOSE AS | 1 | |
| 5P2369 | 36 CLIP (LOOP) | 1 | |
| 5P2370 | 37 CLIP | 1 | |
| 8T9364 | 38 BOLT (1/4-20X0.625-IN) | 2 | |
| 8T4205 | WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 4S6668 | 39 CLIP (LOOP) | 1 | |
| 5T4434 | 40 VALVE AS-SOLENOID (ACTUATES AIR STARTER) | 1 | |
| 7D6081 | VALVE AS | 1 | |
| 5D5569 | CONNECTOR | 1 | |
| 7N9737 | 41 HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 3B6552 | 42 ELBOW-PIPE | 1 | |
| 9D3352 | 43 ELBOW | 1 | |
| 6L5955 | 44 ELBOW | 1 | |
| 4D5914 | 45 HOSE AS | 1 | |
| 3D8911 | 46 CONNECTOR-PIPE | 1 | |
| 6F7732 | BUSHING-REDUCER | 1 | |
| 4N3411 | 47 VALVE GP-RELAY | 1 | |
| 5B7661 | FITTING | 2 | |
| 5H4778 | 48 ELBOW | 3 | |
| 4S6667 | 49 HOSE AS | 1 | |
| 5D7464 | 50 HOSE AS | 1 | |
| 3D8884 | 51 ELBOW | 1 | |
| 4H6147 | 52 CONNECTOR | 2 | |
| 1L2782 | 53 TEE-PIPE | 1 | |
| 1L1722 | 54 CONNECTOR-PIPE | 1 | |
| 4D7969 | 55 HOSE AS | 1 | |
| 4K5629 | 56 FITTING (1/2-14-THD) | 1 | |
| 7D5208 | FITTING (QUICK DISCONNECT, FEMALE) | 1 | |
| 7D5207 | 57 PLUG | 1 | |
| 7D5206 | 58 CAP-DUST | 1 | |
| 8D9423 | 59 COUPLING | 1 | |
| 3D7587 | 60 ELBOW | 2 |
