System And Components
177-7949 LINES GP-HYDRAULIC OIL COOLER -TORQUE CONVERTER, HOIST, BRAKES/N AFS1-UP
Group No: 177-7949
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W2860 | 1 BRACKET | 1 | |
| 2A6780 | 2 HOSE AS | 1 | |
| 2G2213 | 3 TEE | 1 | |
| 2G6104 | 4 TUBE AS | 1 | |
| 4S1253 | 5 PLATE | 1 | |
| 5G4313 | 6 SPACER (10.34X15.88X12-MM THK) | 1 | |
| 5T0017 | 7 ELBOW | 1 | |
| 5T5533 | 8 MANIFOLD | 1 | |
| 5T6742 | 9 ELBOW | 1 | |
| 5T6778 | 10 MANIFOLD | 1 | |
| 5T9030 | 11 TUBE | 1 | |
| 7K2828 | 12 CLIP | 4 | |
| 8W0958 | 13 HOSE AS | 2 | |
| 8W0959 | 14 HOSE AS | 1 | |
| 8W3289 | 15 HOSE AS | 1 | |
| 8W3290 | 16 HOSE AS | 1 | |
| 8W3291 | 17 HOSE AS | 1 | |
| 8W3292 | 18 HOSE AS | 1 | |
| 2015475 | 19 HOSE AS | 1 | |
| 8W5566 | 20 ADAPTER | 1 | |
| 9T1460 | 21 SCREEN (HYDRAULIC OIL COOLER LINES) | 1 | |
| 1047658 | 22 ELBOW | 1 | |
| 1050170 | 23 VALVE GP-DIVERTER (BRAKE COOLING) | 1 | |
| 1196706 | 24 TUBE AS | 1 | |
| 1196707 | 25 TUBE AS | 1 | |
| 1196708 | 26 TUBE AS | 1 | |
| 1196709 | 27 TUBE AS | 1 | |
| 1488417 | 28 REDUCER AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8941 | REDUCER | 1 | |
| 1549001 | 29 HOSE AS | 1 | |
| 1553624 | 30 PLUG AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 9S4182 | PLUG (7/16-20-THD) | 1 | |
| 1732763 | 31 TUBE AS | 1 | |
| 1741530 | 32 PLUG AS | 1 | |
| 1N5998 | PLUG | 1 | |
| 6K6307 | SEAL-O-RING | 1 | |
| 1752810 | 33 HOSE AS | 1 | |
| 1092332 | 34 SEAL-O-RING | 2 | |
| 1488330 | 35 CONNECTOR AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 8T0198 | CONNECTOR | 1 | |
| 1488407 | 36 PLUG AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 1713673 | 37 TEE AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 2 | |
| 1087005 | TEE-O-RING | 1 | |
| 1P3707 | 38 SEAL-RECTANGULAR | 1 | |
| 1P3708 | 39 SEAL-RECTANGULAR | 1 | |
| 1P4579 | 40 FLANGE-HALF | 2 | |
| 1P4582 | 41 FLANGE-HALF | 38 | |
| 3H7654 | 42 WASHER-HARD (13.5X22.5X3-MM THK) | 4 | |
| 3J2903 | 43 COVER | 1 | |
| 4J0524 | 44 SEAL-O-RING | 1 | |
| 4J0527 | 45 SEAL-O-RING | 28 | |
| 4J0528 | 46 SEAL-O-RING | 4 | |
| 4L6454 | 47 BOLT (3/8-16X1-IN) | 2 | |
| 5C6565 | 48 BOLT (1/2-13X1.125-IN) | 5 | |
| 5P1075 | 49 WASHER-HARD (10.2X22.5X3-MM THK) | 6 | |
| 5P2424 | 50 BOLT (1/2-13X2.25-IN) | 4 | |
| 5P2566 | 51 BOLT (1/2-13X1.5-IN) | 68 | |
| 5P7470 | 52 CLIP (SLOT) | 3 | |
| 5P7471 | 53 CLIP (TAB) | 3 | |
| 6D8305 | 54 CLAMP | 4 | |
| 6E6640 | 55 SCREEN AS (HYDRAULIC OIL)(HYDRAULIC OIL COOLER LINES) | 1 | |
| 6F8146 | 56 SEAL-O-RING | 2 | |
| 6G1444 | 57 ADAPTER | 1 | |
| 6V8188 | 58 NUT (1/2-13-THD) | 2 | |
| 6V8801 | 59 NUT (3/8-16-THD) | 2 | |
| 6V8556 | 60 NUT (1-3/16-12-THD) | 1 | |
| 7X0331 | 61 BOLT (1/2-13X4.25-IN) | 2 | |
| 7X0334 | 62 BOLT (1/2-13X5-IN) | 4 | |
| 7X0584 | 63 WASHER-HARD (13.5X20.5X2-MM THK) | 12 | |
| 8C4436 | 64 BOLT (1/2-13X1.375-IN) | 2 | |
| 8G0423 | 65 PLATE | 1 | |
| 8T2501 | 66 BOLT (3/8-16X2-IN) | 1 | |
| 8T4223 | 67 WASHER-HARD (13.5X25.5X3-MM THK) | 121 | |
| 8T4835 | 68 BOLT (1/2-13X2-IN) | 9 | |
| 8T8919 | 69 BOLT (1/2-13X1.75-IN) | 37 | |
| 8T9391 | 70 BOLT (1/2-13X3.75-IN) | 4 | |
| 9B7237 | 71 BOLT (3/8-16X1.25-IN) | 1 | |
| 9D6196 | 72 CLIP (SLOT) | 1 | |
| 9D6197 | 73 CLIP (TAB) | 1 | |
| 6V1867 | 74 CLIP (SLOT) | 2 | |
| 6V1868 | 75 CLIP (TAB) | 2 | |
| 6V1869 | 76 GROMMET (65-MM ID) | 2 | |
| 1488392 | 77 ELBOW AS | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 6V9853 | ELBOW | 1 |
