System And Components
548-1004 TANK GP-FUELS/N FDB1-UP
Group No: 548-1004
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E7753 | 1 FLOAT AS | 1 | |
| 6G7803 | 2 VENT AS | 1 | |
| 1050381 | 3 BLOCK | 1 | |
| 2457451 | 4 BREATHER AS (FUEL TANK) | 1 | |
| 3552924 | 5 VENT AS-FUEL TANK | 1 | |
| 1488373 | 6 ELBOW AS | 1 | |
| 6V8400 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 8C3364 | ELBOW | 1 | |
| 1J9671 | 7 SEAL-O-RING | 2 | |
| 2057303 | 8 ADAPTER-FAST FILL FUEL | 1 | |
| 2525806 | 9 VALVE AS-SHUTOFF (FAST FILL FUEL) | 1 | |
| 5689142 | 10 HOSE AS | 1 | |
| 3619792 | 11 HOSE AS | 1 | |
| 3J2903 | 12 COVER | 1 | |
| 4J0527 | 13 SEAL-O-RING | 1 | |
| 5481007 | 14 TANK AS-FUEL | 1 | |
| 5P2618 | 15 CONNECTOR | 2 | |
| 7D1553 | 16 CLIP | 1 | |
| 8T4121 | 17 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4137 | 18 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4223 | 19 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T5005 | 20 BOLT (M10X1.5X70-MM) | 2 | |
| 8T8919 | 21 BOLT (1/2-13X1.75-IN) | 4 | |
| 9M0164 | 22 CLAMP-HOSE | 1 | |
| 9M7958 | 23 CLAMP-HOSE | 1 | |
| 5T8645 | KIT-VENT (FUEL TANK) | 1 | |
| 2721595 | KIT-VENT (FUEL TANK) | 1 |
