System And Components
584-8350 LINES GP-WATERS/N SMP1-UP
Group No: 584-8350
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1587 | 1 BOLT (1/2-13X1.75-IN) | 8 | |
| 0S1588 | 2 BOLT (3/8-16X1.25-IN) | 4 | |
| 0S1594 | 3 BOLT (3/8-16X1-IN) | 15 | |
| 0S1608 | 4 BOLT (3/8-16X3.75-IN) | 1 | |
| 0S1621 | 5 BOLT (1/2-13X1-IN) | 16 | |
| 0T0055 | 6 BOLT (3/8-16X4.25-IN) | 4 | |
| 0T0065 | 7 BOLT (3/8-16X3.5-IN) | 4 | |
| 0T0573 | 8 BOLT (3/8-16X2.75-IN) | 1 | |
| 0V0375 | 9 BOLT (1/2-13X3.25-IN) | 5 | |
| 1075769 | 10 SEAL-O-RING | 2 | |
| 1090074 | 11 SEAL-O-RING | 1 | |
| 1090076 | 12 SEAL-O-RING | 3 | |
| 1090077 | 13 SEAL-O-RING | 2 | |
| 1123258 | 14 SEAL-O-RING | 1 | |
| 1275447 | 15 SPACER (10.5X20X12-MM THK) | 1 | |
| 1700612 | 16 STUD (3/8-16X4-IN) | 1 | |
| 1744883 | 17 STUD (3/8-16X2-IN) | 1 | |
| 1A2029 | 18 BOLT (3/8-16X1.125-IN) | 4 | |
| 1C2251 | 19 BOLT (3/8-16X1.87-IN) | 6 | |
| 1D4566 | 20 BOLT (1/2-13X3.5-IN) | 5 | |
| 1J3619 | 21 COVER | 4 | |
| 1W1038 | 22 STUD (3/8-16X2.75-IN) | 2 | |
| 2301294 | 23 ELBOW | 1 | |
| 2301296 | 24 ELBOW | 1 | |
| 2301302 | 25 FLANGE | 3 | |
| 2314708 | 26 SEAL-O-RING | 5 | |
| 2343438 | 27 ELBOW | 1 | |
| 2362502 | 28 COVER | 2 | |
| 2374180 | 29 COVER-WATER PUMP | 1 | |
| 2395225 | 30 HOUSING AS (REGULATOR) | 1 | |
| 3B0622 | PLUG-CUP | 1 | |
| 3S9643 | SEAL-LIP TYPE | 2 | |
| 1114374 | VALVE AS (VENT LINES) | 1 | |
| 2485513 | 31 REGULATOR-TEMPERATURE (92-DEG C) | 2 | |
| 2499383 | 32 BONNET | 1 | |
| 2499384 | 33 TUBE AS-BYPASS | 1 | |
| 2502008 | 34 BONNET | 1 | |
| 2502009 | 35 BONNET | 1 | |
| 2514122 | 36 PLATE | 2 | |
| 2B0947 | 37 BOLT (1/2-13X2.25-IN) | 2 | |
| 3008720 | 38 STUD (3/8-16X0.393-IN) | 3 | |
| 3048008 | 39 PLUG AS | 2 | |
| 6V9027 | SEAL-O-RING | 1 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 3345375 | 40 STUD (3/8-16X5.26-IN) | 1 | |
| 3438888 | 41 GASKET | 1 | |
| 3535126 | 42 PLUG AS | 2 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 9S8005 | PLUG (3/4-16-THD) | 1 | |
| 3535140 | 43 PLUG AS | 5 | |
| 6V5063 | SEAL-O-RING | 1 | |
| 9S8008 | PLUG (1-1/16-12-THD) | 1 | |
| 3535144 | 44 PLUG AS | 1 | |
| 6V5064 | SEAL-O-RING | 1 | |
| 9S9334 | PLUG (1-5/16-12-THD) | 1 | |
| 3J6933 | 45 GASKET | 4 | |
| 4N1946 | 46 GASKET | 1 | |
| 5882140 | 47 BRACKET AS | 1 | |
| 5B9603 | 48 BOLT (3/8-16X5-IN) | 2 | |
| 5M2894 | 49 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 5P8245 | 50 WASHER-HARD (13.5X25.5X3-MM THK) | 20 | |
| 6N0008 | 51 ADAPTER | 1 | |
| 7C0145 | 52 CORE AS-OIL COOLER (ENGINE) | 1 | |
| 7G1239 | 53 SPACER (10.5X19X4.5-MM THK) | 1 | |
| 7N1637 | 54 STUD (3/8-16X2.5-IN) | 1 | |
| 2572122 | 55 BOLT (1/2-13X5.75-IN) | 1 | |
| 8M9024 | 56 WASHER-HARD (10.2X22.5X5-MM THK) | 4 | |
| 8T1703 | 57 SEAL-O-RING | 4 | |
| 8T2929 | 58 SEAL-O-RING | 2 | |
| 9X6458 | 59 WASHER-HARD (10.2X22.5X3-MM THK) | 10 | |
| 0L1329 | 60 BOLT (1/2-13X3-IN) | 1 | |
| 6F5282 | 61 BOLT (1/2-13X5.25-IN) | 2 |
