System And Components
3Q-6748 LINES GP-TRAVEL MOTORPART OF 9Q-5195, 9Q-5197, 9Q-5198, 9Q-5232 UNDERCARRIAGE AR
Group No: 3Q-6748
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7Y4800 | 1 SWIVEL GP | 1 | |
| 4I5546 | 2 SUPPORT | 1 | |
| 8T4648 | 3 BOLT (M12X1.75X70MM) | 2 | |
| 8T4223 | 4 WASHER-HARD (13.5X25.5X3MM THK) | 26 | |
| 1P3703 | 5 SEAL-RECTANGULAR | 12 | |
| 6V9844 | 6 TEE-SWIVEL | 1 | |
| 6V8398 | 7 SEAL-O-RING | 5 | |
| 4I7745 | 8 CONNECTOR | 1 | |
| 3D2824 | 9 SEAL-O-RING | 1 | |
| 8T4184 | 10 BOLT (M12X1.75X45MM) | 16 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5MM THK) | 22 | |
| 6V8397 | 12 SEAL-O-RING | 5 | |
| 3J1907 | 13 SEAL-O-RING | 1 | |
| 6V8724 | 14 ELBOW | 2 | |
| 8T4956 | 15 BOLT (M12X1.75X35MM) | 8 | |
| 3K0360 | 16 SEAL-O-RING | 2 | |
| 6V8625 | 17 ELBOW | 2 | |
| 3Q6749 | 18 TUBE AS | 1 | |
| 3Q6750 | 19 TUBE AS | 1 | |
| 9X6032 | 20 BOLT-SOCKET HEAD (M10X1.5X30MM) | 16 | |
| 7Y4531 | 21 CLAMP-HALF | 8 | |
| 9R6247 | 22 STRAP-CABLE | 2 | |
| 8Y0608 | 23 HOSE AS | 2 | |
| 3Q6844 | 24 HOSE AS | 2 | |
| 6V8788 | 25 TEE | 1 | |
| 3Q6753 | 26 HOSE AS | 2 | |
| 3Q6754 | 27 HOSE AS | 2 | |
| 8T0788 | 28 ELBOW | 1 | |
| 3Q6751 | 29 TUBE AS | 1 | |
| 3Q6752 | 30 TUBE AS | 1 | |
| 1P3702 | 31 SEAL-RECTANGULAR | 4 | |
| 1P5766 | 32 FLANGE-HALF | 8 | |
| 1P5765 | 33 FLANGE-HALF | 8 | |
| 8T4182 | 34 BOLT (M10X1.5X45MM) | 22 | |
| 1P3704 | 35 SEAL-RECTANGULAR | 4 | |
| 2M9780 | 36 SEAL-O-RING | 2 | |
| 6V5839 | 37 WASHER (11X21X2.5MM THK) | 16 |
