System And Components
455-0037 MOUNTING GP-RIMS/N D3T1-UP
Group No: 455-0037
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5T9790 | 1 VALVE GP-TIRE (TIRE INFLATION) | 6 | |
| 5T9797 | VALVE AS-TIRE | 1 | |
| 6F3930 | CORE-VALVE | 1 | |
| 6J3134 | SEAL-O-RING | 1 | |
| 9K7951 | CAP-VALVE | 1 | |
| 5T9798 | SPUD AS | 1 | |
| 2D2508 | GROMMET | 1 | |
| 5T9866 | LOCKNUT (11/16-24-THD) | 1 | |
| 5T9796 | 2 CONNECTOR | 2 | |
| 8W0331 | 3 CONNECTOR-SWIVEL | 4 | |
| 2807372 | 4 PLATE | 2 | |
| 2809835 | 5 PLATE | 2 | |
| 4556544 | 6 HOSE AS | 2 | |
| 4556547 | 7 BRACKET | 2 | |
| 5P1076 | 8 WASHER-HARD (13.5X30X4-MM THK) | 4 | |
| 6V8237 | 9 WASHER (26X44X4-MM THK) | 280 | |
| 7X0851 | 10 NUT (M24X3-THD) | 280 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4139 | 12 BOLT (M12X1.75X30-MM) | 4 | |
| 8T4191 | 13 BOLT (M10X1.5X16-MM) | 4 | |
| 8W0338 | 14 SEAL-O-RING | 8 |
