System And Components
334-5019 BRAKE GP-SERVICE & PARKING -REARS/N KAK1-UP
Group No: 334-5019
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6G6282 | 1 PISTON | 1 | |
| 6G6500 | 2 DAMPER AS | 2 | |
| 6V2656 | 3 SEAL-RING | 1 | |
| 6V2658 | 4 SEAL-RING | 1 | |
| 6V2662 | 5 SEAL-RING | 1 | |
| 6V2772 | 6 SEAL-O-RING | 2 | |
| 8W0212 | 7 PLATE-OUTER | 14 | |
| 8W1357 | 8 SEAL-RING | 1 | |
| 8X2495 | 9 RING | 1 | |
| 9D6093 | 10 SPRING | 46 | |
| 9D6135 | 11 SPRING | 42 | |
| 9D7989 | 12 NUT (5/8-11-THD) | 24 | |
| 9D9118 | 13 SPRING-GUIDE | 4 | |
| 9D9121 | 14 SPRING | 4 | |
| 9X7313 | 15 SEAL-O-RING | 1 | |
| 1237269 | 16 SEAL-RING | 1 | |
| 1237273 | 17 SEAL-RING | 1 | |
| 1237274 | 18 SEAL-RING | 1 | |
| 1237275 | 19 SEAL-RING | 1 | |
| 1387101 | 20 PISTON | 1 | |
| 1970960 | 21 HUB-BRAKE | 1 | |
| 3754396 | 22 PLATE | 1 | |
| 2262826 | 23 DISC-FRICTION (EXTENDED LIFE) | 15 | |
| 3345021 | 24 ANCHOR-BRAKE | 1 | |
| 3345023 | 25 HOUSING | 1 | |
| 3371943 | 26 SEAL-RECTANGULAR | 2 | |
| 1394774 | 27 STUD-TAPERLOCK (7/8-9X3.74-IN) | 47 | |
| 1394775 | 28 STUD-TAPERLOCK (1-8X4-IN) | 21 | |
| 1D4624 | 29 BOLT (3/4-10X9-IN) | 12 | |
| 2M9780 | 30 SEAL-O-RING | 5 | |
| 3B2968 | 31 BOLT (3/4-10X3.5-IN) | 44 | |
| 4E9311 | 32 BOLT (3/4-10X4-IN) | 55 | |
| 5D4809 | 33 STUD-TAPERLOCK (5/8-11X4.213-IN) | 16 | |
| 5P8248 | 34 WASHER-HARD (20X36.5X3.5-MM THK) | 111 | |
| 6M9155 | 35 PIN | 4 | |
| 9S4190 | 36 PLUG-O-RING (7/8-14-THD) | 5 | |
| 9X2497 | 37 STUD-TAPERLOCK (5/8-11X10.63-IN) | 8 |
