System And Components
238-4867 TANK AS-FUELS/N 5YW1-UP
Group No: 238-4867
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1H8306 | 1 SCREW-PURGE (1/2-20X1.625-IN) | 1 | |
| 3270918 | 2 CHANNEL | 1 | |
| 1B5174 | 3 PLUG-PIPE | 1 | |
| 2H3934 | 4 SEAL-O-RING | 1 | |
| 2S4078 | 5 SEAL-O-RING | 1 | |
| 3B0551 | 6 PLUG-PIPE | 1 | |
| 4H9027 | 7 PLUG-PIPE | 4 | |
| 4R8932 | 8 PLUG-PIPE | 2 | |
| 5C9553 | 9 BOLT (M6X1X16-MM) | 6 | |
| 6H1147 | 10 STRIP | 3 | |
| 6V5051 | 11 SEAL-O-RING | 1 | |
| 7M8485 | 12 SEAL-O-RING | 2 | |
| 8T4121 | 13 WASHER-HARD (11X21X2.5-MM THK) | 12 | |
| 8T4136 | 14 BOLT (M10X1.5X25-MM) | 12 | |
| 8X5146 | 15 LUG | 1 | |
| 9S4181 | 16 PLUG (1-5/16-12-THD) | 2 | |
| 9S6130 | 17 PLUG | 1 | |
| 9X8256 | 18 WASHER (6.6X12X2-MM THK) | 6 | |
| 1737185 | 19 PLATE AS | 1 | |
| 1152241 | 20 PLATE | 1 |
