System And Components
291-5085 TANK AS-FUELS/N FDB1-1422
Group No: 291-5085
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9S4190 | 1 PLUG-O-RING (7/8-14-THD) | 1 | |
| 1H8306 | 2 SCREW-PURGE (1/2-20X1.625-IN) | 1 | |
| 2934576 | 3 GAUGE (SIGHT GLASS)(FUEL TANK) | 5 | |
| 1152241 | 9 PLATE | 1 | |
| 1643417 | 13 COVER | 2 | |
| 1871679 | 17 COVER | 2 | |
| 2156404 | 21 PLATE AS | 3 | |
| 1B5174 | 42 PLUG-PIPE | 1 | |
| 1H8128 | 43 SEAL-O-RING | 2 | |
| 2M9780 | 45 SEAL-O-RING | 1 | |
| 3B0551 | 46 PLUG-PIPE | 1 | |
| 3D2824 | 47 SEAL-O-RING | 5 | |
| 4H9027 | 48 PLUG-PIPE | 1 | |
| 4R8932 | 49 PLUG-PIPE | 2 | |
| 5H6734 | 50 SEAL-O-RING | 2 | |
| 5S7379 | 51 BOLT (3/8-16X0.875-IN) | 24 | |
| 6V5051 | 53 SEAL-O-RING | 1 | |
| 7M8485 | 54 SEAL-O-RING | 1 | |
| 8T4121 | 56 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4136 | 57 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4223 | 58 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 8T4896 | 59 WASHER-HARD (10.2X18.5X2.5-MM THK) | 24 | |
| 8T8917 | 60 BOLT (1/2-13X1.25-IN) | 6 | |
| 9S4181 | 64 PLUG (1-5/16-12-THD) | 1 |
