System And Components
297-5660 TANK GP-FUELS/N LAJ1-543
Group No: 297-5660
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1H8306 | 1 SCREW-PURGE (1/2-20X1.625-IN) | 1 | |
| 1152241 | 2 PLATE | 1 | |
| 1643417 | 3 COVER | 2 | |
| 1871679 | 4 COVER | 3 | |
| 2801065 | 5 PLATE AS | 2 | |
| 1B5174 | 7 PLUG-PIPE | 1 | |
| 2385082 | 8 SEAL-O-RING | 2 | |
| 2385084 | 9 SEAL-O-RING | 1 | |
| 3E6773 | 10 SEAL-O-RING | 3 | |
| 4H9027 | 11 PLUG-PIPE | 1 | |
| 4R8932 | 12 PLUG-PIPE | 1 | |
| 5P9436 | 13 PLUG | 1 | |
| 6V5051 | 14 SEAL-O-RING | 1 | |
| 8T4121 | 15 WASHER-HARD (11X21X2.5-MM THK) | 34 | |
| 8T4136 | 16 BOLT (M10X1.5X25-MM) | 34 | |
| 8T4223 | 17 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4956 | 18 BOLT (M12X1.75X35-MM) | 4 | |
| 9S4181 | 19 PLUG (1-5/16-12-THD) | 1 | |
| 9S4183 | 20 PLUG (1-1/16-12-THD) | 1 | |
| 9X7287 | 21 SEAL-O-RING | 2 |
